Page 1 FIAT 500 ABARTH 2 0 1 4 O W N E R ’ S M A N U A L I N C L U D E S C A B R I O...
Page 2 FIAT is a registered trademark of Fiat Group Marketing & WARNING! Corporate Communication S.p.A., used under license by Chrysler Group LLC.
Page 3: Introduction 3
TABLE OF CONTENTS SECTION PAGE INTRODUCTION ............. . . 3 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE .
Page 5: Table Of Contents
INTRODUCTION CONTENTS INTRODUCTION ......4 VEHICLE IDENTIFICATION NUMBER ..7 HOW TO USE THIS MANUAL ....5 VEHICLE MODIFICATIONS/ALTERATIONS .
Page 6: Introduction
- all essentials that are maintaining its validity traditional to our vehicles. • the range of additional services available to FIAT This Owner’s Manual has been prepared with the assis- Group Automobiles customers tance of service and engineering specialists to acquaint NOTE: After reviewing the owner information, it you with the operation and maintenance of your vehicle.
Page 7: How To Use This Manual
INTRODUCTION 5 HOW TO USE THIS MANUAL Consult the Table of Contents to determine which section contains the information you desire. Since the specification of your vehicle depends on the items of equipment ordered, certain descriptions and illustrations may differ from your vehicle’s equipment. The detailed index at the back of this Owner’s Manual contains a complete listing of all subjects.
Page 8 6 INTRODUCTION...
Page 9: Vehicle Identification Number
INTRODUCTION 7 WARNINGS AND CAUTIONS This Owners Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire Owners Manual, you may miss important information.
Page 10: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Stamped VIN Location NOTE: It is illegal to remove or alter the VIN.
Page 11 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A WORD ABOUT YOUR KEYS ... . .11 ▫ Remote Key Unlock, Driver Door/All Doors 1st Press .......16 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Advanced Front Air Bag Features ...42 LIFTGATE ......25 ▫...
Page 13: A Word About Your Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 The vehicle is supplied with a code card containing key A WORD ABOUT YOUR KEYS code numbers to order duplicate keys, and the autho- The key fob contains the Remote Keyless Entry (RKE) rized dealer that sold you your new vehicle has the key transmitter with an integrated key.
Page 14 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 7. Release the clutch pedal. WARNING! • Before exiting a vehicle, always turn the ignition to the OFF/LOCK position, apply the parking brake, shift the transmission into REVERSE gear, and remove the key fob from the ignition. When leav- ing the vehicle, always lock your vehicle.
Page 15: Locking Doors With A Key
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key-In-Ignition Reminder WARNING! (Continued) Opening the driver’s door when the key is in the ignition • Do not leave children or animals inside parked and the ignition switch position is OFF/LOCK, sounds a vehicles in hot weather.
Page 16: Replacement Keys
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A key which has not been programmed is also Replacement Keys considered an invalid key, even if it is cut to fit the NOTE: Only keys that have been programmed to the ignition switch lock cylinder for that vehicle.
Page 17: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 General Information The Sentry Key® system complies with FCC rules part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...
Page 18: Remote Key Unlock, Driver Door/All Doors 1St Press
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE within five seconds, to unlock all doors and the liftgate. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on. Remote Key Unlock, Driver Door/All Doors 1st Press This feature lets you program the system to unlock either the driver’s door or all doors on the first push of the...
Page 19 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Power Top Open. The roof will stop opening when- WARNING! (Continued) ever the unlock button on the key fob is released, or • Never place any extremities (hands, feet, etc.) near when it reaches the spoiler position the convertible top components, the upper wind- NOTE: If your power convertible top does not open with shield area, the shelf area behind the rear seats, or...
Page 20: To Lock The Doors And Liftgate
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Press the mechanical key release button and release To Lock The Doors And Liftgate the mechanical key to access the battery case screw Press and release the LOCK button on the RKE transmit- located on the side of the Key Fob.
Page 21 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 Key Fob Screw Location Battery Case Removed 3. Take out the battery case. Remove and replace the 4. Refit the battery case inside the Key Fob and turn the battery observing its polarity. screw to lock it into place.
Page 22: General Information
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If your RKE transmitter fails to operate from a normal General Information distance, check for these two conditions: This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the 1.
Page 23 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 WARNING! (Continued) • For personal security and safety in the event of a collision, lock the vehicle doors as you drive as well as when you park and leave the vehicle. • Before exiting a vehicle, always apply the parking brake, shift the transmission into PARK, and re- move the Key Fob from the ignition.
