Page 1 FIAT 500 ABARTH ® 2 0 1 8 O W N E R ’ S M A N U A L A N D A B A R T H C A B R I O...
Page 2 VEHICLES SOLD IN CANADA This manual illustrates and describes the operation of With respect to any Vehicles Sold in Canada, the name features and equipment that are either standard or op- FCA US LLC shall be deemed to be deleted and the name tional on this vehicle.
Page 3 TABLE OF CONTENTS SECTION PAGE INTRODUCTION ..............3 GRAPHICAL TABLE OF CONTENTS .
Page 5 INTRODUCTION CONTENTS INTRODUCTION ......4 WARNINGS AND CAUTIONS ....5 HOW TO USE THIS MANUAL .
Page 6 4 INTRODUCTION INTRODUCTION This Owner’s Manual describes all versions of this vehicle. Options and equipment dedicated to specific markets or Dear Customer, versions are not expressly indicated in the text. Therefore, Congratulations on selecting your new vehicle. Be assured you should only consider the information which is related that it represents precision workmanship, distinctive styl- to the trim level, engine, and version that you have ing, and high quality.
Page 7 INTRODUCTION HOW TO USE THIS MANUAL WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against oper- Essential Information ating procedures that could result in a collision, bodily Consult the Table of Contents to determine which section injury and/or death. It also contains CAUTIONS against contains the information you desire.
Page 9 GRAPHICAL TABLE OF CONTENTS CONTENTS FRONT VIEW ......8 INSTRUMENT PANEL .....10 REAR VIEW .
Page 10: Front View
8 GRAPHICAL TABLE OF CONTENTS FRONT VIEW Front View 1 — Exterior Mirrors 3 — Hood / Engine Compartment 2 — Windshield 4 — Headlights...
Page 11: Rear View
GRAPHICAL TABLE OF CONTENTS 9 REAR VIEW Rear View 1 — Rear Lights 2 — Rear Windshield Wiper 3 — Liftgate...
Page 12: Instrument Panel
10 GRAPHICAL TABLE OF CONTENTS INSTRUMENT PANEL Instrument Panel 1 — Air Vents 4 — Uconnect System 2 — Uconnect Phone Controls 5 — Climate Controls 3 — Instrument Cluster...
Page 13: Interior
GRAPHICAL TABLE OF CONTENTS 11 INTERIOR Interior 1 — Steering Wheel 3 — Seats 2 — Glove Compartment 4 — Gear Selector...
Page 15: Table Of Contents
GETTING TO KNOW YOUR VEHICLE CONTENTS KEYS ....... . .16 DOORS .
Page 16 14 GETTING TO KNOW YOUR VEHICLE ▫ Automatic Dimming Mirror — If Equipped ..35 ▫ Interior Light Timing (Center Position) ..41 ▫ Power Mirrors ......36 ▫...
Page 17 GETTING TO KNOW YOUR VEHICLE 15 ▫ To Open ......59 HOOD ....... .64 ▫...
Page 18: Keys
16 GETTING TO KNOW YOUR VEHICLE KEYS NOTE: The authorized dealer that sold you your vehicle has the key code numbers for your vehicle locks. These Key With Remote Control numbers can be used to order duplicate keys from your The Remote Keyless Entry (RKE) key fob contains an authorized dealer.
Page 19 GETTING TO KNOW YOUR VEHICLE 17 WARNING! Failure to follow these warnings can result in injuries that are serious or fatal to you, your passengers, and others around you: • Before operating the power top, make sure that no moving parts of the convertible top can injure a person or animal.
Page 20 18 GETTING TO KNOW YOUR VEHICLE Replacing The Battery In The Key With Remote To replace the battery, proceed as follows: Control 1. Push mechanical release button to open the mechanical key. 2. Turn the screw to unlock using a small screwdriver. 3.
Page 21: Ignition Switch
GETTING TO KNOW YOUR VEHICLE 19 Request For Additional Remote Controls IGNITION SWITCH The system can recognize up to eight remote controls. Mechanical Ignition Switch Should a new remote control be necessary, go to an The ignition switch can be turned to three different posi- authorized dealer, taking an ID document and the car tions: ownership documents.
Page 22 20 GETTING TO KNOW YOUR VEHICLE If the key is turned to the STOP position before shifting into WARNING! park, the key will have to be moved to the driving (MAR) • Before exiting a vehicle, always shift the automatic position and back to STOP.
Page 23: Key-In-Ignition Reminder
GETTING TO KNOW YOUR VEHICLE 21 If the vehicle security light is on after the key is turned to CAUTION! the MAR (ACC/ON/RUN) position, it indicates that there is a problem with the electronics. An unlocked vehicle is an invitation. Always remove the key from the ignition and lock all doors when CAUTION! leaving the vehicle unattended.
Page 24: Replacement Keys
22 GETTING TO KNOW YOUR VEHICLE Replacement Keys VEHICLE SECURITY ALARM The vehicle security alarm monitors the vehicle doors for NOTE: Only keys that have been programmed to the unauthorized entry and the ignition switch for unauthor- vehicle electronics can be used to start the vehicle. Once a ized operation.
Page 25: To Disarm The System
GETTING TO KNOW YOUR VEHICLE 23 3. The horn will sound and the vehicle security light in the To Disarm The System instrument cluster will switch on for approximately Push unlock on the key fob, or insert the key into the three seconds.
Page 26: Central Lock/Unlock (Switch Safe Lock Device) - If Equipped
24 GETTING TO KNOW YOUR VEHICLE Central Lock/Unlock (Switch Safe Lock Device) — Activating The Safe Lock Device If Equipped The Safe Lock device is enabled on all the doors by quickly This safety device prevents the operation of the interior double-pushing the lock button on the key fob.
Page 27 GETTING TO KNOW YOUR VEHICLE 25 If the lock symbol is visible when the door is shut, the door WARNING! (Continued) will lock. Therefore, make sure the key fob is not inside the • Allowing children to be in a vehicle unattended is vehicle before closing the door.
Page 28: Power Door Locks
26 GETTING TO KNOW YOUR VEHICLE Power Door Locks Auto Door Locks A power door lock switch is incorporated into the driver When enabled, the door locks will lock automatically when door handle. Push or pull the handle to lock or unlock the the vehicle’s speed exceeds 12 mph (20 km/h).
Page 29: Manual Adjustment Front Seats
GETTING TO KNOW YOUR VEHICLE 27 Manual Adjustment Front Seats While sitting in the seat, lift up on the bar and move the seat forward or rearward. Release the bar once the desired Forward/Rearward Adjustment position is reached. Then, using body pressure, move The adjusting bar is located at the front of the seats, near forward and rearward on the seat to be sure that the seat the floor.
Page 30 28 GETTING TO KNOW YOUR VEHICLE Seat Height Adjustment The driver’s seat height can be raised or lowered by using a lever, located on the outboard side of the seat. Pump the lever upward to raise the seat height, or pump the lever downward to lower the seat height.
Page 31 GETTING TO KNOW YOUR VEHICLE 29 EZ Entry Feature Memory Seat Feature The driver and front passenger seats have an EZ entry Both front seats have a memory feature, which can operate feature for rear seat passengers. Pull upward on the release in two ways: tether, located on the outboard side of the seatback, dump •...
Page 32: Heated Seats - If Equipped
30 GETTING TO KNOW YOUR VEHICLE Heated Seats — If Equipped WARNING! (Continued) On some models, the front driver and passenger seats may • Do not place anything on the seat or seatback that be equipped with heaters in both the seat cushions and insulates against heat, such as a blanket or cushion.
Page 33 GETTING TO KNOW YOUR VEHICLE 31 Rear Seat Release Buttons Folded Rear Seats WARNING! Do not pile luggage or cargo higher than the top of the seatback. This could impair visibility or become a dangerous projectile in a sudden stop or collision.
Page 34: Head Restraints
32 GETTING TO KNOW YOUR VEHICLE HEAD RESTRAINTS WARNING! • All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a crash.
Page 35: Rear Head Restraints
GETTING TO KNOW YOUR VEHICLE 33 Rear Head Restraints To raise the head restraint, pull upward on the head restraint. To lower the head restraint, push the adjustment button, located at the base of the head restraint, and push downward on the head restraint. Refer to “Occupant Restraints”...
Page 36: Steering Wheel
34 GETTING TO KNOW YOUR VEHICLE STEERING WHEEL Push down on the lever to unlock the column. With one hand firmly on the steering wheel, move the steering Tilt Steering Column — If Equipped column up or down as desired. Push the lever up to lock This feature allows you to tilt the steering column upward the column firmly in place.
Page 37: Getting To Know Your Vehicle 35
GETTING TO KNOW YOUR VEHICLE 35 Headlight glare from vehicles behind you can be reduced NOTE: This feature is disabled when the vehicle is mov- by moving the small control under the mirror to the night ing in REVERSE. position (toward the rear of the vehicle). The mirror should be adjusted while set in the day position (toward the windshield).
Page 38: Power Mirrors
36 GETTING TO KNOW YOUR VEHICLE Power Mirrors Using the mirror control switch, push on any of the four arrows for the direction that you want the mirror to move. The power mirror controls are located on the driver’s door trim panel.
Page 39: Spotter Mirror - If Equipped
GETTING TO KNOW YOUR VEHICLE 37 Spotter Mirror — If Equipped Heated Mirrors — If Equipped Some models are equipped with a driver’s side spotter mirror. The spotter mirror allows for a greater range of These mirrors are heated to melt frost or ice. This visibility on the driver’s side of the vehicle.
Page 40: Headlights
38 GETTING TO KNOW YOUR VEHICLE Headlights NOTE: The low beams and side/taillights will not be on with DRL. Rotate the end of the multifunction lever upward If allowed by law in the country in which the vehicle was to the first detent for headlight operation. purchased the DRL function can be turned on or off using the display menus.
Page 41: Follow Me Home/Headlight Delay
GETTING TO KNOW YOUR VEHICLE 39 Follow Me Home/Headlight Delay When this feature is selected, the driver can choose to have the headlights remain on for a preset period of time. Activation Remove the key or turn the ignition to the STOP (OFF/ LOCK) position, and pull the multifunction lever toward the steering wheel within two minutes.
Page 42: Turn Signals
40 GETTING TO KNOW YOUR VEHICLE Turn Signals Lane Change Assist Push the multifunction lever upward to signal a right turn Tap the lever up or down once, without moving beyond or downward to signal a left turn. The corresponding the detent, and the turn signal (right or left) will flash three indicator in the instrument cluster display will blink to times.
Page 43: Interior Light Timing (Center Position)
GETTING TO KNOW YOUR VEHICLE 41 Cargo Area Lights CAUTION! There is also a courtesy light located in the rear cargo area. Before getting out of the vehicle be sure that the switch Whenever the rear lift gate is opened, the light will turn on is in the center position or that the lights are off to and then turn off when the lift gate is closed.
Page 44: Front Windshield Wiper Operation
42 GETTING TO KNOW YOUR VEHICLE Front Windshield Wiper Operation High Speed There are four different modes of operation for the front Push the lever downward to the third detent. The wipers windshield wipers. The windshield wiper lever can be will operate at high speed.
Page 45: Rear Windshield Wiper
GETTING TO KNOW YOUR VEHICLE 43 Rear Windshield Wiper CAUTION! Rotate the end of the windshield wiper/washer lever • Turn the windshield wipers off when driving upward to the first detent past the intermittent settings for through an automatic car wash. Damage to the wind- intermittent wipe operation.
Page 46: Climate Controls
44 GETTING TO KNOW YOUR VEHICLE NOTE: The windshield wipers/washers will only operate CLIMATE CONTROLS with the ignition in the ON/RUN position. The Climate Control System allows you to regulate the Rear Windshield Washer Operation temperature, air flow, and direction of air circulating throughout the vehicle.
Page 47: Manual Climate Control Overview
GETTING TO KNOW YOUR VEHICLE 45 Manual Climate Control Overview Manual Climate Control...
Page 48 46 GETTING TO KNOW YOUR VEHICLE Manual Climate Control Descriptions Icon Description A/C Button Push the A/C button to engage the Air Conditioning (A/C). A LED will illuminate when the A/C system is engaged. Recirculation Setting Rotate this control to change the system between recirculation mode and outside air mode. Re- circulation can be used when outside air conditions such as smoke, odors, dust, or high humid- ity are present.
Page 49 GETTING TO KNOW YOUR VEHICLE 47 Icon Description Blower Control There are seven blower speeds. Use this control to regulate the amount of air forced through the system in any mode you select. The blower speed increases as you move the control clockwise from the OFF position.
