ELITE SERIES COMMERCIAL HIGH-TRAFFIC

AC SLIDE GATE OPERATOR

LiftMaster

845 Larch Avenue

Elmhurst, IL 60126-1196

INSTALLATION MANUAL

Model SL3000U

• THIS PRODUCT IS TO BE INSTALLED AND SERVICED BY A TRAINED GATE

SYSTEMS TECHNICIAN ONLY.

• This model is for use on vehicular passage gates ONLY and not intended for

use on pedestrian passage gates.

• This model is intended for use in Class I, II, III and IV vehicular slide gate

applications.

• Visit LiftMaster.com to locate a professional installing dealer in your area.

• This gate operator is compatible with MyQ

SL3000101U

1 HP Single Phase

SL3000501U

1/2 HP Single Phase

and Security+ 2.0™ accessories.

Need help?

Do you have a question about the ELITE SL3000101U and is the answer not in the manual?

Questions and answers

Summary of Contents for Chamberlain ELITE SL3000101U

Page 1 ELITE SERIES COMMERCIAL HIGH-TRAFFIC AC SLIDE GATE OPERATOR INSTALLATION MANUAL Model SL3000U SL3000101U 1 HP Single Phase SL3000501U 1/2 HP Single Phase • THIS PRODUCT IS TO BE INSTALLED AND SERVICED BY A TRAINED GATE SYSTEMS TECHNICIAN ONLY. • This model is for use on vehicular passage gates ONLY and not intended for use on pedestrian passage gates.
Page 2 TABLE OF CONTENTS LOCKS ....................26 SAFETY SAFETY SYMBOL AND SIGNAL WORD REVIEW ........1 EXPANSION BOARD OVERVIEW USAGE CLASS ..................2 EXIT FAIL SWITCH ................27 UL325 ENTRAPMENT PROTECTION REQUIREMENTS ......2 AC FAIL SWITCH .................27 SAFETY INSTALLATION INFORMATION ..........3 ANTI TAIL SWITCH ................27 GATE CONSTRUCTION INFORMATION ..........4 QUICK CLOSE SWITCH ................27 INTRODUCTION...
Page 3 SAFETY SAFETY SYMBOL AND SIGNAL WORD REVIEW When you see these Safety Symbols and Signal Words on the following pages, they will alert you to the possibility of Serious Injury or Death if you do not comply with the warnings that accompany them. The hazard may come from something mechanical or from electric shock.
Page 4 SAFETY USAGE CLASS CLASS I – RESIDENTIAL VEHICULAR GATE OPERATOR A vehicular gate operator (or system) intended for use in garages or parking areas associated with a residence of one-to four single families. CLASS II – COMMERCIAL/GENERAL ACCESS VEHICULAR GATE OPERATOR A vehicular gate operator (or system) intended for use in a commercial location or building such as a multi-family housing unit (five or more single family units), hotel, garages, retail store, or other buildings...
Page 5 SAFETY SAFETY INSTALLATION INFORMATION Vehicular gate systems provide convenience and security. Gate The Stop and/or Reset (if provided separately) must be located in systems are comprised of many component parts. The gate the line-of-sight of the gate. Activation of the reset control shall not operator is only one component.
Page 6 SAFETY GATE CONSTRUCTION INFORMATION Vehicular gates should be installed in accordance with ASTM F2200: Standard Specification for Automated Vehicular Gate Construction. For a copy, contact ASTM directly at 610-832-9585 or www.astm.org. GENERAL REQUIREMENTS 3.1.2 All openings shall be designed, guarded, or screened from the bottom of the gate to the top of the gate or a minimum of 72 in.
Page 7 INTRODUCTION CARTON INVENTORY NOT SHOWN: Documentation Packet, Chain #41 - 30 feet, Eye Bolt Kit Key (2) Warning Signs (2) and Warranty Card Cover Operator LiftMaster Monitored Retro-Reflective Photoelectric Sensor TOOLS NEEDED • 1/2" wrench for cover screw 5/16" • 3/4" wrench for 1/2" concrete anchors •...
Page 8 INTRODUCTION OPERATOR SPECIFICATIONS This model is intended for use in vehicular slide gate applications: Usage Classification Class I, II, III, & IV Model SL3000501U 1/2 HP: 120 Vac, 6 Amps (12 Amps including accessory outlets) Main AC Supply Model SL3000101U 1 HP: 120 Vac, 12 Amps (18 Amps including accessory outlets) Accessory Power 24 Vac, 500 mA max.
Page 9 INTRODUCTION SITE PREPARATION Check the national and local building codes BEFORE installation. CONDUIT & CONCRETE PAD SAFETY Entrapment protection devices are required to protect against any Conduit must be UL approved for low and high voltage. Consider entrapment or safety conditions encountered in your gate the operator placement BEFORE installing the pad or post.
Page 10 INTRODUCTION OVERVIEW OF TYPICAL INSTALLATION IMPORTANT SAFETY INFORMATION: One or more external monitored entrapment protection sensors shall be located where the risk of entrapment or obstruction exists at either the opening or closing direction. Any gap larger than 2-1/4 inches between the gate and a fixed object such as a wall, pillar, column, or operator must be filled.
Page 11 INSTALLATION • To AVOID damaging gas, power or other underground utility lines, • DO NOT touch the heater when switch is on, heater may be hot. contact underground utility locating companies BEFORE digging more than 18 inches (46 cm) deep. TYPES OF INSTALLATIONS STANDARD INSTALLATION REAR INSTALLATION...
Page 12 INSTALLATION STEP 1 DETERMINE LOCATION FOR CONCRETE PAD AND OPERATOR Check the national and local building codes before installation. STANDARD INSTALLATION 1. The gate operator should be installed near the front roller of the gate. Lay out the concrete pad. 2.