Page 24: Power Door Locks
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks WARNING! (Continued) A power door lock switch is incorporated into the driver • Do not leave the Key Fob in or near the vehicle, or door handle. Push or pull the handle to lock or unlock the in a location accessible to children.
Page 25: Power Windows
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 To change the Autoclose setting in the EVIC, proceed as follows: 1. Briefly press the MENU button “On” or “Off” will flash on the display (according to the previous set- ting). 2. Press the + or – button for setting. 3.
Page 26 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE driver and passenger door windows. The window con- trols will operate when the ignition switch is in the ON/RUN position. WARNING! Never leave children unattended in a vehicle, and do not let children play with power windows. Do not leave the key fob in or near the vehicle, or in a location accessible to children.
Page 27: Liftgate
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 second, release, and the window will go down automati- To open the liftgate, squeeze the liftgate release handle cally. To cancel the Auto-Down movement, operate the and pull the liftgate open with one fluid motion. switch in either the up or down direction and release the switch.
Page 28: Occupant Restraints
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS WARNING! Some of the most important safety features in your • Driving with the liftgate open can allow poisonous vehicle are the restraint systems: exhaust gases into your vehicle. You and your •...
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 • All seat belt systems (except the driver’s) include Here are some simple steps you can take to minimize the Automatic Locking Retractors (ALRs), which lock the risk of harm from a deploying air bag: seat belt webbing into position by extending the belt 1.
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ride properly buckled up in the rear seat. Never allow 5. If the air bag system in this vehicle needs to be children to slide the shoulder belt behind them or under modified to accommodate a disabled person, contact their arm.
Page 31: Lap/Shoulder Belts
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 Buckle up even though you are an excellent driver, even WARNING! (Continued) on short trips. Someone on the road may be a poor driver • Being too close to the steering wheel or instrument and cause a collision that includes you.
Page 32 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE lock and reduce the risk of you striking the inside of the WARNING! (Continued) vehicle or being thrown out. • Wearing your belt in the wrong place could make your injuries in a collision much worse. You might WARNING! suffer internal injuries, or you could even slide out •...
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 the belt. Slide the latch plate up the webbing as far as 3. When the belt is long enough to fit, insert the latch necessary to allow the belt to go around your lap. plate into the buckle until you hear a “click.”...
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) your strongest bones will take the force in a colli- • A belt buckled into the wrong buckle will not sion. protect you properly. The lap portion could ride too •...
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 WARNING! • A lap belt worn too high can increase the risk of injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdo- men.
Page 36: Lap/Shoulder Belt Untwisting Procedure
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. 1. Position the latch plate as close as possible to the The belt will automatically retract to its stowed posi- anchor point.
Page 37: Automatic Locking Retractor Mode (Alr) - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 Restraints” section. The chart below defines the type of out only the amount of webbing necessary to comfort- feature for each seating position. ably wrap around the occupant’s mid-section. Slide the latch plate into the buckle until you hear a click. Driver Passenger Automatic Locking Retractor Mode (ALR) —...
Page 38: Energy Management Feature
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Engage The Automatic Locking Mode WARNING! 1. Buckle the combination lap and shoulder belt. • The belt and retractor assembly must be replaced if 2. Grasp the shoulder portion and pull downward until the seat belt assembly Automatic Locking Retractor the entire belt is extracted.
Page 39: Seat Belt Pretensioning And Load Limitation
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 This safety belt system has a retractor assembly that is Enhanced Seat Belt Use Reminder System designed to release webbing in a controlled manner. This (BeltAlert®) feature is designed to help reduce the belt force acting on BeltAlert®...
Page 40: Seat Belt Extender
WARNING! BeltAlert® can be enabled or disabled by your autho- Using a seat belt extender when not needed can rized dealer. FIAT Group Automobiles S.p.A. does not increase the risk of injury in a collision. Only use recommend deactivating BeltAlert®.
Page 41: Seat Belts And Pregnant Women
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 Seat Belts And Pregnant Women Supplemental Restraint System (SRS) — Air Bags We recommend that pregnant women use the seat belts This vehicle has Advanced Front Air Bags for both the throughout their pregnancy. Keeping the mother safe is driver and front passenger as a supplement to the seat the best way to keep the baby safe.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The Driver and Front Passenger Advanced Front Air Bags are certified to the Federal regulations for Advanced Air Bags. The Advanced Front Air Bags are designed to allow the air bags to have different inflation levels based on several factors, including the severity and type of collision.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 This vehicle is equipped with Supplemental Side Air Bag • Occupant Restraint Controller (ORC) Inflatable Curtains (SABIC) to protect the driver, front, • Air Bag Warning Light and rear passengers sitting next to a window. The SABIC are located above the side windows.