Page 50 48 GETTING TO KNOW YOUR VEHICLE Icon Description Floor Mode Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.
Page 51: Automatic Temperature Control Overview
GETTING TO KNOW YOUR VEHICLE 49 Automatic Temperature Control Overview Automatic Temperature Controls...
Page 52 50 GETTING TO KNOW YOUR VEHICLE Control Descriptions Icon Description A/C Button Push and release to change the current setting, the indicator illuminates when A/C is ON. Per- forming this function again will cause the A/C operation to switch into manual mode and the A/C indicator will turn off.
Page 53 GETTING TO KNOW YOUR VEHICLE 51 Icon Description Front Defrost Button Push and release to change the current airflow setting to Defrost mode. The indicator illumi- nates when this feature is ON. Air comes from the windshield and side window demist outlets. When the defrost button is selected, the blower level will increase.
Page 54 52 GETTING TO KNOW YOUR VEHICLE Icon Description Modes Control: Push the button in the center of the knob to change the airflow distribution mode. The airflow distri- bution mode can be adjusted so air comes from the instrument panel outlets, floor outlets, defrost outlets and demist outlets.
Page 55 GETTING TO KNOW YOUR VEHICLE 53 Icon Description Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.
Page 56: Automatic Temperature Control (Atc) - If Equipped
54 GETTING TO KNOW YOUR VEHICLE Climate Control Functions Recirculation In cold weather, use of Recirculation mode may lead to A/C (Air Conditioning) excessive window fogging. The Recirculation feature may The Air Conditioning (A/C) button allows the operator to be unavailable if conditions exist that could create fogging manually activate or deactivate the air conditioning sys- on the inside of the windshield.
Page 57: Operating Tips
GETTING TO KNOW YOUR VEHICLE 55 3. When the system is set up for your comfort level, it is NOTE: The system will not automatically sense the pres- not necessary to change the settings. You experience the ence of fog, mist or ice on the windshield. Defrost mode greatest efficiency by simply allowing the system to must be manually selected to clear the windshield and side function automatically.
Page 58 56 GETTING TO KNOW YOUR VEHICLE Vacation/Storage CAUTION! (Continued) Before you store your vehicle, or keep it out of service (i.e., • Use care when washing the inside of the rear win- vacation) for two weeks or more, run the air conditioning dow.
Page 59: Windows
GETTING TO KNOW YOUR VEHICLE 57 A/C Air Filter WINDOWS The climate control system filters out dust and pollen from Power Window Controls the air. Contact an authorized dealer to service your A/C The power window controls are located on the shifter air filter, and to have it replaced when needed.
Page 60: Auto-Down
58 GETTING TO KNOW YOUR VEHICLE partially open positions. This is a normal occurrence and WARNING! can be minimized. If the buffeting occurs with the rear windows open, open the front and rear windows together Never leave children unattended in a vehicle, and do to minimize the buffeting.
Page 61: To Open
GETTING TO KNOW YOUR VEHICLE 59 open fully, then stop automatically. This is called “Express WARNING! Open”. During Express Open operation, any movement of • Never leave children alone in a vehicle, or with the sunroof switch will stop the sunroof. access to an unlocked vehicle.
Page 62: Sun Shade - If Equipped
60 GETTING TO KNOW YOUR VEHICLE Sun Shade — If Equipped Pinch Protect Feature For vehicles equipped with either a power sunroof or a This feature will detect an obstruction in the opening of the fixed glass roof, there is a sun shade that can be open or sunroof during Express Close operation.
Page 63: Power Convertible Top - If Equipped
GETTING TO KNOW YOUR VEHICLE 61 POWER CONVERTIBLE TOP — IF EQUIPPED NOTE: • The power top buttons will operate when the ignition On vehicles equipped with a power convertible top, the switch is turned to the MAR (ACC/ON/RUN) position. power convertible top switch is located on the overhead console.
Page 64: Raising The Power Top
62 GETTING TO KNOW YOUR VEHICLE NOTE: NOTE: • Vertical movement only operates in auto open/close • If the top is three-quarter of the way open, you can close mode. the top if vehicle speeds are above 50 mph (80 km/h). •...
Page 65: Power Convertible Top Relearn Procedure
GETTING TO KNOW YOUR VEHICLE 63 2. Begin with the top in the fully closed position (using CAUTION! manual mode). Failure to follow these cautions may cause interior 3. Hold the open button to move the top to the fully open water damage, stains or mildew on the top material: position.
Page 66: Wind Stop
64 GETTING TO KNOW YOUR VEHICLE Wind Stop 2. Rotate the safety catch under the front edge of the hood, near the center, and raise the hood. The Wind Stop installs in the backseat area of the vehicle. The Wind Stop will not interfere with power top operation. Therefore, it can remain installed when the top is up.
Page 67: Closing
GETTING TO KNOW YOUR VEHICLE 65 3. Lift the hood prop rod that clips to the right side (left Closing side when standing in front of the hood) of the engine compartment. Place the hood prop rod in the hole of WARNING! hood hinge to secure the hood in the open position.
Page 68: Liftgate
66 GETTING TO KNOW YOUR VEHICLE LIFTGATE WARNING! Opening • Driving with the liftgate open can allow poisonous To unlock the liftgate, use the key fob or activate the power exhaust gases into your vehicle. You and your pas- door lock switches located on the driver door handle. sengers could be injured by these fumes.
Page 69: Internal Equipment
GETTING TO KNOW YOUR VEHICLE 67 INTERNAL EQUIPMENT Cupholders Storage Front Cupholders For the driver and front passenger, cupholders are located Glove Compartment on the floor console between the front seats. The glove compartment is located on the passenger side of the instrument panel.
Page 70: Sun Visors
68 GETTING TO KNOW YOUR VEHICLE Rear Cupholders Sun Visors For rear passengers, there are cupholders located on the The driver and passenger sun visors are located on the floor between the front driver and passenger seats. headliner, near the front windshield. The sun visors can be rotated downward or up against the door glass.
Page 71: Electrical Power Outlets
GETTING TO KNOW YOUR VEHICLE 69 Electrical Power Outlets Power is available when the ignition switch is in the ON/RUN or START position. Insert the cigar lighter or There is a standard 12 Volt (13 Amp) power outlet, located accessory plug into the outlet for use. To preserve the in the floor console, for added convenience.
Page 72 70 GETTING TO KNOW YOUR VEHICLE Your vehicle is also equipped with a charge-only USB NOTE: Close the glove compartment immediately after power outlet that can be used to power cellular phones, use while driving. Injuries may occur during accidents if small electronics, and other low powered electrical acces- the glove compartment is left open.
Page 73 GETTING TO KNOW YOUR VEHICLE 71 WARNING! CAUTION! (Continued) • After the use of high power draw accessories, or long To avoid serious injury or death: periods of the vehicle not being started (with acces- • Only devices designed for use in this type of outlet sories still plugged in), the vehicle must be driven a should be inserted into any 12 Volt outlet.
Page 75 GETTING TO KNOW YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT CLUSTERS ....74 WARNING LIGHTS AND MESSAGES ..85 ▫...
Page 76: Instrument Clusters
74 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTERS Your vehicle is equipped with one of the following instru- ment clusters. Lounge Instrument Cluster Base...
Page 77 GETTING TO KNOW YOUR INSTRUMENT PANEL 75 Sport Instrument Cluster Base...
Page 78 76 GETTING TO KNOW YOUR INSTRUMENT PANEL Sport Instrument Cluster Sport Mode...
Page 79 GETTING TO KNOW YOUR INSTRUMENT PANEL 77 Sport Turbo Instrument Cluster Base...
Page 80 78 GETTING TO KNOW YOUR INSTRUMENT PANEL Sport Turbo Instrument Cluster Sport Mode...
Page 81: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL 79 Instrument Cluster Descriptions WARNING! (Continued) 1. Tachometer • A hot engine cooling system is dangerous. You or • This gauge measures engine revolutions per minute others could be badly burned by steam or boiling (RPM x 1000).
Page 82: Instrument Cluster Display
80 GETTING TO KNOW YOUR INSTRUMENT PANEL 5. Base And Sport Mode Gauge Displays NOTE: Different trips may have different values even if the same driving style is maintained. Some factors that may Depending on what options and trim level your vehicle impact the calculated index value are: may be equipped with, two gauge displays are available •...
Page 83: Instrument Cluster Display Control Buttons
GETTING TO KNOW YOUR INSTRUMENT PANEL 81 • Personal Settings (Customer Programmable Features) The steering wheel mounted controls allow you to scroll through and enter the main menus and submenus. You can • Outside Temperature Display access the specific information you want and make selec- •...
Page 84: Instrument Cluster Display Setup Menu
82 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: When opening one of the front doors, the instru- 2. Push and release the up or down arrow button (by ment cluster display will turn on the clock and the miles or single pushes) to select the new setting.
Page 85: Oil Change Reset
GETTING TO KNOW YOUR INSTRUMENT PANEL 83 Oil Change Reset Turbo Boost Gauge Your vehicle is equipped with an engine oil change indi- Your vehicle is equipped with a boost gauge and integrated cator system. The “Change Engine Oil” message will shift light indicator located to the left of the instrument appear in the instrument cluster display for approximately cluster.
Page 86: Trip Computer
84 GETTING TO KNOW YOUR INSTRUMENT PANEL • Average Fuel Economy B TRIP COMPUTER • Average Speed B The Trip Computer is located in the instrument cluster. It displays trip information such as: trip information, range, • Travel Time B (Driving Time) fuel consumption, average speed, and travel time.
Page 87: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL 85 NOTE: The range depends on several factors: driving WARNING LIGHTS AND MESSAGES style, type of route (freeway, residential, mountain roads, The warning/indicator lights will illuminate in the instru- etc.), and conditions of use of the vehicle (load, tire ment panel together with a dedicated message and/or pressure, etc.).
Page 88 86 GETTING TO KNOW YOUR INSTRUMENT PANEL — Brake Warning Light NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level conditions. This warning light monitors various brake functions, in- The vehicle should have service performed, and the brake cluding brake fluid level and parking brake application.
Page 89 GETTING TO KNOW YOUR INSTRUMENT PANEL 87 The light also will turn on when the parking brake is Steering” in “Starting And Operating” for further informa- applied with the ignition switch in the ON/RUN position. tion. NOTE: This light shows only that the parking brake is WARNING! applied.
Page 90 88 GETTING TO KNOW YOUR INSTRUMENT PANEL If the light continues to flash when the vehicle is running, — Liftgate Open Warning Light immediate service is required and you may experience This indicator will illuminate when the liftgate is open/ reduced performance, an elevated/rough idle, or engine ajar/not fully closed.
Page 91: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 89 Refer to “Occupant Restraint Systems” in “Safety” for — Electronic Stability Control (ESC) Warning further information. Light — If Equipped The “ESC Indicator Light” in the instrument cluster will — Transmission Fault Warning Light come on when the ignition is placed in the ON/RUN or This light will illuminate (together with a message in the MAR (ACC/ON/RUN) position, and when ESC is acti-...
Page 92 90 GETTING TO KNOW YOUR INSTRUMENT PANEL • This light will come on when the vehicle is in an ESC • A blown protection fuse event. • A break in the electrical connection — Electronic Stability Control (ESC) Off Warning —...
Page 93 GETTING TO KNOW YOUR INSTRUMENT PANEL 91 — Low Fuel Warning Light WARNING! When the fuel level reaches approximately 1–1.3 gal (3–5 L) A malfunctioning catalytic converter, as referenced this light will turn on, and remain on until fuel is added. above, can reach higher temperatures than in normal —...
