ETI PI-800-GEN2 Instruction Manual page 11

Electrical Test Instruments PI-800 GEN2 and PI-1600 GEN2
PI800 GEN2
OPTION A INPUT SUPPLY:
120 or 240 VAC + 10%, -15% (Switch Selectable), SINGLE PHASE
60 HZ (50 Hz at 10% lower maximum line voltages)
4.2 KVA (Continuous) at 3.8 KVA output (90% efficiency)
PI-800 GEN2 OUTPUT CURRENT & OVERLOAD CAPABILITIES:
4.2V (S/P) 8.4 V
(Ser)
800 A 400 A
1120 A 560 A
1600 A 800 A
2400 A 1200 A
3200 A 1600 A
4000 A 2000 A
5600 A * 2800 A *
8000 A * 4000 A *
*Available with 240 VAC input only; Max ON Times may be less at 120 VAC
**Maximum output current possible into short circuit with very low source impedance
OPTION B INPUT SUPPLY:
208, 240 or 277 VAC + 10%, -15% (Switch Selectable), SINGLE PHASE
60 HZ (50 Hz at 10% lower maximum line voltages)
4.2 KVA (Continuous) at 3.8 KVA output (90% efficiency)
PI-800 GEN2 OUTPUT CURRENT & OVERLOAD CAPABILITIES:
4.2V (S/P) 8.4 V
(Ser)
800 A 400 A
1120 A 560 A
1600 A 800 A
2400 A 1200 A
3200 A 1600 A
4000 A 2000 A
5600 A * 2800 A *
8000 A * 4000 A *
**Maximum output current possible into short circuit with very low source impedance
Copyright© 1994-2021
Ovld Duty Max ON Time
*
1x 100% CONTINUOUS
1.4x 50% 15 Minutes
2x 25% 5 Minutes
3x 10% 2.5 Minutes
4x 6% 75 Seconds
5x 4% 4 Seconds
7x 2% 2 Seconds
10x 1% 0.6 Second
Ovld Duty Max ON Time
*
1x 100% CONTINUOUS
1.4x 50% 15 Minutes
2x 25% 5 Minutes
3x 10% 2.5 Minutes
4x 6% 75 Seconds
5x 4% 4 Seconds
7x 2% 2 Seconds
10x 1% 0.6 Second
Electrical Test Instruments, LLC.
Min OFF
Time
N/A
15 Minutes
15 Minutes
20 Minutes
20 Minutes
2 Minutes
2 Minutes
1 Minute
Min OFF
Time
N/A
15 Minutes
15 Minutes
20 Minutes
20 Minutes
2 Minutes
2 Minutes
1 Minute
2-7
Max Inp Curr
(@240/120)
18 / 36
25 / 50
36 / 72
50 / 100
72 / 144
90 / 180
126 *
180 *
Max Inp Curr
(@277/240/208)
16 / 18 / 21
22 / 25 / 29
31 / 36 / 42
43 / 50 / 58
62 / 72 / 83
78 / 90 / 104
109 / 126 / 146
155 / 180 / 208
All Rights Reserved