Page 44: Advanced Front Air Bag Features
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Advanced Front Air Bag Features WARNING! (Continued) The Advanced Front Air Bag system provides output • Do not put anything on or around the air bag appropriate to the severity and type of collision as covers or attempt to open them manually.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 Supplemental Seat-Mounted Side Air Bags (SAB) When the air bag deploys, it opens the seam between the front and side of the seat’s trim cover. Each air bag Supplemental Seat-Mounted Side Air Bags (SAB) provide deploys independently;...
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system includes side impact sensors that are cali- brated to deploy the Seat-Mounted Side Air Bags (SAB) and SABIC during impacts that require air bag occupant protection. SAB and SABIC air bags are a supplement to the seat belt restraint system.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 WARNING! WARNING! (Continued) • Your vehicle is equipped with SABIC air bags, do • Your vehicle is equipped with left and right not have any accessory items installed which will Supplemental Side Air Bag Inflatable Curtain alter the roof, including adding a sunroof to your (SABIC), do not stack luggage or other cargo up vehicle.
Page 48: Air Bag Deployment Sensors And Controls
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Knee Impact Bolsters ORC deploys the Advanced Front Air Bags, Supplemen- tal Driver Side Knee Air Bag, Supplemental Side Air Bag The Knee Impact Bolsters help protect the knees of the Inflatable Curtain (SABIC), Supplemental Seat-Mounted driver and front passenger, and position the front occu- Side Air Bags (SAB), and front seat belt pretensioners, as pants for the best interaction with the Advanced Front...
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 hand, depending on the type and location of impact, ON/RUN or START position. If the key is in the OFF/ Advanced Front Air Bags may deploy in crashes with LOCK position, or not in the ignition, the air bag system little vehicle front-end damage but that produce a severe is not on and the air bags will not inflate.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE noted that could affect the air bag system. The diagnos- quantity of non-toxic gas is generated to inflate the tics also record the nature of the malfunction. Advanced Front Air Bags. Different air bag inflation rates are possible, based on several factors, including the WARNING! collision type and severity.
Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Advanced Front Air Bags, it signals the inflator units. A Based on the severity and type of collision, the side air large quantity of non-toxic gas is generated to inflate the bag inflator on the crash side of the vehicle may be Supplemental Driver Side Knee Air Bag.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Side Air Bag Inflatable Curtain covers the window. The air bag inflates in about 30 (SABIC) Inflator Units milliseconds (about one-quarter of the time that it takes to blink your eyes) with enough force to injure you if you During collisions where the impact is confined to a are not belted and seated properly, or if items are particular area of the side of the vehicle, the ORC may...
Page 53 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Front And Side Impact Sensors • Unlock the doors automatically. In front and side impacts, impact sensors can aid the After the event occurs, when the system is active, the ORC in determining appropriate response to impact message Fuel Cutoff See Handbook is displayed.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Customer Action Customer Will See 1. Turn ignition OFF. (Turn Signal Switch Must be placed in Neutral State). 2. Turn ignition ON. Left Turn Light is OFF. Right Turn Light BLINKS. 3. Turn Right Turn Signal Switch ON. Right Turn Light is ON SOLID.
Page 55 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 If a reset procedure step is not completed within 45 floor. They are not caused by contact with chemicals. seconds, then the turn signal lights will turn off and the They are not permanent and normally heal quickly. reset procedure must be performed again in order to be However, if you haven’t healed significantly within a successful.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Air Bag System WARNING! WARNING! Deployed air bags and seat belt pretensioners cannot protect you in another collision. Have the air bags, • Modifications to any part of the air bag system seat belt pretensioners, and the front seat belt retrac- could cause it to fail when you need it.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 Air Bag Warning Light WARNING! (Continued) • Do not attempt to modify any part of your air bag You will want to have the air bags ready to system. The air bag may inflate accidentally or may inflate for your protection in a collision.
Page 58: Event Data Recorder (Edr)
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If the speedometer, tachometer, or any engine • How various systems in your vehicle were operating; related gauges are not working, the Occupant Restraint • Whether or not the driver and passenger safety belts Controller (ORC) may also be disabled.