Page 94 92 GETTING TO KNOW YOUR INSTRUMENT PANEL — Service Warning Light — If Equipped Should one or more tires be in the condition mentioned above, the display will show the indications corresponding The “Maintenance Plan” includes vehicle maintenance at to each tire. fixed intervals.
Page 95 GETTING TO KNOW YOUR INSTRUMENT PANEL 93 more of your tires is significantly under-inflated. Accord- the installation of replacement or alternate tires or wheels ingly, when the low tire pressure telltale illuminates, you on the vehicle that prevent the TPMS from functioning should stop and check your tires as soon as possible, and properly.
Page 96: Yellow Indicator Lights
94 GETTING TO KNOW YOUR INSTRUMENT PANEL — Immobilizer Vehicle Theft Alarm Warning — Rear Defrost Light Light This indicator will illuminate when the rear window This warning light will illuminate when the vehicle secu- defroster is on. The rear window defroster automatically rity alarm system has detected an attempt to break into the turns off after 20 minutes.
Page 97: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL 95 Green Indicator Lights NOTE: • A continuous chime will sound if the vehicle is driven — Cruise Control Set Indicator Light — If more than 1 mile (1.6 km) with either turn signal on. Equipped •...
Page 98: Onboard Diagnostic System - Obd Ii
96 GETTING TO KNOW YOUR INSTRUMENT PANEL ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! (Continued) Your vehicle is equipped with a sophisticated Onboard • If the MIL is flashing while the vehicle is running, Diagnostic system called OBD II. This system monitors the severe catalytic converter damage and power loss performance of the emissions, engine, and transmission will soon occur.
Page 99: Emissions Inspection And Maintenance Programs
GETTING TO KNOW YOUR INSTRUMENT PANEL 97 Normally, the OBD II system will be ready. The OBD II WARNING! (Continued) system may not be ready if your vehicle was recently • Be possible that vehicle systems, including safety serviced, recently had a dead battery or a battery replace- related systems, could be impaired or a loss of ment.
Page 100 98 GETTING TO KNOW YOUR INSTRUMENT PANEL • The MIL will not flash at all and will remain fully illuminated until you place the ignition in the off posi- tion or start the engine. This means that your vehicle’s OBD II system is ready and you can proceed to the I/M station.
Page 101 SAFETY CONTENTS ▫ Child Restraints ..... . .139 SAFETY FEATURES ..... .100 ▫...
Page 102: Safety Features
100 SAFETY SAFETY FEATURES WARNING! Four-Wheel Anti-Lock Brake System (ABS) • The ABS contains sophisticated electronic equip- The Four-Wheel ABS is designed to aid the driver in ment that may be susceptible to interference caused maintaining vehicle control under adverse braking condi- by improperly installed or high output radio trans- tions.
Page 103: Electronic Brake Control System
SAFETY Brake Assist System (BAS) WARNING! (Continued) The BAS is designed to optimize the vehicle’s braking • The capabilities of an ABS equipped vehicle must capability during emergency braking maneuvers. The sys- never be exploited in a reckless or dangerous manner tem detects an emergency braking situation by sensing the that could jeopardize the user’s safety or the safety of rate and amount of brake application and then applies...
Page 104 102 SAFETY slip differential and controls the wheel spin across a driven WARNING! axle. If one wheel on a driven axle is spinning faster than the other, the system will apply the brake of the spinning The Brake Assist System (BAS) cannot prevent the wheel.
Page 105 SAFETY HSA Activation Criteria Disabling/Enabling HSA The following criteria must be met in order for HSA to If you wish to turn the HSA system on or off, it can be done activate: using the Customer Programmable Features in the Uconnect Settings.
Page 106 104 SAFETY • Oversteer - when the vehicle is turning more than appropriate for the steering wheel position. • Understeer - when the vehicle is turning less than appropriate for the steering wheel position. ESC Off Switch (Manual Transmission) NOTE: The ESC Off switch is located left of the steering column (Manual Transmission Only).
Page 107 SAFETY ESC Operating Modes WARNING! (Continued) The ESC system has three available operating modes. hydroplaning. ESC also cannot prevent collisions resulting from loss of vehicle control due to inappro- Full On priate driver input for the conditions. Only a safe, This is the normal operating mode for ESC.
Page 108 106 SAFETY WARNING! WARNING! When in “Partial Off” mode, the TCS functionality of In the ESC “Full Off” mode, the engine torque reduc- ESC (except for the limited slip feature described in tion and stability features are cancelled. Therefore, the the TCS section) has been disabled and the “ESC Off enhanced vehicle stability offered by ESC is unavail- Indicator Light”...
Page 109: Auxiliary Driving Systems
SAFETY The ESC Activation/Malfunction Indicator Light (located AUXILIARY DRIVING SYSTEMS in the instrument cluster) starts to flash as soon as the tires Tire Pressure Monitoring System (TPMS) lose traction and the ESC system becomes active. The ESC The Tire Pressure Monitor System (TPMS) will warn the Activation/Malfunction Indicator Light also flashes when driver of a low tire pressure based on the vehicle recom- TCS is active.
Page 110 108 SAFETY The TPMS will continue to warn the driver of low tire System Warning Light will turn off only after the tires are pressure as long as the condition exists, and will not turn inflated to the vehicle’s recommended cold tire pressure off until the tire pressure is at or above the recommended value.
Page 111 SAFETY NOTE: TPM System With Comfort Cluster • The TPMS is not intended to replace normal tire care and maintenance, or to provide warning of a tire failure or This is the TPMS warning indicator located in the condition. instrument cluster. •...
Page 112 110 SAFETY • Jamming due to electronic devices or driving next to Tire Pressure Monitoring Low Pressure Warnings facilities emitting the same radio frequencies as the TPM The Tire Pressure Monitoring System Warning Light will sensors. illuminate in the instrument cluster, an audible chime will •...
Page 113 SAFETY • However, after driving the vehicle for up to 20 minutes TPM System With (TFT) Tire Pressure Display above 15 mph (24 km/h), the Tire Pressure Monitoring Screen System Warning Light will flash on and off for 75 The Tire Pressure Monitor System (TPMS) uses wireless seconds and then remain on solid and the “Service Tire technology with wheel rim mounted electronic sensors to Pressure Monitoring System”...
Page 114 112 SAFETY Tire Pressure Monitoring Low Pressure Warnings Should this occur, you should stop as soon as possible and inflate the tires with low pressure to the vehicle’s recom- mended cold placard pressure value. Once the system The Tire Pressure Monitoring System Warning Light receives the updated tire pressures, the system will auto- will illuminate in the instrument cluster and a matically update and the Tire Pressure Monitoring System...
Page 115 SAFETY 2. Installing aftermarket window tinting that contains ma- terials that may block radio wave signals. 3. Accumulation of snow or ice around the wheels or wheel housings. 4. Using tire chains on the vehicle. 5. Using wheels/tires not equipped with TPM sensors. NOTE: •...
Page 116: Occupant Restraint Systems
114 SAFETY • For each subsequent ignition switch cycle, a chime will NOTE: Changes or modifications not expressly approved sound, the Tire Pressure Monitoring System Warning by the party responsible for compliance could void the Light will flash on and off for 75 seconds and then user’s authority to operate the equipment.
Page 117 SAFETY 1. Children 12 years old and under should always ride 7. The driver and front passenger seats should be moved buckled up in the rear seat of a vehicle with a rear seat. back as far as practical to allow the front air bags room to inflate.
Page 118: Seat Belt Systems
116 SAFETY Seat Belt Systems a few seconds. If the driver or outboard front seat passen- ger (if equipped with outboard front passenger seat Buckle up even though you are an excellent driver, even on BeltAlert) is unbuckled when the ignition switch is first in short trips.
Page 119 SAFETY Change of Status Lap/Shoulder Belts All seating positions in your vehicle are equipped with If the driver or outboard front seat passenger (if equipped lap/shoulder belts. with outboard front passenger seat BeltAlert) unbuckles their seat belt while the vehicle is traveling, the BeltAlert The seat belt webbing retractor will lock only during very warning sequence will begin until the seat belts are buck- sudden stops or collisions.
Page 120 118 SAFETY WARNING! (Continued) WARNING! • It is dangerous to ride in a cargo area, inside or • A lap belt worn too high can increase the risk of outside of a vehicle. In a collision, people riding in injury in a collision. The seat belt forces won’t be at these areas are more likely to be seriously injured or the strong hip and pelvic bones, but across your killed.
Page 121 SAFETY Lap/Shoulder Belt Operating Instructions WARNING! (Continued) 1. Enter the vehicle and close the door. Sit back and adjust • A seat belt that is worn under your arm is dangerous. the seat. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck 2.
Page 122 120 SAFETY 3. When the seat belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Positioning The Lap Belt 5. Position the shoulder belt across the shoulder and chest with minimal, if any slack so that it is comfortable and Inserting Latch Plate Into Buckle not resting on your neck.
Page 123 SAFETY Lap/Shoulder Belt Untwisting Procedure position, an authorized dealer can provide you with a Seat Belt Extender. The Seat Belt Extender should be used only Use the following procedure to untwist a twisted lap/ if the existing seat belt is not long enough. When the Seat shoulder belt.
Page 124 122 SAFETY Seat Belts And Pregnant Women Seat Belt Pretensioner The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices may improve the performance of the seat belt by removing slack from the seat belt early in a collision.
Page 125 SAFETY Switchable Automatic Locking Retractor (ALR) webbing out far enough to comfortably wrap around the occupant’s mid-section so as to not activate the ALR. If the The seat belts in the passenger seating positions are ALR is activated, you will hear a clicking sound as the seat equipped with a Switchable Automatic Locking Retractor belt retracts.
Page 126: Supplemental Restraint Systems (Srs)
124 SAFETY How To Engage The Automatic Locking Mode WARNING! (Continued) 1. Buckle the combination lap and shoulder belt. • Do not use the Automatic Locking Mode to restrain occupants who are wearing the seat belt or children 2. Grasp the shoulder portion and pull downward until who are using booster seats.
Page 127 SAFETY • Steering Wheel and Column The ORC turns on the Air Bag Warning Light in the instrument panel for approximately four to eight seconds • Instrument Panel for a self-check when the ignition switch is in the MAR/ • Knee Impact Bolsters ACC/ON/RUN position.
Page 128 126 SAFETY NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint Controller (ORC) may also be disabled. In this condition the air bags may not be ready to inflate for your protection. Have an authorized dealer service the air bag system immediately.
Page 129 SAFETY This vehicle may be equipped with a driver and/or front WARNING! (Continued) passenger seat belt buckle switch that detects whether the • Never place a rear-facing child restraint in front of an driver or front passenger seat belt is buckled. The seat belt air bag.
Page 130 128 SAFETY Because air bag sensors measure vehicle deceleration over WARNING! (Continued) time, vehicle speed and damage by themselves are not • Relying on the air bags alone could lead to more good indicators of whether or not an air bag should have severe injuries in a collision.
Page 131 SAFETY The SABs may help to reduce the risk of occupant injury WARNING! during certain side impacts, in addition to the injury • Do not drill, cut, or tamper with the knee impact reduction potential provided by the seat belts and body structure.
