Summary of Contents for Hoover Dual V Advance
- Page 1 Dual V Advance User Guide HW86-DVA-S Version 1.0...
-
Page 2: Table Of Contents
CONTENTS Contents Machine Overview General Safety Information Operation Maintenance FAQs Other Information... -
Page 3: Machine Overview
Stretch hose caddy Max Extract pedal Recline pedal Accessories Wheels Hoover cleaning solution Hard floor squeegee (Available on some models only) Base lint filter Upholstery tool *Some parts may vary according to model. Please check inside flap of box for more details. -
Page 4: General Safety Information
9. The appliance should only be used as described in the quick start guide (if applicable) or in the full online user guide. 10. Only Hoover recommended attachments and solutions should be used with this appliance. 11. Do not use this carpet washer if it has been dropped, damaged, left outdoors or dropped into water. -
Page 5: Operation
OPERATION Please read General Safety Information at the beginning before use. Assembling your carpet washer handle and Spinscrub wash tool Place handle on machine. Turn the dial clockwise to Place Spinscrub tool in secure the handle. caddy. Assembling your tool caddy and hose Attach top caddy section Turn locking tab clockwise Attach bottom caddy... - Page 6 • Test your carpets/rugs/upholstery - Run the machine over a small hidden area. If no pile distortion occurs continue cleaning over required area. IMPORTANT: Only use Hoover carpet cleaning solution. Using other solutions may cause excess foaming. Excessive foam will prevent the machine from working effectively. Using other solutions will invalidate the guarantee.
- Page 7 OPERATION Operating your carpet washer Remove the detergent tank cap and pour required carpet/hard floor cleaning solution into tank. Tighten cap before returning tank to unit. Wash/Rinse/Max Extract switch The wash/rinse/max extract switch allows you to easily change from cleaning your carpet with a solution/water mix, rinsing with water only, and solely extracting water and solution from your carpet.
- Page 8 OPERATION Washing your carpets Unwrap power cord and Turn the machine on. Recline the machine. When Set the wash/rinse/max plug unit in. the machine is reclined, extract switch to WASH. the brushes will rotate. In Spinscrub brushes deep an upright position, the clean your carpets with brushes will not rotate.
- Page 9 OPERATION Washing hard floors CAUTION: To prevent damage to wood floors and other hard floors, follow the flooring manufacturer’s cleaning recommendations. NOTE: If using cleaner on sealed wood floors, inspect floor surface for worn finish, bare wood or separated joints. It’s not recommended to use the cleaner on wood floors if any of these conditions exist.
- Page 10 OPERATION Rinsing your carpets and hard floors (optional) Rinsing is not necessary, but will help remove solution and residue and help your carpets or hard floors look fresher. Turn the machine on. Recline the machine. Set the wash/rinse/max When the machine is extract switch to RINSE.
- Page 11 OPERATION Max Extract switch and pedal (optional) When the MAX EXTRACT function is selected, no water/solution mix is released onto your carpets or hard floors even when trigger is pressed. Turn the machine on. Recline the machine. Set the wash/rinse/max extract switch to MAX EXTRACT.
- Page 12 OPERATION Picking up spills For small spills, use the upholstery wash tool provided. Remove hose. Place hose into hose connection port and turn clockwise to secure. Align solution tube with Attach the upholstery wash Turn the machine on. Pull wash tool back over connector port.
- Page 13 Run the Spinscrub brush and upholstery wash tools over a small hidden area. The Spinscrub wash tool has rotating brushes to tackle spots and stains. The clean water tank will need to be filled with Hoover carpet cleaning solution and water before use. Remove hose.
- Page 14 NOTE: Rinse out tank with clean water and leave to air dry before storing your machine. Cleaning the dirty water tank lint filter Important: Cleaning filters maintains cleaning performance. Hoover recommends that your filters should be checked and cleaned after each use.
- Page 15 MAINTENANCE Cleaning the base lint filter This filter should be checked and cleaned after every use. Place the machine flat Remove the filter. Rinse under water to Allow to dry completely and locate the base lint remove debris. before replacing or storing filter.
-
Page 16: Maintenance
MAINTENANCE WARNING: To reduce the risk of electric shock, turn the machine off and unplug from electrical socket before performing maintenance/troubleshooting checks. Important: All water and solution must be removed from tanks before removing blockages from the brushes. Removing blockages from the brushes Place the machine flat. -
Page 17: Faqs
FAQs Is there an accessory missing? • Check the ‘This pack contains’ panel on the box to make sure the part is definitely included in your unit Why won’t the carpet washer turn on? • It may not be plugged into the electrical socket correctly: ensure that the plug is pushed in securely and switched on •... -
Page 18: Other Information
Other Information Service & Help If you have queries or concerns about using your Hoover, please visit www.hoover.ae Technical Specification Voltage: 220-240V ~50/60Hz Wattage: 1350W Clean water tank capacity: 3.7L Dirty water tank: 3.2L Cord length: 10m Weight: 10.3kg (depending on model) - Page 19 NOTES...