Page 59: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 To read data recorded by an EDR, special equipment is Children 12 years or younger should ride properly required, and access to the vehicle or the EDR is needed. buckled up in a rear seat, if available. According to crash In addition to the vehicle manufacturer, other parties, statistics, children are safer when properly restrained in such as law enforcement, that have the special equip-...
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WARNING! • For additional information, refer • “Extreme Hazard! Do not use a rearward-facing www.seatcheck.org or call 1–866–SEATCHECK. Cana- child restraint on a seat protected by an air bag in dian residents should refer to Transport Canada’s front of it!”...
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight or Age Recommended Type of Child Restraint Infants and Children who are two years old or Either an Infant Carrier or a Convertible Toddlers younger and who have not reached the Child Restraint, facing rearward in the rear...
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints reach the highest weight or height allowed by their convertible child seat. Safety experts recommend that children ride rearward- facing in the vehicle until they are two years old or until WARNING! they reach either the height or weight limit of their rear facing child safety seat.
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 have outgrown the rear-facing weight or height limit of WARNING! their rear-facing convertible child seat. Children should remain in a forward-facing child seat with a harness for • Improper installation can lead to failure of an as long as possible, up to the highest weight or height infant or child restraint.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Children Too Large For Booster Seats 4. Is the lap part of the belt as low as possible, touching the child’s thighs and not their stomach? Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend 5.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Recommendations For Attaching Child Restraints Use any attachment method shown with an “X” Below Combined LATCH – Weight of the LATCH – Restraint Type Lower Anchors Seat Belt + Top Child + Child Lower Anchors Seat Belt Only + Top Tether...
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lower Anchors and Tethers for Children (LATCH) Your vehicle is equipped with the child restraint anchor- Restraint System age system called LATCH, which stands for Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH- equipped child seats.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 LATCH Positions For Installing Child Restraints In This Vehicle Lower Anchorage Symbol 2 anchorages per • seating position Top Tether Anchorage Symbol •...
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE What is the weight limit (child’s 65 lbs (29.5 kg) Use the LATCH anchorage system weight + weight of the child re- until the combined weight of the straint) for using the LATCH an- child and the child restraint is chorage system to attach the child 65 lbs (29.5 kg).
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Can two child restraints be at- Never “share” a LATCH anchorage tached using a common lower with two or more child restraints. LATCH anchorage? If the center position does not have dedicated LATCH lower anchor- ages, use the seat belt to install a child seat in the center position next to a child seat using the...
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Locating The LATCH Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback, below the anchorage sym- bols on the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 LATCH-compatible child restraint systems will be Always follow the directions of the child restraint manu- equipped with a rigid bar or a flexible strap on each side. facturer when installing your child restraint. Not all child Each will have a hook or connector to attach to the lower restraint systems will be installed as described here.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Place the child seat between the lower anchorages for 6. Tighten all of the straps as you push the child restraint that seating position. For some second row seats, you rearward and downward into the seat. Remove slack may need to recline the seat and / or raise the head in the straps according to the child restraint manufac- restraint to get a better fit.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 child restraint belt path and then buckle it. Do not lock WARNING! the seatbelt. Remind all children in the vehicle that the seat belts are not toys and that they should not play with Child restraint anchorages are designed to withstand them.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing Child Restraints Using The Vehicle Seat child restraint’s belt path. Please see the following Belt table(s) and the following sections for more information about both types of seat belts. The seat belts in the passenger seating positions are equipped with either a Switchable Automatic Locking Lap/Shoulder Belt Systems for Installing Child Retractor (ALR) or a cinching latch plate or both.
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 What is the weight limit (child’s Weight limit of the Child Restraint Always use the tether anchor when weight + weight of the child re- using the seat belt to install a for- straint) for using the Tether Anchor ward facing child restraint, up to the with the seat belt to attach a forward...
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing A Child Restraint With A Switchable 5. To lock the seat belt, pull down on the shoulder part of Automatic Locking Retractor (ALR) the belt until you have pulled all the seat belt webbing out of the retractor.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 strap. See the section “Installing Child Restraints rear-most position to make room for the child seat. Using the Top Tether Anchorage” for directions to You may also move the front seat forward to allow attach a tether anchor.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE strap. Refer to “Installing Child Restraints Using The If the belt still cannot be tightened after you shorten the Top Tether Anchorage” for directions to attach a tether buckle, disconnect the latch plate from the buckle, turn anchor.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 route the tether strap under the head restraint and 4. Remove slack in the tether strap according to the child between the two posts. If not possible, lower the head restraint manufacturer’s instructions. restraint and pass the tether strap around the outboard side of the head restraint.