Page 132 130 SAFETY WARNING! Do not use accessory seat covers or place objects between you and the Side Air Bags; the performance could be adversely affected and/or objects could be pushed into you, causing serious injury. Supplemental Side Air Bag Inflatable Curtains (SABICs) This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains (SABICs).
Page 133 SAFETY positioned in the area where the SABICs inflate. Children Side Impacts are at an even greater risk of injury from a deploying air The Side Air Bags are designed to activate in certain side bag. impacts. The Occupant Restraint Controller (ORC) deter- The SABICs may help reduce the risk of partial or complete mines whether the deployment of the Side Air Bags in a ejection of vehicle occupants through side windows in...
Page 134 132 SAFETY Side Air Bags are a supplement to the seat belt restraint WARNING! system. Side Air Bags deploy in less time than it takes to • Side Air Bags need room to inflate. Do not lean blink your eyes. against the door or window.
Page 135 SAFETY • Supplemental Side Air Bags The Side Air Bags will not deploy in all rollover events. The rollover sensing system determines if a rollover event may • Supplemental Knee Air Bags be in progress and whether deployment is appropriate. In •...
Page 136 134 SAFETY • As the air bags deflate, you may see some smoke-like NOTE: particles. The particles are a normal by-product of the • Air bag covers may not be obvious in the interior trim, process that generates the non-toxic gas used for air bag but they will open during air bag deployment.
Page 137 SAFETY Your vehicle may also be designed to perform any of these NOTE: After an accident, remember to cycle the ignition other functions in response to the Enhanced Accident to the STOP (OFF/LOCK) position and remove the key Response System: from the ignition switch to avoid draining the battery.
Page 138 136 SAFETY Depending on the nature of the event the left and right turn Customer Will See signal lights, located in the instrument panel, may both be NOTE: Each step MUST blinking and will continue to blink. In order to move your Customer Action BE held for at least two vehicle to the side of the road, you must follow the system...
Page 139 SAFETY Maintaining Your Air Bag System Customer Will See NOTE: Each step MUST Customer Action WARNING! BE held for at least two • Modifications to any part of the air bag system could seconds cause it to fail when you need it. You could be 12.
Page 140 138 SAFETY • How various systems in your vehicle were operating; WARNING! (Continued) • Whether or not the driver and passenger safety belts • Do not attempt to modify any part of your air bag were buckled/fastened; system. The air bag may inflate accidentally or may •...
Page 141: Child Restraints
SAFETY Child Restraints There are different sizes and types of restraints for children from newborn size to the child almost large enough for an Everyone in your vehicle needs to be buckled up at all adult safety belt. Always check the child seat Owner’s times, including babies and children.
Page 142 140 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Recommended Type Of Child Child Size, Height, Weight Or Age Restraint Infants and Toddlers Children who are two years old or Either an Infant Carrier or a Convert- younger and who have not reached ible Child Restraint, facing rearward the height or weight limits of their in the rear seat of the vehicle...
Page 143 SAFETY Infant And Child Restraints WARNING! Safety experts recommend that children ride rear-facing in • Never place a rear-facing child restraint in front of an the vehicle until they are two years old or until they reach air bag. A deploying passenger front air bag can either the height or weight limit of their rear-facing child cause death or serious injury to a child 12 years or restraint.
Page 144 142 SAFETY All children whose weight or height is above the forward- WARNING! (Continued) facing limit for the child seat should use a belt-positioning • When your child restraint is not in use, secure it in booster seat until the vehicle’s seat belts fit properly. If the the vehicle with the seat belt or LATCH anchorages, child cannot sit with knees bent over the vehicle’s seat or remove it from the vehicle.
Page 145 SAFETY 4. Is the lap part of the belt as low as possible, touching the WARNING! child’s thighs and not the stomach? Never allow a child to put the shoulder belt under an 5. Can the child stay seated like this for the whole trip? arm or behind their back.
Page 146 144 SAFETY Restraint Type Combined Use Any Attachment Method Shown With An “X” Below Weight of the LATCH – Lower Seat Belt Only LATCH – Lower Seat Belt + Top Child + Child Anchors Only Anchors + Top Tether Anchor Restraint Tether Anchor Child Restraint...
Page 147 SAFETY LATCH Positions For Installing Child Restraints In This Vehicle LATCH Positions Lower Anchorage Symbol (2 Anchorages Per Seating Position) Top Tether Anchorage Symbol Frequently Asked Questions About Installing Child Restraints With LATCH What is the weight limit (child’s weight + weight 65 lbs Use the LATCH anchorage system until the com- of the child restraint) for using the LATCH an-...
Page 148 146 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Can the LATCH anchorages and the seat belt be Do not use the seat belt when you use the LATCH used together to attach a rear-facing or forward- anchorage system to attach a rear-facing or facing child restraint? forward-facing child restraint.
Page 149 SAFETY Locating The LATCH Anchorages Locating The Upper Tether Anchorages The lower anchorages are round bars that are found at the There are tether strap anchorages behind each rear seating rear of the seat cushion where it meets the position located on the back of the seat. seatback, below the anchorage symbols on the seatback.
Page 150 148 SAFETY strap. The tether strap will have a hook at the end to attach 2. Place the child seat between the lower anchorages for to the top tether anchorage and a way to tighten the strap that seating position. For some second row seats, you after it is attached to the anchorage.
Page 151 SAFETY How To Stow An Unused Switchable-ALR (ALR) WARNING! (Continued) Seat Belt: • Child restraint anchorages are designed to withstand When using the LATCH attaching system to install a child only those loads imposed by correctly-fitted child restraint, stow all ALR seat belts that are not being used by restraints.
Page 152 150 SAFETY The seat belts in the passenger seating positions are Lap/Shoulder Belt Systems For Installing Child equipped with a Switchable Automatic Locking Retractor Restraints In This Vehicle (ALR) that is designed to keep the lap portion of the seat belt tight around the child restraint so that it is not necessary to use a locking clip.
Page 153 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to the with the seat belt to attach a forward...
Page 154 152 SAFETY 1. Place the child seat in the center of the seating position. 6. Try to pull the webbing out of the retractor. If it is For some second row seats, you may need to recline the locked, you should not be able to pull out any webbing. seat and/or raise the head restraint to get a better fit.
Page 155 SAFETY Installing Child Restraints Using The Top Tether 1. Look behind the seating position where you plan to Anchorage install the child restraint to find the tether anchorage. You may need to move the seat forward to provide WARNING! better access to the tether anchorage. If there is no top tether anchorage for that seating position, move the Do not attach a tether strap for a rear-facing car seat to child restraint to another position in the vehicle if one is...
Page 156: Transporting Pets
154 SAFETY 3. Attach the tether strap hook of the child restraint to the WARNING! top tether anchorage as shown in the diagram. • An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.
Page 157: Safety Tips
SAFETY SAFETY TIPS Exhaust Gas Transporting Passengers WARNING! NEVER TRANSPORT PASSENGERS IN THE CARGO Exhaust gases can injure or kill. They contain carbon AREA. monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can even- WARNING! tually poison you.
Page 158: Safety Checks You Should Make Inside The Vehicle
156 SAFETY Whenever a change is noticed in the sound of the exhaust Air Bag Warning Light system, when exhaust fumes can be detected inside the The Air Bag warning light will turn on for four to vehicle, or when the underside or rear of the vehicle is eight seconds as a bulb check when the ignition switch damaged, have a competent mechanic inspect the complete is first turned to ON/RUN.
Page 159 SAFETY Floor Mat Safety Information WARNING! (Continued) Always use floor mats designed to fit your vehicle. Only • ALWAYS REMOVE THE EXISTING FLOOR MAT use a floor mat that does not interfere with the operation of FROM THE VEHICLE before installing any other the accelerator, brake or clutch pedals.
Page 160: Periodic Safety Checks You Should Make Outside
158 SAFETY Periodic Safety Checks You Should Make Outside WARNING! (Continued) The Vehicle • ALWAYS make sure objects cannot fall or slide into Tires the driver’s side floor area when the vehicle is moving. Objects can become trapped under accelera- Examine tires for excessive tread wear and uneven wear tor, brake, or clutch pedals and could cause a loss of patterns.
Page 161 STARTING AND OPERATING CONTENTS ▫ Downshifting ......167 STARTING PROCEDURES ....161 ▫...
Page 162 160 STARTING AND OPERATING ▫ To Accelerate For Passing ....179 ADDING FUEL ......187 ▫...
Page 163: Starting Procedures
STARTING AND OPERATING 161 STARTING PROCEDURES Automatic Transmission Before starting your vehicle, adjust your seat, adjust both The gear selector must be in the PARK or NEUTRAL inside and outside mirrors, and fasten your seat belts. position before you can start the engine. Depress the brake pedal before shifting to any driving gear.
Page 164: Extended Park Starting
162 STARTING AND OPERATING electric engine block heater is available as optional equip- 3. If the engine fails to start within 10 to 15 seconds, cycle ment from your authorized dealer or may be standard the ignition to the OFF mode, wait five seconds to allow equipment in some markets.
Page 165: After Starting
STARTING AND OPERATING 163 ENGINE BREAK-IN RECOMMENDATIONS CAUTION! A long break-in period is not required for the engine and • Do not attempt to push or tow your vehicle to get it drivetrain (transmission and axle) in your vehicle. started. Vehicles equipped with an automatic trans- Drive moderately during the first 300 miles (500 km).
Page 166: Parking Brake
164 STARTING AND OPERATING NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as a problem. PARKING BRAKE Before leaving the vehicle, make sure that the parking brake is fully applied.
Page 167: Manual Transmission - If Equipped
STARTING AND OPERATING 165 WARNING! CAUTION! • Never leave children alone in a vehicle, or with If the Brake Warning Light remains on with the park- access to an unlocked vehicle. ing brake released, a brake system malfunction is • Allowing children to be in a vehicle unattended is indicated.
Page 168: Recommended Shift Speeds
166 STARTING AND OPERATING Never drive with your foot resting on the clutch pedal, and never try to hold the vehicle on a hill with the clutch pedal partially engaged. This will cause abnormal wear on the clutch. Never shift into REVERSE until the vehicle has come to a complete stop.
Page 169: Downshifting
STARTING AND OPERATING 167 Downshifting AUTOMATIC TRANSMISSION — IF EQUIPPED Proper downshifting will improve fuel economy and pro- WARNING! long engine life. • It is dangerous to shift out of PARK or NEUTRAL if CAUTION! the engine speed is higher than idle speed. If your foot is not firmly pressing the brake pedal, the If you skip a gear while downshifting or downshift at vehicle could accelerate quickly forward or in re-...
Page 170: Key Ignition Park Interlock
168 STARTING AND OPERATING NOTE: You must press and hold the brake pedal while WARNING! (Continued) shifting out of PARK. • Never leave children alone in a vehicle, or with Key Ignition Park Interlock access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number This vehicle is equipped with a Key Ignition Park Interlock of reasons.
Page 171: Gear Ranges
STARTING AND OPERATING 169 The electronically-controlled transmission adapts its shift The transmission gear selector provides PARK, REVERSE, schedule based on driver inputs, along with environmental NEUTRAL, DRIVE, and AutoStick (+/–) shift positions. and road conditions. The transmission electronics are self- Manual shifts can be made using the AutoStick shift calibrating;...
