Single channel of mic/line acoustic echo cancellation (AEC), noise cancellation (NC), and automatic gain control (AGC).
•
48 VDC phantom power on microphone input, software selectable.
•
2 line level inputs with adjustable input level.
•
40 dB/second convergence rate on each AEC channel.
•
270 msec tail time.
•
20dB headroom on all channels.
•
3 line level outputs (0dBu nominal level), user adjustable.
•
Polycom patented noise cancellation algorithms remove steady-state noise signals on mic/line input (and on telephone line
output in Vortex EF2211); user adjustable up to 15 dB of noise reduction.
•
5-band parametric filters for input and output equalization on each of the inputs and outputs.
•
Digitally controlled analog trim pots on A/D inputs for precise input level adjustment.
•
24-bit codecs, 32-bit floating-point processing.
• 48kHz sample rate ⇒ 22 kHz bandwidth on all channels.
•
RS-232 for interface to control systems and Conference Composer software.
•
24 configurable logic input pins and 20 configurable logic output status pins.
•
High speed, low-delay EF expansion bus links up to 8 Vortex devices with 4 channels per device plus AEC reference.
•
32 user presets, 16 factory presets, 256 macros (each up to 256 commands).
•
Conference Composer software for easy configuration, project management, and project documentation.
•
InstantDesigner setup wizard reduces configuration time from hours to minutes – its capabilities will amaze you!
•
Front panel LCD for controlling and configuring the product without a computer.
•
Internal signal generator for noise masking applications and calibration.