Page 80: Transporting Pets
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE While cruising, brief full-throttle acceleration within the Transporting Pets limits of local traffic laws contributes to a good break-in. Air Bags deploying in the front seat could harm your pet. Wide-open throttle acceleration in low gear can be detri- An unrestrained pet will be thrown about and possibly mental and should be avoided.
Page 81: Safety Tips
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 NOTE: A new engine may consume some oil during its WARNING! first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and • Do not leave children or animals inside parked not interpreted as an indication of difficulty.
Page 82: Exhaust Gas
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas WARNING! (Continued) • If it is necessary to sit in a parked vehicle with the WARNING! engine running, adjust your heating or cooling Exhaust gases can injure or kill. They contain carbon controls to force outside air into the vehicle.
Page 83: Safety Checks You Should Make Inside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 dealer. If the light stays on, flickers, or comes on while Safety Checks You Should Make Inside The driving, have the system checked by an authorized Vehicle dealer. Seat Belts Defroster Inspect the belt system periodically, checking for cuts, frays, and loose parts.
Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Check mounting of mats on a regular basis. Always Pedals that cannot move freely can cause loss of properly reinstall and secure floor mats that have vehicle control and increase the risk of serious per- been removed for cleaning.
Page 85: Periodic Safety Checks You Should Make Outside The Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 Door Latches Periodic Safety Checks You Should Make Outside The Vehicle Check for positive closing, latching, and locking. Tires Fluid Leaks Examine tires for excessive tread wear and uneven wear Check area under vehicle after overnight parking for fuel, patterns.
Page 87 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS POWER CONVERTIBLE TOP — IF EQUIPPED . .88 ▫ Heated Mirrors — If Equipped ... .95 ▫ Lowering The Power Top....88 ▫...
Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ EZ Entry Feature ..... .106 ▫ Lane Change Assist ....113 ▫...
Page 89 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 ▫ To Vary The Speed Setting ....122 ▫ Wind Buffeting ..... . .130 ▫...
Page 90: Power Convertible Top - If Equipped
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: POWER CONVERTIBLE TOP — IF EQUIPPED On vehicles equipped with a power convertible top, the • The power top buttons will operate when the ignition power convertible top switch is located on the overhead switch is turned to the ACC/ON/RUN position.
Page 91: Raising The Power Top
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 NOTE: Vertical movement only operates in auto open/ NOTE: Rail lubrication is recommended every 2000 close mode. cycles, or if scratching noises due to dust are present. Refer to “Fluids, Lubes, and Genuine Part” in “Maintain- Raising The Power Top ing Your Vehicle”...
Page 92: Power Convertible Top Relearn Procedure
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE closing to the one-quarter open and three-quarter open CAUTION! (Continued) comfort stops), or if the remote keyless power top • Use care when washing the vehicle, water pressure function is inoperable, or if the trunk lid does not open - directed at the weather strip seals may cause water the following relearn procedure may be necessary.
Page 93: Wind Stop
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 7. CONTINUE to hold the CLOSED button until the top NOTE: DO NOT interrupt this activity. begins to cycle fully open, then release the CLOSED If the power convertible top does not relearn repeat the button.
Page 94: Automatic Dimming Mirror - If Equipped
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlight glare from vehicles behind you can be reduced Automatic Dimming Mirror — If Equipped by moving the small control under the mirror to the night This mirror automatically adjusts for headlight glare position (toward the rear of the vehicle).
Page 95: Power Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 Power Mirrors The power mirror controls are located on the driver’s door trim panel. Automatic Dimming Mirror CAUTION! To avoid damage to the mirror during cleaning, never Power Mirror Switches spray any cleaning solution directly onto the mirror. The power mirror controls consist of a mirror select Apply the solution onto a clean cloth and wipe the switch and a four-way mirror control switch.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE mirror, press the mirror select switch to either the L (left) Spotter Mirror — If Equipped or R (right) to select the mirror you need to adjust. Some models are equipped with a driver’s side spotter Using the mirror control switch, press on any of the four mirror.
Page 97: Folding Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Folding Mirrors The exterior mirrors are hinged to allow the mirror to pivot forward or rearward to help avoid damage. The mirror has three detent positions: full forward, normal and full rearward. Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice.