Page 172 170 STARTING AND OPERATING PARK (P) WARNING! This range supplements the parking brake by locking the • Never use the PARK position as a substitute for the transmission. The engine can be started in this range. parking brake. Always apply the parking brake fully Never attempt to use PARK while the vehicle is in motion.
Page 173 STARTING AND OPERATING 171 WARNING! (Continued) CAUTION! • Unintended movement of a vehicle could injure • Before moving the transmission gear selector out of those in or near the vehicle. As with all vehicles, you PARK, you must turn the ignition to the ON/RUN should never exit a vehicle while the engine is mode, and also press the brake pedal.
Page 174 172 STARTING AND OPERATING REVERSE (R) CAUTION! (Continued) This range is for moving the vehicle backward. Shift into Towing” in “Starting And Operating” and “Towing A REVERSE only after the vehicle has come to a complete Disabled Vehicle” in “In Case Of Emergency” for stop.
Page 175 STARTING AND OPERATING 173 If the transmission temperature exceeds normal operating In the event of a momentary problem, the transmission can limits, the transmission controller will expand the range of be reset to regain all forward gears by performing the torque converter clutch engagement.
Page 176: Autostick
174 STARTING AND OPERATING • The transmission will automatically downshift as the AUTOSTICK vehicle slows (to prevent engine lugging) and will AutoStick is a driver-interactive transmission feature pro- display the current gear. viding manual shift control, giving you more control of the •...
Page 177: Sport Mode
STARTING AND OPERATING 175 To disengage AutoStick mode, return the gear selector to the DRIVE position. You can shift in or out of the AutoStick position at any time without taking your foot off the accelerator pedal. WARNING! Do not downshift for additional engine braking on a slippery surface.
Page 178: Power Steering
176 STARTING AND OPERATING Automatic Transmission — If Equipped WARNING! 1. Push the SPORT button, located above the climate Continued operation with reduced or no power steer- controls to activate SPORT mode. ing assist could pose a safety risk to yourself and NOTE: others.
Page 179: Speed Control
STARTING AND OPERATING 177 NOTE: • Even if the power steering assistance is no longer operational, it is still possible to steer the vehicle. Under these conditions there will be a substantial increase in steering effort, especially at low speeds and during parking maneuvers.
Page 180: To Activate
178 STARTING AND OPERATING To Activate To Vary The Speed Setting Push the ON/OFF button. The Cruise Indicator Light in To Increase Speed the instrument cluster display will illuminate. To turn the When the Speed Control is set, you can increase speed by system off, push the ON/OFF button a second time.
Page 181: To Accelerate For Passing
STARTING AND OPERATING 179 • If the button is continually pushed, the set speed will • If the button is continually pushed, the set speed will continue to increase until the button is released, then the continue to decrease until the button is released, then the new set speed will be established.
Page 182: To Resume Speed
180 STARTING AND OPERATING To Resume Speed Rear Park Assist Sensors To resume a previously set speed, push the RES (+) button The four Rear Park Assist sensors, located in the rear and release. Resume can be used at any speed above fascia/bumper, monitor the area behind the vehicle that is 25 mph (40 km/h).
Page 183: Rear Park Assist Display
STARTING AND OPERATING 181 Rear Park Assist Display right rear region and will produce an audible alert. As the vehicle moves closer to the obstacle, the display will show When the vehicle is in REVERSE, the warning display will fewer arcs and the audible alert becomes more frequent. turn ON indicating the system status.
Page 184 182 STARTING AND OPERATING Audible And Visual Signals Supplied By The Rear Park Assist System SIGNAL MEANING INDICATION Obstacle Distance An obstacle is present within the Audible Signal (dashboard loud- sensors’ field of view speaker) • Sound pulses emitted at a rate that increases as the distance decreases.
Page 185: Failure Indications
STARTING AND OPERATING 183 While audible signals are emitted, the audio system is not Even if the system is able to identify that a specific sensor muted. is in failure condition, the instrument cluster display shall indicate that the Rear Park Assist system is unavailable, The audible signal is turned off immediately if the distance without reference to the sensor in failure condition.
Page 186 184 STARTING AND OPERATING • Clean the Rear Park Assist sensors regularly, taking care WARNING! (Continued) not to scratch or damage them. The sensors must not be • Before using ParkSense, it is strongly recommended covered with ice, snow, slush, mud, dirt or debris. that the ball mount and hitch ball assembly is Failure to do so can result in the system not working disconnected from the vehicle when the vehicle is...
Page 187: Parkview Rear Back Up Camera
STARTING AND OPERATING 185 If your vehicle is equipped with the Camera Delay feature CAUTION! (Continued) and it is turned on, the rear camera image will be displayed • The vehicle must be driven slowly when using for up to ten seconds after the vehicle is shifted out of ParkSense in order to be able to stop in time when an REVERSE unless one of the following conditions occurs: obstacle is detected.
Page 188 186 STARTING AND OPERATING The following table shows the approximate distances for each zone: Zone Distance To The Rear Of The Vehicle 0 - 1 ft (0 - 30 cm) Yellow 1 ft - 3 ft (30 cm - 1 m) Green 3 ft or greater (1 m or greater) WARNING!
Page 189: Adding Fuel
STARTING AND OPERATING 187 ADDING FUEL WARNING! Fuel Filler Cap (Gas Cap) • Never have any smoking materials lit in or near the The gas cap is located on the passenger side of the vehicle. vehicle when the gas cap is removed or the tank is If the gas cap is lost or damaged, be sure the replacement being filled.
Page 190: Loose Fuel Filler Cap Message
188 STARTING AND OPERATING NOTE: VEHICLE LOADING • When the fuel nozzle “clicks” or shuts off, the fuel tank Certification Label is full. As required by National Highway Traffic Safety Adminis- • Tighten the gas cap about 1/4 turn until you hear one tration regulations, your vehicle has a certification label click.
Page 191 STARTING AND OPERATING 189 Gross Axle Weight Rating (GAWR) Curb Weight The GAWR is the maximum permissible load on the front The curb weight of a vehicle is defined as the total weight and rear axles. The load must be distributed in the cargo of the vehicle with all fluids, including vehicle fuel, at full area so that the GAWR of each axle is not exceeded.
Page 192: Trailer Towing
190 STARTING AND OPERATING Improper weight distributions can have an adverse effect CAUTION! (Continued) on the way your vehicle steers and handles and the way on your vehicle can break, or it can change the way the brakes operate. your vehicle handles. This could cause you to lose control.
Page 193: Driving Tips
STARTING AND OPERATING 191 This vehicle may also be towed using a tow dolly (with the Acceleration front wheels OFF the ground). Rapid acceleration on snow covered, wet, or other slippery Vehicles equipped with manual transmissions may be flat surfaces may cause the driving wheels to pull erratically to towed (with all four wheels on the ground) speeds up to the right or left.
Page 194: Driving Through Water
192 STARTING AND OPERATING • Slow down if the road has standing water or puddles. Shallow Standing Water • Replace the tires when tread wear indicators first be- Although your vehicle is capable of driving through shal- come visible. low standing water, consider the following Cautions and •...
Page 195 STARTING AND OPERATING 193 CAUTION! • Always check the depth of the standing water before driving through it. Never drive through standing water that is deeper than the bottom of the tire rims mounted on the vehicle. • Determine the condition of the road or the path that is under water and if there are any obstacles in the way before driving through the standing water.
Page 197 IN CASE OF EMERGENCY CONTENTS HAZARD WARNING FLASHERS ... .197 TIRE SERVICE KIT — IF EQUIPPED ..213 ▫ Tire Service Kit Storage....213 BULB REPLACEMENT .
Page 198 196 IN CASE OF EMERGENCY ▫ Manual Transmission ....227 EVENT DATA RECORDER (EDR) ... .228 ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) .
Page 199: Hazard Warning Flashers
IN CASE OF EMERGENCY 197 HAZARD WARNING FLASHERS Do not use this emergency warning system when the vehicle is in motion. Use it when your vehicle is disabled The Hazard Warning flasher switch is located on the and it is creating a safety hazard for other motorists. instrument panel below the radio.
Page 200: Replacing Exterior Bulbs
198 IN CASE OF EMERGENCY Exterior Bulbs Bulb Number Front Low and High Beam Headlamp HIR2LL Front Parking/Daytime Running Lamps W21/5W Front Fog Lamps H11LL Front Side Marker Lamps Front Turn Signal Lamps WY21W Side Direction Lamps WY5W Rear Turn Signal Lamps PY21W Rear Side Marker Lamps Rear Tail and Stop Lamps...
Page 201 IN CASE OF EMERGENCY 199 Front Turn Signal, Parking And Daytime Running 5. Remove the bulb and replace as needed. Lamps 6. Install the bulb into socket, and rotate bulb/socket 1. Turn the steering wheel completely to the left or right. clockwise into lamp locking it in place.
Page 202: Replacing Interior Bulbs
200 IN CASE OF EMERGENCY Rear Tail, Stop, Backup And Turn Signal Lamps 6. Replace lamps as required and reinstall lamp. 1. Open the liftgate. Replacing Interior Bulbs 2. Remove the two screws and remove the tail lamp Rear Cargo Lamp assembly.
Page 203: Interior Fuses
IN CASE OF EMERGENCY 201 WARNING! (Continued) • If the replaced fuse blows again, contact an autho- rized dealer. • If a general protection fuse for safety systems (air bag system, braking system), power unit systems (engine system, transmission system) or steering system blows, contact an authorized dealer.
Page 204 202 IN CASE OF EMERGENCY Vehicle Fuse Cavity Mini Fuse Description Number 10 Amp Red Diagnostic Socket, Vehicle Radio, Climate Control System 20 Amp Yellow Bi-Directional Washer 20 Amp Yellow Passenger Power Window 7.5 Amp Brown Left Low Beam, Headlamp Leveling 7.5 Amp Brown Airbag 5 Amp Tan...
Page 205: Underhood Fuses
IN CASE OF EMERGENCY 203 Underhood Fuses The ID number of the electrical component corresponding to each fuse can be found on the back of the cover. The Front Distribution Unit is located on the right side of the engine compartment, next to the battery. To access the fuses, press the release tabs and remove the cover.
Page 206 204 IN CASE OF EMERGENCY Cavity Maxi Fuse Mini Fuse Description 20 Amp Yellow – Radiator Fan - Single Speed 30 Amp Green – Radiator Fan - Low Speed 40 Amp Orange – Radiator Fan - High Speed 40 Amp Orange –...
Page 207: Tire Service Kit - If Equipped
IN CASE OF EMERGENCY 205 Cavity Maxi Fuse Mini Fuse Description – 7.5 Amp Brown Stability Control System – 15 Amp Blue Fog Lamps 30 Amp Green – Sunroof/Convertible Top 20 Amp Yellow – Cooling Pump – If Equipped – 10 Amp Red Transmission 30 Amp Green...
Page 208: Tire Service Kit Components And Operation
206 IN CASE OF EMERGENCY Tire Service Kit Components And Operation Selecting Air Mode Push in the Mode Select Knob (5) and turn to this position for air pump operation only. Use the Black Air Pump Hose (7) when selecting this mode. Selecting Sealant Mode Push in the Mode Select Knob (5) and turn to this position to inject the Tire Service Kit Sealant and to...
Page 209 IN CASE OF EMERGENCY 207 • For optimum performance, make sure the valve stem on the wheel is free of debris before connecting the Tire Service Kit. • You can use the Tire Service Kit air pump to inflate bicycle tires. The kit also comes with two needles, located in the Accessory Storage Compartment (on the bottom of the air pump) for inflating sport balls, rafts, or similar inflatable items.
Page 210: Sealing A Tire With Tire Service Kit
208 IN CASE OF EMERGENCY WARNING! (Continued) WARNING! (Continued) • Do not use Tire Service Kit or drive the vehicle under • Take care not to allow the contents of Tire Service Kit the following circumstances: to come in contact with hair, eyes, or clothing. Tire Service Kit sealant is harmful if inhaled, swallowed, –...
