Figure 14. The matrix worksheet including the full matrix and the EF Bus sub matrix. You can use this matrix to design your input and output
mappings. Inputs to the main matrix are on the left and outputs are on the top. Inputs to the sub-matrices (PB0, ..., PB7, WB0, ..., WB7, ...) are
from the Vortex with device ID 0, ..., 7, respectively.