Page 98: Blue&Me™ Hands-Free Communication
Overview voice recognition system is of the “speaker independent” Windows Mobile™-based FIAT BLUE&ME™ is a per- type. sonal telematic system enabling you to use communica- With this system you can also play your favorite music...
Page 99: The Hands-Free Kit
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 your mobile phone manually and visually using the The Hands-Free Kit steering wheel controls and the instrument panel multi- The basic characteristic of this hands-free kit is voice function display. recognition with Bluetooth® wireless technology. With this system you can make and receive calls safely and securely by using either voice commands or buttons on the steering wheel.
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To get started with BLUE&ME™ hands-free kit with • To interact with BLUE&ME™ you can use either the voice recognition, you have to simply pair your buttons on the steering wheel or voice commands. Bluetooth®...
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 The hands-free kit enables the following operations: • Conference Call — you can call another contact while you are engaged in a phone conversation (with • Contact Calling By Voice — you can call a contact in Bluetooth®...
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE wheel. When using the hands-free phone, the audio NOTE: Not all mobile phones support the SMS text output of a phone conversation is heard through your car message reader function or automatic phonebook trans- sound speakers.
Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 • To manage the list of SMS texts received on your Media Player BLUE&ME™ paired mobile phone. With the BLUE&ME™ media player you can play, the digital audio files stored on a USB device by simply •...
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Playback Options — while playing tracks you can WARNING! select the following options: Play, Stop, Next track, Previous track, Shuffle and Loop track. • Driving while distracted can result in loss of ve- hicle control, accident and injury.
Page 105: Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 WARNING! (Continued) WARNING! • Keep the Owner’s Manual in the car: when kept in • It is dangerous to ride in a cargo area, inside or the car, the Owner’s Manual will be a ready refer- outside of a vehicle.
Page 106: Recline Adjustment
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seat belts and while the vehicle is parked.
Page 107: Seat Height Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Seat Height Adjustment The driver’s seat height can be raised or lowered by using a lever, located on the outboard side of the seat. Pump the lever upward to raise the seat height, or pump the lever downward to lower the seat height.
Page 108: Ez Entry Feature
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lift the seatback upright and push the seat rearward to EZ Entry Feature its locked position once the rear passengers are seated. The driver and front passenger seats have an EZ entry feature for rear seat passengers. Pull upward on the Memory Feature release tether, located on the outboard side of the seat- Both front seats have a memory feature, which can...
Page 109: Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 fore/aft (memory) position on the tracks. This results in WARNING! the seat back memory being set only – The track will then be locked forward of its last set fore/aft memory posi- • Persons who are unable to feel pain to the skin tion.
Page 110: Head Restraints
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE button, located at the base of the head restraint, and push Head Restraints downward on the head restraint. Refer to “Occupant Head restraints are designed to reduce the risk of injury Restraints” in “Things To Know Before Starting Your by restricting head movement in the event of a rear- Vehicle”...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 1. Pull the bottom of the RED hood release lever, located on the left kick panel, rearward. Hood Safety Latch Location Lift the hood prop rod that clips to the right side (left side when standing in front of the hood) of the engine Hood Release Lever compartment.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Be sure the hood is fully latched before driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision. Failure to follow this warning could result in serious injury or death.
Page 113: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 LIGHTS Multifunction Lever The multifunction lever, located on the left side of the steering wheel, controls the operation of the headlights, headlight beam selection, passing light and turn signals. NOTE: The external lights can only be turned on with the ignition in the ON/RUN position.
Page 114: High Beams
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High Beams Daytime Running Lights — If Equipped To activate the Daytime Running Lights (DRL), rotate the With the low beams activated, push the multi- end of the multifunction lever to the O symbol. function lever towards the instrument panel to NOTE: The low beams and side/taillights will not be on turn on the high beams.
Page 115: Lane Change Assist
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Lane Change Assist Tap the lever up or down once, without moving beyond the detent, and the turn signal (right or left) will flash three times then automatically turn off. Follow Me Home/Headlight Delay When this feature is selected the driver can choose to have the headlights remain on for a preset period of time.
Page 116: Interior Lights
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Deactivation on the right light and press the switch to the left to turn on the left light. Pull the multifunction lever toward the steering wheel and hold it for more than two seconds. CAUTION! Interior Lights Before getting out of the vehicle be sure that the...
Page 117: Front Fog Lights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 • When the doors are unlocked with the Key Fob a 10 second timer is activated. • When the doors are locked with the Key Fob the lights will turn off. Interior Light Timing (On/Right Position) •...