Page 211 IN CASE OF EMERGENCY 209 2. Verify that the valve stem (on the wheel with the 5. Uncoil the Power Plug (8) and insert the plug into the deflated tire) is in a position that is near to the ground. vehicle’s 12 Volt power outlet.
Page 212 210 IN CASE OF EMERGENCY Select Knob (5) is in the Sealant Mode position and not 2. The pump will start to inject air into the tire immedi- Air Mode. Push the Power Button (4) to turn On the Tire ately after the Sealant Bottle (1) is empty.
Page 213 IN CASE OF EMERGENCY 211 3. Immediately disconnect the Sealant Hose (6) from the WARNING! valve stem, reinstall the cap on the fitting at the end of the hose, and place the Tire Service Kit in the vehicle Tire Service Kit is not a permanent flat tire repair. Have storage location.
Page 214 212 IN CASE OF EMERGENCY If tire pressure is less than 19 psi (1.3 Bar): 6. Replace the Sealant Bottle (1) and Sealant Hose (6) assembly at an authorized dealer as soon as possible. The tire is too badly damaged. Do not attempt to drive the Refer to “(F) Sealant Bottle And Hose Replacement”.
Page 215: Tire Service Kit - If Equipped
IN CASE OF EMERGENCY 213 6. Verify that the cap is installed on the fitting at the end of Tire Service Kit Components And Operation the Sealant Hose (6) and return the hose to its storage area (located on the bottom of the air pump). 7.
Page 216: Tire Service Kit Usage Precautions
214 IN CASE OF EMERGENCY Using The Mode Select Knob And Hoses Using The Deflation Button Your Tire Service Kit is equipped with the following Push the Deflation Button (9) to reduce the air symbols to indicate the air or sealant mode. pressure in the tire if it becomes over-inflated.
Page 217 IN CASE OF EMERGENCY 215 • The Sealant Bottle (4) and Sealant Hose (3) are a one tire • Do not lift or carry the Tire Service Kit by the hoses. application use and need to be replaced after each use. Always replace these components immediately at your WARNING! original equipment vehicle dealer.
Page 218: Sealing A Tire With Tire Service Kit
216 IN CASE OF EMERGENCY Sealing A Tire With Tire Service Kit WARNING! (Continued) • A loose Tire Service Kit thrown forward in a collision (A) Whenever You Stop To Use Tire Service Kit: or hard stop could endanger the occupants of the 1.
Page 219 IN CASE OF EMERGENCY 217 3. Place the Tire Service Kit flat on the ground next to the If the sealant (white fluid) does not flow within 0 – 10 deflated tire. seconds through the Sealant Hose (3): 4. Remove the cap from the valve stem and then screw the 1.
Page 220 218 IN CASE OF EMERGENCY If the sealant (white fluid) does flow through the Sealant If the tire inflates to the recommended pressure or is at Hose (3): least 26 psi (1.8 Bar) pressure within 15 minutes: 1. Continue to operate the pump until sealant is no longer 1.
Page 221 IN CASE OF EMERGENCY 219 (D) Drive Vehicle: 4. Check the pressure in the tire by reading the Pressure Gauge (8). Immediately after injecting sealant and inflating the tire, drive the vehicle 5 miles (8 km) or ten minutes to ensure If tire pressure is less than 19 psi (1.3 Bar): distribution of the Tire Service Kit Sealant within the tire.
Page 222: Jump Starting Procedure
220 IN CASE OF EMERGENCY 5. Remove the Speed Limit sticker from the instrument the button. An audible click will be heard indicating the panel after the tire has been repaired. bottle is locked into place. Release the button. 6. Replace the Sealant Bottle (4) and Sealant Hose (3) 6.
Page 223: Preparations For Jump Start
IN CASE OF EMERGENCY 221 CAUTION! WARNING! • Take care to avoid the radiator cooling fan whenever Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 the hood is raised. It can start anytime the ignition Volts or damage to the battery, starter motor, alternator switch is ON.
Page 224: Jump Starting Procedure
222 IN CASE OF EMERGENCY 3. Connect the negative end (-) of the jumper cable to the WARNING! negative (-) post of the booster battery. Do not allow vehicles to touch each other as this could 4. Connect the opposite end of the negative (-) jumper establish a ground connection and personal injury cable to a good engine ground (exposed metal part of could result.
Page 225: Gear Selector Override
IN CASE OF EMERGENCY 223 2. Disconnect the negative end (-) of the jumper cable from 1. Turn the engine OFF. the negative (-) post of the booster battery. 2. Firmly apply the parking brake. 3. Disconnect the opposite end of the positive (+) jumper 3.
Page 226: If Your Engine Overheats
224 IN CASE OF EMERGENCY 7. The vehicle may then be started in NEUTRAL. WARNING! 8. Reinstall the gear selector override access cover. You or others can be badly burned by hot engine coolant (antifreeze) or steam from your radiator. If you IF YOUR ENGINE OVERHEATS see or hear steam coming from under the hood, do not In any of the following situations, you can reduce the...
Page 227: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY 225 FREEING A STUCK VEHICLE WARNING! (Continued) If your vehicle becomes stuck in mud, sand or snow, it can faster than 30 mph (48 km/h) or for longer than 30 often be moved using a rocking motion. Turn the steering seconds continuously without stopping when you are wheel right and left to clear the area around the front stuck and do not let anyone near a spinning wheel, no...
Page 228: Towing A Disabled Vehicle
226 IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF The Ground Automatic Transmission Manual Transmission Flat Tow NONE NOT ALLOWED If transmission is operable: •...
Page 229: Automatic Transmission
IN CASE OF EMERGENCY 227 CAUTION! CAUTION! (Continued) • Towing this vehicle in violation of the above require- • Do not use sling type equipment when towing. ments can cause severe transmission damage. Dam- Vehicle damage may occur. age from improper towing is not covered under the •...
Page 230 228 IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM (EARS) This vehicle is equipped with an Enhanced Accident Response System. Please refer to “Occupant Restraint Systems” in “Safety” for further information on the Enhanced Accident Re- sponse System (EARS) function. EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR).
Page 231 SERVICING AND MAINTENANCE CONTENTS ▫ Cooling System ......248 SCHEDULED SERVICING ....231 ▫...
Page 232 230 SERVICING AND MAINTENANCE ▫ Preserving The Bodywork ....277 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES ....274 INTERIORS .
Page 233: Scheduled Servicing
SERVICING AND MAINTENANCE 231 SCHEDULED SERVICING Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a Your vehicle is equipped with an automatic oil change scheduled oil change is performed by someone other than indicator system.
Page 234: Maintenance Plan
232 SERVICING AND MAINTENANCE Once A Month Or Before A Long Trip: At Every Oil Change Interval As Indicated By Oil Change Indicator System: Check engine oil level. Change oil and filter. Check windshield washer fluid level. Rotate the tires. Rotate at the first sign of irregular Check the tire inflation pressures and look for unusual wear, even if it occurs before the oil indicator system wear or damage.
Page 235 SERVICING AND MAINTENANCE 233 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary. Inspect brake linings, replace if needed. Inspect parking brake function, adjust as necessary. Additional Maintenance Replace cabin/air conditioning filter.
Page 236 234 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Inspect and replace PCV valve if necessary. Replace accessory drive belt and tensioner. Replace the timing belt. ** The spark plug change interval is mileage based only, WARNING! (Continued) yearly intervals do not apply.
Page 237: Engine Compartment - 1.4L Turbo
SERVICING AND MAINTENANCE 235 ENGINE COMPARTMENT — 1.4L TURBO 1 — Engine Coolant Reservoir Pressure Cap 6 — Air Cleaner Filter 2 — Engine Oil Dipstick 7 — Engine Oil Fill 3 — Brake Fluid Reservoir 8 — Engine Coolant Reservoir 4 —...
Page 238: Checking Oil Level
236 SERVICING AND MAINTENANCE Checking Oil Level CAUTION! To assure proper engine lubrication, the engine oil must be Overfilling or underfilling the crankcase will cause maintained at the correct level. Check the oil level at aeration or loss of oil pressure. This could damage your regular intervals, such as every fuel stop.
Page 239: Maintenance-Free Battery
SERVICING AND MAINTENANCE 237 Maintenance-Free Battery WARNING! (Continued) Your vehicle is equipped with a maintenance-free battery. • The battery in this vehicle has a vent hose that You will never have to add water, nor is periodic mainte- should not be disconnected and should only be nance required.
Page 240: Dealer Service
238 SERVICING AND MAINTENANCE DEALER SERVICE NOTE: Under no circumstances should oil change inter- vals exceed 10,000 miles (16,000 km), twelve months or 350 An authorized dealer has the qualified service personnel, hours of engine run time, whichever comes first. The 350 special tools, and equipment to perform all service opera- hours of engine run or idle time is generally only a concern tions in an expert manner.
Page 241: Engine Oil Filter
SERVICING AND MAINTENANCE 239 Synthetic engine oils which do not have both the engine oil CAUTION! certification mark and the correct SAE viscosity grade number should not be used. Do not use chemical flushes in your engine oil as the chemicals can damage your engine.
Page 242: Engine Air Cleaner Filter
240 SERVICING AND MAINTENANCE Engine Oil Filter Selection Engine Air Cleaner Filter Selection This manufacturer’s engines have a full-flow type dispos- The quality of replacement engine air cleaner filters varies able oil filter. Use a filter of this type for replacement. The considerably.
Page 243 SERVICING AND MAINTENANCE 241 Refrigerant Recovery And Recycling — R–1234yf WARNING! (Continued) R–1234yf Air Conditioning Refrigerant is a hydrofluo- • The air conditioning system contains refrigerant un- roolefin (HFO) that is endorsed by the Environmental der high pressure. To avoid risk of personal injury or Protection Agency and is an ozone-friendly substance with damage to the system, adding refrigerant or any a low global-warming potential.
Page 244 242 SERVICING AND MAINTENANCE 1. Remove the Torx screw that secures the passenger side 2. Pull the console closeout cover rearward to disengage console closeout cover. the front retaining tab and remove the cover. Torx Screw Location Console Closeout Panel...
Page 245 SERVICING AND MAINTENANCE 243 3. Remove the two 5.5 mm screws (1 and 2) that secure the particulate air filter cover to the HVAC housing. A/C Air Filter 5. Install the A/C air filter with the air filter position indicators pointing in the same direction as removal. Air Filter Cover Screw Locations 4.
Page 246: Body Lubrication
244 SERVICING AND MAINTENANCE Refer to the “Maintenance Plan” for the proper mainte- Windshield Wiper Blades nance intervals. Clean the rubber edges of the wiper blades and the windshield periodically with a sponge or soft cloth and a Body Lubrication mild nonabrasive cleaner.
Page 247 SERVICING AND MAINTENANCE 245 The wiper blades and wiper arms should be inspected periodically, not just when wiper performance problems are experienced. This inspection should include the follow- ing points: • Wear or uneven edges • Foreign material • Hardening or cracking •...
Page 248: Exhaust System
246 SERVICING AND MAINTENANCE 3. Grab the bottom of the wiper blade and rotate it forward Exhaust System to unsnap the blade pivot pin from the wiper blade The best protection against carbon monoxide entry into the holder. vehicle body is a properly maintained engine exhaust system.
Page 249 SERVICING AND MAINTENANCE 247 Under normal operating conditions, the catalytic converter WARNING! (Continued) will not require maintenance. However, it is important to • A hot exhaust system can start a fire if you park over keep the engine properly tuned to assure proper catalyst materials that can burn.
Page 250: Cooling System
248 SERVICING AND MAINTENANCE Cooling System Coolant Checks Check engine coolant (antifreeze) protection every 12 WARNING! months (before the onset of freezing weather, where appli- cable). If the engine coolant (antifreeze) is dirty or rusty in • You or others can be badly burned by hot engine appearance, the system should be drained, flushed and coolant (antifreeze) or steam from your radiator.
