- Page 1 Preh Touch Commander Preh Screen Commander Operators Manual and Technical Data...
-
Page 2: Table Of Contents
General Points__________________________________________________________ 6 Contents of packing______________________________________________________ 7 Installation of Touchscreen _______________________________________________ 8 Conditions for the System _______________________________________________ 8 Cable Installation and System Settings _____________________________________ 8 On Screen Display (OSD) _______________________________________________ 9 3.3.1 Menu: BASIC SETTINGS ___________________________________________________ 10 3.3.2 Menu: IMAGE POSITION ___________________________________________________ 11 3.3.3 Menu: SYSTEM___________________________________________________________ 12 Mechanical Adjustment of the LCD Position________________________________ 13... - Page 3 Pict. 2: rear view audio cable (with models with loudspeaker only) Pict. 3: view from below LC-Display (12,1”) with touch interface or monitor glass swing direction loudspeaker (optional) ON/OFF switch Volume regulator (with models with loudspeaker only) VGA connector...
- Page 4 Up Button Down Button Select Button Swing Direction Pict. 5: rear view Pict. 6: view from below LC-Display (12,1”) with touch interface or monitor glass Swing Direction Smart Card Reader (Optional) Magnetic Card Reader (Optional) Base Cover Module VGA Connector...
- Page 5 Pict. 8: rear view I Pict. 9: rear view II (bracketry) Exit Button Up Button Down Button Select Button LC-Display (12,1”) with touch surface or monitor glass VGA connector (15 pol.) Power Supply (jack bush) serial connector RS 232 (Touch Controller) Bracketry...
-
Page 6: General Points
A normal mouse can be used parallel to the Touch Commander. The Preh Screen Commander is without a touch surface. Instead of this you will have a monitor glass. In this case you do not have a touch function on the screen. You will have a high quality TFT monitor. -
Page 7: Contents Of Packing
Smart Card reader into the cover module is provided for. The Preh Touch Commander/Preh Screen Commander can also be used with optional bracketry for wall mount or pole mount hardware. Pict. 10: Example for adjustable Pict. -
Page 8: Installation Of Touchscreen
Installation of Touchscreen Please read the following indications prior to starting work with the Preh Touch Commander/Preh Screen Commander! The following steps are necessary for a correct function of the device: 1 Adjust computer and switch it off, connect Touch Commander/Screen Commander, switch on computer and Touch Commander/Screen Commander (see chapter 3.2). -
Page 9: On Screen Display (Osd)
If the SVGA cable between touchscreen/TFT monitor and computer is disconnected, the LED lights up red. On Screen Display (OSD) For setting the LC Display you find 4 keys on the right-hand side of the housing (see pict. 4). The On Screen Display can be initiated with either of the 4 keys. First of all the main menu appears. -
Page 10: 3.3.1 Menu: Basic Settings
BASIC SETTINGS. For this fine adjustment you should use either picture "Shutdown Windows“, a test picture or a monitor test program. In the file: \Touch\Montest (CD Rom) you will find a monitor test program for the different operating systems. -
Page 11: 3.3.2 Menu: Image Position
CONTRAST With the keys UP and DOWN the contrast of the picture can be increased or decreased. COLOR CONTROL In this sub-menu the saturation of each of the three main colour parts of the picture can be adjusted individually. Consequently the colour tone can be adapted to the individual preference of colour on part of the user. -
Page 12: Menu: System
HORIZONTAL POSITION With this menu point the picture can be moved by using keys UP (right) and DOWN (left). HORIZONTAL SIZE With this menu point the picture can be made wider or narrower by using keys UP and DOWN. On false adjustment of this parameter vertical stripes may appear in the picture. VERTICAL POSITION With this menu point the picture can be moved upwards and downwards by using keys UP and DOWN. -
Page 13: Mechanical Adjustment Of The Lcd Position
The adjustment (tilting or swinging) of the touchscreen/TFT monitor depends on your used pole or wall mount hardware. The LCD of the Preh Touch Commander is swinging and tiltable. According to the usage the LCD position can be changed. -
Page 14: Driver Installation
Driver for EloTouch Touchscreens Important Note: Integrated in the Preh Touch Commander there is the serial Accu Touch Controller E271-2210 (Controller model Smart Set 2xx0). It is firmly adjusted to 9600 Bps. Normally this is clearly recognised by the setup programs. If, however, it is not clearly recognised, the adjustment can be done by hand or be restarting the corresponding setup program. -
Page 15: Care
General Points Attention: The Preh Touch Commander/Preh Screen Commander does not contain any electronical components which can be replaced or repaired by the user. Consequently you should not try to do your own repair work. Moreover, you would lose all warranty claims for this product. -
Page 16: Troubleshooting List
Fault LED on touchscreen/ TFT monitor remains dark LED on touchscreen/ TFT monitor lights up red and no picture appears The display shows only part of the picture or the picture is distorted... -
Page 17: Additional Help
Additional help If you have problems with the connection and the installation of the Preh Touch Commander, please contact your dealer. You will get our service under the following numbers: Email: support@preh.com fax: +49 (9771) 92-152 Technical Data Electronics: Following values are valid for the model with integrated power supply only:... - Page 18 Touch: resistive Interface: Technology: Resolution: Surface: Transmition: Controller: Durability capacitive Interface: Technology: Resolution: Surface: Transmition: Controller: Durability ESD and EMV behaviour: CE-sign (see also chapter Statement of confermation) Perturbing radiation: Resistance to jamming: Durability mechanical bearing parts: Tilting and swinging Environmental conditions: Operating temperature: Storing temperature:...
-
Page 19: Safety Instructions
This applies especially to unprofessional repair and maintenance jobs. Any claims for damages against the Preh works – no matter for which legal reason – are excluded if no intention and gross negligence can be proved. Above limitation do not apply to claims for damages out of the product liability law. -
Page 20: Statement Of Confirmation
This is to certify that statements of confirmation are available for all different types of the Preh Touch Commander and the Preh Screen Commander. Of course, you can order them from Preh stating the exact type description (see type label on the bottom of the device).