Page 118: Windshield Wipers And Washers
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS The windshield wiper/washer lever is located on the right side of the steering column. NOTE: The windshield wipers/washers will only oper- ate with the ignition in the ON/RUN position. Front Windshield Wiper Operation There are five different modes of operation for the front windshield wipers.
Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 NOTE: The Intermittent function only has one detent Front Windshield Washer Operation but wiper delay will vary with changes in vehicle speed. Pull the windshield wiper/washer lever toward the As vehicle speed increases the delay time will decrease. steering wheel to activate the washers.
Page 120: Rear Windshield Wiper
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Always remove any buildup of snow that prevents the windshield wiper blades from returning to the off position. If the windshield wiper control is turned off and the blades cannot return to the off position, damage to the wiper motor may occur.
Page 121: Tilt Steering Column - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 Rear Windshield Washer Operation Push the windshield wiper/washer lever toward the instrument panel to activate the rear washer. Push and hold the lever for more than a half second and the wipers will activate automatically for three cycles after the lever is released.
Page 122: Electronic Speed Control
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Failure to follow this warning may result in serious injury or death.
Page 123: To Activate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 NOTE: In order to ensure proper operation, the Elec- WARNING! tronic Speed Control system has been designed to shut down if multiple Speed Control functions are operated at Leaving the Electronic Speed Control system on the same time.
Page 124: To Deactivate
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pressing the RES (+) button once will result in a 1 mph To Deactivate (1.0 km/h) increase in set speed. Each subsequent tap of A soft tap on the brake pedal, pushing the CANC button, the button results in an increase of 1 mph (1.0 km/h).
Page 125: To Accelerate For Passing
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 To Accelerate For Passing WARNING! Press the accelerator as you would normally. When the Electronic Speed Control can be dangerous where the pedal is released, the vehicle will return to the set speed. system cannot maintain a constant speed.
Page 126: Rear Park Assist Sensors
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Park Assist is automatically activated when the The minimum height of a detectable obstacle corre- transmission is placed into REVERSE. As the distance sponds to the maximum height of an obstacle that would from an obstacle behind the vehicle decreases, the au- clear the underside of the car during the parking maneu- dible alert becomes more frequent.
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Audible And Visual Signals Supplied By The Rear Park Assist System SIGNAL MEANING INDICATION Obstacle Distance An obstacle is present within the Audible signal (dashboard loud- sensors’ field of view speaker) • Sound pulses emitted at a rate that increases as the distance de- creases.
Page 128: Failure Indications
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE While audible signals are emitted, the audio system is not The sensors and wiring are tested continuously when the muted. ignition is in the ON/RUN position. Failures are indi- cated immediately if they occur when the system is ON. The audible signal is turned off immediately if the distance increases.
Page 129: Park Assist System Usage Precautions
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 • Objects such as bicycle carriers, etc., must not be Park Assist System Usage Precautions placed within 12 in (30 cm) from the rear fascia/ NOTE: bumper while driving the vehicle. Failure to do so can •...
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) WARNING! (Continued) • The vehicle must be driven slowly when using • Before using ParkSense®, it is strongly recom- Rear Park Assist in order to be able to stop in time mended that the ball mount and hitch ball assem- when an obstacle is detected.
Page 131: Power Sunroof - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof roof switch is located in the overhead • Never leave children alone in a vehicle, or with console. access to an unlocked vehicle. Never leave the key fob in or near the vehicle, or in a location accessible to children.
Page 132: To Open
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Open Pinch Protect Feature Press and hold the power sunroof switch rearward for This feature will detect an obstruction in the opening of approximately one second and the sunroof will stop at the sunroof during Express Close operation.
Page 133: Emergency Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Emergency Operation In case of electrical failure the sunroof can be operated with the hex wrench that is located in the glove box. There is a plug located in the rear of the sunroof opening at the center of the vehicle.
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watts (13 Amps) power rating is exceeded, the fuse protecting the system will need to be replaced. •...
Page 135 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. •...
Page 136: Cigar Lighter - If Equipped
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER — IF EQUIPPED CAUTION! WARNING! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in When the cigar lighter is in use it becomes very hot. use (i.e., cellular phones, etc.).
Page 137: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 For rear passengers, there are cupholders located on the CUPHOLDERS floor between the front driver and passenger seats. For the driver and front passenger, cupholders are lo- cated on the floor console between the front seats. Rear Cupholders Front Cupholders...