Page 251 SERVICING AND MAINTENANCE 249 • This vehicle has not been designed for use with propyl- Selection Of Coolant ene glycol-based engine coolant (antifreeze). Use of Refer to “Fluids And Lubricants” in “Technical Specifica- propylene glycolbased engine coolant (antifreeze) is not tions”...
Page 252 250 SERVICING AND MAINTENANCE Please review these recommendations for using Organic NOTE: Additive Technology (OAT) engine coolant (antifreeze) • It is the owner’s responsibility to maintain the proper that meets the requirements of FCA Material Standard level of protection against freezing according to the MS.90032.
Page 253 SERVICING AND MAINTENANCE 251 The cap should be inspected and cleaned if there is any Coolant Level accumulation of foreign material on the sealing surfaces. The coolant expansion bottle provides a quick visual method for determining that the coolant level is adequate. WARNING! With the engine off and cold, the level of the coolant (antifreeze) in the bottle should be between the “MAX”...
Page 254: Brake System
252 SERVICING AND MAINTENANCE If an examination of your engine compartment shows no Brake System evidence of radiator or hose leaks, the vehicle may be In order to assure brake system performance, all brake safely driven. The vapor will soon dissipate. system components should be inspected periodically.
Page 255: Manual Transmission - If Equipped
SERVICING AND MAINTENANCE 253 Use only manufacturer’s recommended brake fluid. Refer WARNING! (Continued) to “Fluids And Lubricants” in “Technical Specifications” • Overfilling the brake fluid reservoir can result in for further information. spilling brake fluid on hot engine parts, causing the brake fluid to catch fire.
Page 256: Automatic Transmission - If Equipped
254 SERVICING AND MAINTENANCE Add fluid, if necessary, to maintain the proper level. CAUTION! Please see an authorized dealer for service. Using a transmission fluid other than the manufactur- Frequency Of Fluid Change er’s recommended fluid may cause deterioration in transmission shift quality and/or torque converter Under normal operating conditions, the fluid installed at shudder.
Page 257: Raising The Vehicle
SERVICING AND MAINTENANCE 255 Fluid Level Check Routine fluid and filter changes are not required. However, change the fluid and filter if the fluid becomes contami- The fluid level is preset at the factory and does not require nated (with water, etc.), or if the transmission is disas- adjustment under normal operating conditions.
Page 258 256 SERVICING AND MAINTENANCE Tire Markings NOTE: • P (Passenger) — Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Example: P215/65R15 95H. • European — Metric tire sizing is based on European design standards.
Page 259 SERVICING AND MAINTENANCE 257 Tire Identification Number (TIN) the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If the TIN is not found on the The TIN may be found on one or both sides of the tire; outboard side, then you will find it on the inboard side of however, the date code may only be on one side.
Page 260 258 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located be- hind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
Page 261 SERVICING AND MAINTENANCE 259 Tire Loading And Tire Pressure NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar or the rear edge of the driver’s side door. Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle.
Page 262 260 SERVICING AND MAINTENANCE This placard tells you important information about the: To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of 1. Number of people that can be carried in the vehicle. occupants and cargo should never exceed XXX kg or 2.
Page 263 SERVICING AND MAINTENANCE 261 (5) Determine the combined weight of luggage and NOTE: cargo being loaded on the vehicle. That weight may not • If your vehicle will be towing a trailer, load from your safely exceed the available cargo and luggage load trailer will be transferred to your vehicle.
Page 264: Tires - General Information
262 SERVICING AND MAINTENANCE Tires — General Information WARNING! Tire Pressure Overloading of your tires is dangerous. Overloading Proper tire inflation pressure is essential to the safe and can cause tire failure, affect vehicle handling, and satisfactory operation of your vehicle. Four primary areas increase your stopping distance.
Page 265 SERVICING AND MAINTENANCE 263 • Economy Both under-inflation and over-inflation affect the stability of the vehicle and can produce a feeling of sluggish • Tread Wear response or over responsiveness in the steering. • Ride Comfort NOTE: Safety • Unequal tire pressures from side to side may cause erratic and unpredictable steering response.
Page 266 264 SERVICING AND MAINTENANCE Tire Inflation Pressures Check tire pressures more often if subject to a wide range of outdoor temperatures, as tire pressures vary with tem- The proper cold tire inflation pressure is listed on the perature changes. driver’s side B-Pillar or rear edge of the driver’s side door. Tire pressures change by approximately 1 psi (7 kPa) per At least once a month: 12°F (7°C) of air temperature change.
Page 267 SERVICING AND MAINTENANCE 265 • The damage is only on the tread section of your tire dealer for recommended safe operating speeds, loading and cold tire inflation pressures. (sidewall damage is not repairable). • The puncture is no greater than a ¼ of an inch (6 mm). WARNING! Consult an authorized tire dealer for tire repairs and High speed driving with your vehicle under maximum...
Page 268 266 SERVICING AND MAINTENANCE See the tire pressure monitoring section for more informa- tion. Tire Spinning When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels above 30 mph (48 km/h) or for longer than 30 seconds continuously without stopping. Refer to “Freeing A Stuck Vehicle”...
Page 269 SERVICING AND MAINTENANCE 267 Life Of Tire Keep dismounted tires in a cool, dry place with as little exposure to light as possible. Protect tires from contact with The service life of a tire is dependent upon varying factors oil, grease, and gasoline. including, but not limited to: Replacement Tires •...
Page 270: Tire Types
268 SERVICING AND MAINTENANCE It is recommended you contact an authorized tire dealer or WARNING! (Continued) original equipment dealer with any questions you may • Failure to equip your vehicle with tires having ad- have on tire specifications or capability. Failure to use equate speed capability can result in sudden tire equivalent replacement tires may adversely affect the failure and loss of vehicle control.
Page 271 SERVICING AND MAINTENANCE 269 Summer Or Three Season Tires — If Equipped Snow Tires Summer tires provide traction in both wet and dry condi- Some areas of the country require the use of snow tires tions, and are not intended to be driven in snow or on ice. during the Winter.
Page 272: Spare Tires - If Equipped
270 SERVICING AND MAINTENANCE Spare Tires — If Equipped Compact Spare Tire — If Equipped The compact spare is for temporary emergency use only. NOTE: For vehicles equipped with Tire Service Kit instead You can identify if your vehicle is equipped with a compact of a spare tire, please refer to “Tire Service Kit”...
Page 273 SERVICING AND MAINTENANCE 271 Do not install a wheel cover or attempt to mount a WARNING! conventional tire on the collapsible spare wheel, since the wheel is designed specifically for the collapsible spare tire. Compact and collapsible spares are for temporary emergency use only.
Page 274: Wheel And Wheel Trim Care
272 SERVICING AND MAINTENANCE Limited Use Spare — If Equipped Wheel And Wheel Trim Care The limited use spare tire is for temporary emergency use All wheels and wheel trim, especially aluminum and only. This tire is identified by a label located on the limited chrome plated wheels, should be cleaned regularly using use spare wheel.
Page 275: Tire Chains (Traction Devices)
SERVICING AND MAINTENANCE 273 When cleaning extremely dirty wheels including excessive Dark Vapor Chrome, Black Satin Chrome, or Low Gloss brake dust, care must be taken in the selection of tire and Clear Coat Wheels wheel cleaning chemicals and equipment to prevent dam- age to the wheels.
Page 276: Tire Rotation Recommendations
274 SERVICING AND MAINTENANCE Tire Rotation Recommendations The tires on the front and rear of your vehicle operate at different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates. These effects can be reduced by timely rotation of tires. The benefits of rotation are especially worthwhile with aggres- sive tread designs such as those on all season type tires.
Page 277: Treadwear
SERVICING AND MAINTENANCE 275 Treadwear WARNING! The Treadwear grade is a comparative rating, based on The traction grade assigned to this tire is based on the wear rate of the tire when tested under controlled straight-ahead braking traction tests, and does not conditions on a specified government test course.
Page 278: Bodywork
276 SERVICING AND MAINTENANCE What Causes Corrosion? WARNING! Corrosion is the result of deterioration or removal of paint The temperature grade for this tire is established for and protective coatings from your vehicle. a tire that is properly inflated and not overloaded. The most common causes are: Excessive speed, under-inflation, or excessive load- •...
Page 279: Preserving The Bodywork
SERVICING AND MAINTENANCE 277 Do not use abrasive cleaning components, solvents, steel Special Care wool or other aggressive material to clean the lenses. • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a Preserving The Bodywork month.
Page 280 278 SERVICING AND MAINTENANCE Convertible Top Care — If Equipped Washing Hand washing is highly recommended. Automatic car NOTE: Lubricate the top rails with Berulub FR 43 every washing equipment can damage the top material. If you 2000 cycles or if scratching noises due to dust are present. must use an automatic car wash, soft cloth systems are preferred.
Page 281: Interiors
SERVICING AND MAINTENANCE 279 INTERIORS CAUTION! Seats And Fabric Parts Never use an abrasive type cleaner or bleaches. Clean- Use Mopar Total Clean to clean fabric upholstery and ers should not contain silicones, organic solvents, carpeting. petroleum distillates, or plasticizers. Always wait until the top is thoroughly dry before lowering it into the WARNING! storage area.
Page 282: Plastic And Coated Parts
280 SERVICING AND MAINTENANCE Cleaning Plastic Instrument Cluster Lenses WARNING! The lenses in front of the instruments in this vehicle are A frayed or torn belt could rip apart in a collision and molded in clear plastic. When cleaning the lenses, care leave you with no protection.
Page 283: Glass Surfaces
SERVICING AND MAINTENANCE 281 NOTE: If equipped with light colored leather, it tends to Glass Surfaces show any foreign material, dirt, and fabric dye transfer All glass surfaces should be cleaned on a regular basis with more so than darker colors. The leather is designed for easy Mopar Glass Cleaner, or any commercial household-type cleaning, and FCA recommends Mopar total care leather glass cleaner.
Page 285 TECHNICAL SPECIFICATIONS CONTENTS ▫ Do Not Use E-85 In Non-Flex Fuel Vehicles ..288 VEHICLE IDENTIFICATION NUMBER ..284 ▫ CNG And LP Fuel System Modifications ..288 BRAKE SYSTEM .
Page 286: Vehicle Identification Number
284 TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER The Vehicle Identification Number (VIN) is found on the left front corner of the instrument panel, visible through the windshield. This number also appears engraved on the right front door sill, under the sill scuff plate, on an adhesive label applied to the right door opening on the B-Pillar, on the vehicle registration and title.
Page 287: Wheel And Tire Torque Specifications
TECHNICAL SPECIFICATIONS 285 In the event power assist is lost for any reason (i.e., **Use only your authorized dealer recommended lug nuts/ repeated brake applications with the engine OFF) the bolts and clean or remove any dirt or oil before tightening. brakes will still function.
Page 288: Fuel Requirements
286 TECHNICAL SPECIFICATIONS Tighten the lug nuts/bolts in a star pattern until each FUEL REQUIREMENTS nut/bolt has been tightened twice. 1.4L Engine This engine is designed to meet all emis- sion regulations, provide satisfactory fuel economy and performance when using high-quality unleaded “Regular” gasoline having a posted octane number of 87 as specified by the (R+M)/2 method.
Page 289: Reformulated Gasoline
