Introduction

Installation Precautions

WARNING
• Take measures to prevent the instrument from falling
in the event of an earthquake or other disaster.
Strong vibrations could cause the instrument to fall over,
resulting in injury.
• The power supply voltages and power consumptions
of this instrument are listed below. The power supply
voltage of the instrument is indicated on the label on
the back of the instrument. Connect the instrument
only to a power supply of the voltage indicated;
otherwise, fire or electric shock could result. Check that the
power supply voltage is stable and that its current capacity is
sufficient to operate all the components of the system. If not, the
instrument will not operate at its rated performance. When using
CBM-20Alite, refer to the instruction manuals of the incorporated
instruments for power supply voltages and power consumptions.
CBM-20A
Part No.
228-45012-31
228-45012-32
228-45012-38
1: 100 VA, if AC OUT is not used.
• Ground the instrument.
Grounding is necessary to prevent electric shock in the
event of an accident or electrical discharge, and
important for ensuring stable operation.
• Do not place heavy objects on the power cord,
and keep any hot items away.
The cord could be damaged, resulting in fire, electrical
shock or malfunction. If the cord becomes damaged,
contact your Shimadzu representative immediately.
• Do not modify the cord in any way. Do not bend
it excessively or pull on it.
The cord could be damaged, resulting in fire, electrical
shock or malfunction. If the cord becomes damaged,
contact your Shimadzu representative immediately.
VIII
Power Supply Voltage
(indicated on the instrument)
AC 100-120 V (100-120 V
AC 100-120 V (100-120 V
AC 220-240 V (220-240V
Power
Consumption
1
∼
400 VA
)
1
∼
400 VA
)
1
∼
400 VA
)
Frequency
50-60 Hz
50-60 Hz
50-60 Hz
CBM-20A/20Alite