TECHNICAL SPECIFICATIONS 287 Reformulated Gasoline Indiscriminate use of fuel system cleaning agents should be avoided. Many of these materials intended for gum and Many areas of the country require the use of cleaner varnish removal may contain active solvents or similar burning gasoline referred to as “Reformulated Gasoline”.
Page 290: Do Not Use E-85 In Non-Flex Fuel Vehicles
288 TECHNICAL SPECIFICATIONS Do Not Use E-85 In Non-Flex Fuel Vehicles MMT In Gasoline Non-Flex Fuel Vehicles (FFV) are compatible with gasoline Methylcyclopentadienyl Manganese Tricarbonyl (MMT) is containing up to 15% ethanol (E-15). Use of gasoline with a manganese-containing metallic additive that is blended higher ethanol content may void the New Vehicle Limited into some gasoline to increase octane.
Page 291: Carbon Monoxide Warnings
TECHNICAL SPECIFICATIONS 289 Carbon Monoxide Warnings CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition WARNING! malfunctions can cause the catalytic converter to Carbon monoxide (CO) in exhaust gases is deadly. overheat. If you notice a pungent burning odor or Follow the precautions below to prevent carbon mon- some light smoke, your engine may be out of tune or oxide poisoning:...
Page 292: Fluid Capacities
290 TECHNICAL SPECIFICATIONS FLUID CAPACITIES U.S. Metric Fuel (Approximate) 10.5 Gallons 40 Liters Engine Oil with Filter 1.4 Liter Turbo Engine 4 Quarts 3.8 Liters Cooling System 1.4 Liter Turbo Engine (Mopar Antifreeze/Engine Coolant 10 Year/ 4.6 Quarts 4.4 Liters 150,000 Mile (240,000 km) Formula) —...
Page 293 TECHNICAL SPECIFICATIONS 291 Component Fluid, Lubricant, or Genuine Part Spark Plugs We recommend you use Mopar Spark Plugs. Fuel Selection 91 Octane Recommended – 87 Octane Acceptable, 0-15% Ethanol. CAUTION! CAUTION! (Continued) • Do not use water alone or alcohol-based engine •...
Page 294: Chassis
292 TECHNICAL SPECIFICATIONS Chassis Component Fluid, Lubricant, or Genuine Part Manual Transmission – If Equipped We recommend you use Mopar C635 DDCT/MTX Trans- mission Fluid. Automatic Transmission – If Equipped Use only Mopar AW-1 Automatic Transmission Fluid or equivalent. Failure to use the correct fluid may affect the function or performance of your transmission.
Page 295 MULTIMEDIA CONTENTS UCONNECT SYSTEMS ....294 UCONNECT 3/3 NAV VOICE RECOGNITION QUICK TIPS ......307 CYBERSECURITY .
Page 296: Uconnect Systems
294 MULTIMEDIA UCONNECT SYSTEMS The risk of unauthorized and unlawful access to your vehicle systems may still exist, even if the most recent For detailed information about your Uconnect system, version of vehicle software (such as Uconnect software) is refer to your Uconnect Owner’s Manual Supplement. installed.
Page 297: Uconnect Settings
MULTIMEDIA NOTE: UCONNECT SETTINGS • FCA US LLC or your dealer may contact you directly The Uconnect system uses a combination of buttons on the regarding software updates. touchscreen and buttons on the faceplate located on the center of the instrument panel that allows you to access •...
Page 298: Customer Programmable Features - Uconnect 3/3 Nav Display Settings
296 MULTIMEDIA Customer Programmable Features — Uconnect 3/3 the back arrow button on the touchscreen or push the back NAV Display Settings button on the faceplate to return to the previous menu. Or press the “X” button on the touchscreen to close out of the Push the Settings button on the faceplate, to display settings screen.
Page 299 MULTIMEDIA Units After pressing the “Units” button on the touchscreen, you may select each unit of measure independently displayed in the instrument cluster display. The following selectable units of measure are listed below: Setting Name Selectable Options Changes the instrument cluster display to US units of measure.
Page 300 298 MULTIMEDIA Voice After pressing the “Voice” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Voice Response Length Brief Long Show Command List Always With Help Never Clock & Date After pressing the “Clock & Date” button on the touch- screen, the following settings will be available: Setting Name Selectable Options...
Page 301 MULTIMEDIA Safety/Assistance After pressing the “Safety/Assistance” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Hill Start Assist — If Equipped Rear View Camera Delay ParkView Backup Camera Active Guide Lines — If Equipped NOTE: When this feature is enabled, active (dynamic) grid lines are overlaid on the Rear Backup Camera image to illustrate the width of the vehicle and its projected back up path based on the steering wheel position.
Page 302 300 MULTIMEDIA Lights After pressing the “Lights” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Daytime Running Lights Doors & Locks After pressing the “Doors & Locks” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Auto Door Locks...
Page 303 MULTIMEDIA Engine Off Options After pressing the “Engine Off Options” button on the touchscreen, the following settings will be available: Setting Name Selectable Options Radio Off Delay 0 min. 20 min. Audio After pressing the “Audio” button on the touchscreen, the following settings will be available: Setting Name Selectable Options...
Page 304 302 MULTIMEDIA Setting Name Selectable Options Radio Off With Door NOTE: When the “Radio Off With Door” feature is selected, the radio remains on until the driver or passenger door is opened or when the Radio Off Delay time expires. Phone/Bluetooth After pressing the “Phone/Bluetooth”...
Page 305 MULTIMEDIA SiriusXM Setup — If Equipped After pressing the “SiriusXM Setup” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Tune Start NOTE: “Tune Start” begins playing the current song from the beginning when you tune to a music channel using one of the 12 presets, so you can enjoy the complete song.
Page 306 304 MULTIMEDIA Restore Settings After pressing the “Restore Settings” button on the touch- screen, the following settings will be available: Setting Name Selectable Options Restore Settings NOTE: When the “Restore Settings” feature is selected it will reset the Display, Clock, Audio, and Radio Settings to their default settings.
Page 307: Steering Wheel Audio Controls
MULTIMEDIA STEERING WHEEL AUDIO CONTROLS Pushing the center button makes the radio switch between the various modes available (AM/FM/SAT/AUX/Media The remote sound system controls are located on the rear Player, etc.) and can also be used to select/enter an item surface of the steering wheel.
Page 308: Ipod/Usb/Media Player Control - If Equipped
306 MULTIMEDIA current track, or to the beginning of the previous track if it RADIO OPERATION AND MOBILE PHONES is within eight seconds after the current track begins to Under certain conditions, the mobile phone being on in play. your vehicle can cause erratic or noisy performance from your radio.
Page 309: Uconnect 3/3 Nav Voice Recognition Quick Tips
MULTIMEDIA UCONNECT 3/3 NAV VOICE RECOGNITION QUICK Get Started TIPS 1. Visit UconnectPhone.com to check mobile device and Introducing Uconnect feature compatibility and to find phone pairing instruc- tions. Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips 2.
Page 310: Basic Voice Commands
308 MULTIMEDIA All you need to control your Uconnect system with your Basic Voice Commands voice are the buttons on your steering wheel. The basic Voice Commands below can be given at any point while using your Uconnect system. Push the VR button .
Page 311: Radio
MULTIMEDIA Radio Use your voice to quickly get to the AM, FM or SiriusXM Satellite Radio stations you would like to hear. (Subscrip- tion or included SiriusXM Satellite Radio trial required.) Push the VR button . After the beep, say: •...
Page 312: Phone
310 MULTIMEDIA • “ Play artist Beethoven”; “ Play album Greatest Hits”; “ Phone Play song Moonlight Sonata”; “ Play genre Classical” Making and answering hands-free phone calls is easy with Uconnect. When the Phonebook button is illuminated for TIP: Press the “Browse” button on the touchscreen to see the Uconnect 3/3 NAV radio, your system is ready.
Page 313: General Information
MULTIMEDIA NOTE: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Additional Information © 2018 FCA US LLC. All rights reserved. Mopar and Uconnect are registered trademarks and Mopar Owner Connect is a trademark of FCA US LLC.
Page 314 312 MULTIMEDIA • Do not use solvents such as benzene, thinner, cleaners, or anti-static sprays. • Store the disc in its case after playing. • Do not expose the disc to direct sunlight. • Do not store the disc where temperatures may become too high.
Page 315 CUSTOMER ASSISTANCE CONTENTS ▫ Customer Assistance For The Hearing Or Speech SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE ......314 Impaired (TDD/TTY) .
Page 316: Suggestions For Obtaining Service For Your Vehicle
314 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR IF YOU NEED ASSISTANCE YOUR VEHICLE The manufacturer and its authorized dealer are vitally interested in your satisfaction. We want you to be happy Prepare For The Appointment with our products and services. If you are having warranty work done, be sure to have the right papers with you.
Page 317: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE 315 Any communication to the manufacturer’s customer center Mexico, D. F. should include the following information: In Mexico City: 800-505-1300 • Owner’s name and address Outside Mexico City: +(52)55 50817568 • Owner’s telephone number (home and office) Puerto Rico And U.S. Virgin Islands •...
Page 318: Service Contract
316 CUSTOMER ASSISTANCE Bell Canada. For TTY teletypewriter users, dial 711 and for Limited Warranty expires, please refer to the contract Voice callers, dial 1-800-855-0511 to connect with a Bell documents, and contact the person listed in those docu- Relay Service operator. ments.
Page 319: Warranty Information
CUSTOMER ASSISTANCE 317 WARRANTY INFORMATION To contact NHTSA, you may call the Vehicle Safety Hotline toll free at 1-888-327-4236 (TTY: 1-800-424-9153); See the Warranty Information Booklet for the terms and or go to http://www.safercar.gov; or write to: Admin- provisions of FCA US LLC warranties applicable to this istrator, NHTSA, 1200 New Jersey Avenue, SE., West vehicle and market.
Page 320: Publication Order Forms
318 CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS Owner’s Manuals To order the following manuals, you may use either the These Owner’s Manuals have been prepared with the website or the phone numbers listed below. Visa, Master- assistance of service and engineering specialists to acquaint card, American Express, and Discover orders are accepted.
Page 321 INDEX...
Page 322 320 INDEX About Your Brakes ......284 Air Filter ....... .240 Adding Engine Coolant (Antifreeze) .
Page 323 INDEX 321 Autostick ....... .174 Caps, Filler Fuel ........187 Battery .
Page 324 322 INDEX Cleaning Customer Assistance ......314 Wheels ....... .272 Customer Programmable Features .
Page 325 INDEX 323 Electronic Stability Control (ESC) ....103 Enhanced Accident Response Feature ..134, 228 Electronic Throttle Control Warning Light ..87 Ethanol.
Page 326 324 INDEX Folding Rear Seat ......26 Gauges Freeing A Stuck Vehicle ..... .225 Fuel .
Page 327 INDEX 325 Ignition ........19 Lane Change Assist ..... . .37, 40 Switch .
Page 328 326 INDEX Malfunction Indicator (Check Engine) ...91 Lubricant Selection ....253, 292 Park .
Page 329 INDEX 327 Disposal .......239 Power Filter ....... . .239 Brakes .
Page 330 328 INDEX Remote Keyless Entry Extender .......121 Power Convertible Top Function ....16 Front Seat .
Page 331 INDEX 329 Service Manuals ......318 Wheel, Heated ......34 Settings Wheel, Tilt .
Page 332 330 INDEX Inflation Pressure ......264 Traction Control ......102 Jacking .
Page 333 INDEX 331 Warranty Information ..... . .317 Washer Adding Fluid ......236 Washers, Windshield .
Page 339 INSTALLATION OF RADIO TRANSMITTING Mobile radio equipment with output power greater than EQUIPMENT normal may require special precautions. Special design considerations are incorporated into this All installations should be checked for possible interfer- vehicle’s electronic system to provide immunity to radio ence between the communications equipment and the frequency signals.

Fiat 500 ABARTH 2018 Owner's Manual

Graphical

Getting to Know Your Vehicle

Getting to Know Your Instrument Panel

Safety

Starting and Operating

In Case of Emergency

Servicing and Maintenance

Technical Specifications

Multimedia

Customer Assistance

Quick Links

Chapters

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fiat 500 ABARTH 2018

Summary of Contents for Fiat 500 ABARTH 2018