Page 138: Storage
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE CARGO AREA FEATURES The rear seatbacks have a fold down feature to allow Glove Box Compartment increased cargo capacity. The glove box is located on the right side of the instru- ment panel. Pull outward on the door latch to open the Push down the release button, located at the outboard glove box.
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Rear Seat Release Buttons Folded Rear Seats...
Page 140: Rear Window Features
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES CAUTION! Rear Window Defroster Failure to follow these cautions can cause damage to the heating elements: The rear window defroster button is located in the • Use care when washing the inside of the rear center of the instrument panel, below the radio.
Page 141: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS INSTRUMENT PANEL FEATURES ..141 ▫ Trip Computer ..... . .160 TURBO BOOST GAUGE .
Page 142 140 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Quick Guide ......177 ▫ CD Player Operation ....201 ▫...
Page 143: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 141 INSTRUMENT PANEL FEATURES 1 — Side Vent 7 — Passenger Air Bag 13 — Storage Compartment 2 — Multifunction Lever – Light Control 8 — Glove Compartment 14 — Shift Lever 3 — Instrument Cluster And Warning Lights 9 —...
Page 144: Turbo Boost Gauge
142 UNDERSTANDING YOUR INSTRUMENT PANEL TURBO BOOST GAUGE Your vehicle is equipped with a boost gauge and inte- grated shift light indicator located to the left of the instrument cluster. The boost gauge indicates the intake manifold pressure relative to barometric pressure. The engine management system in your vehicle intelligently regulates intake manifold pressure based on environ- mental (ambient) and engine operating conditions.
Page 145: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 143 INSTRUMENT CLUSTER...
Page 146: Instrument Cluster Descriptions
144 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Rear Defrost Button INSTRUMENT CLUSTER DESCRIPTIONS 1. Glow Plug Light — If Equipped Press and release this button to turn on the rear window defroster. This indicator will illuminate The Glow Plug light will flash during engine oil when the rear window defroster is on.
Page 147 UNDERSTANDING YOUR INSTRUMENT PANEL 145 6. Park/Headlight ON Indicator / Follow Me Home CAUTION! (Continued) (Headlight Delay) Indicator — If Equipped • Do not use scrapers, sharp instruments, or abrasive This indicator will illuminate when the park window cleaners on the interior surface of the lights or headlights are turned on.
Page 148 146 UNDERSTANDING YOUR INSTRUMENT PANEL Failure, External Light Failure, Fuel Cut-Off Intervention, 11. Seat Belt Reminder Light Fuel Cut-Off Not Available, Parking Sensor Failure. When the ignition switch is first turned to ON/ 9. Air Bag Warning Light RUN, this light will turn on if the driver’s seat belt is unbuckled, a chime will sound.
Page 149 UNDERSTANDING YOUR INSTRUMENT PANEL 147 vehicle is experiencing a problem with the charging should turn off. If the light remains lit with the engine system. Obtain SERVICE IMMEDIATELY. See an autho- running, your vehicle will usually be drivable; however, rized dealer. see an authorized dealer for service as soon as possible.
Page 150 148 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle placard or tire inflation pressure label, you should Your vehicle has also been equipped with a TPMS determine the proper tire inflation pressure for those malfunction indicator to indicate when the system is not tires.) operating properly.
Page 151 UNDERSTANDING YOUR INSTRUMENT PANEL 149 17. Oil Pressure Warning Light CAUTION! This light indicates low engine oil pressure. The The TPMS has been optimized for the original light should turn on momentarily when the engine is equipment tires and wheels. TPMS pressures and started.
Page 152 150 UNDERSTANDING YOUR INSTRUMENT PANEL Certain conditions, such as a loose or missing gas cap, WARNING! poor fuel quality, etc., may illuminate the MIL after engine start. The vehicle should be serviced if the light A malfunctioning catalytic converter, as referenced stays on through several of your typical driving cycles.
Page 153 UNDERSTANDING YOUR INSTRUMENT PANEL 151 normal, turn the engine off immediately and call for Vehicles equipped with the Anti-Lock Brake System service. Refer to “If Your Engine Overheats” in “What To (ABS), are also equipped with Electronic Brake Force Do In Emergencies” for further information. Distribution (EBD).
Page 154 152 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: This light shows only that the parking brake is been detected in the ESC system. If this light remains on, applied. It does not show the degree of brake application. see your authorized dealer as soon as possible to have the problem diagnosed and corrected.
Page 155 Anti-Lock the vehicle. Contact a Fiat dealer if you still cannot start brakes. If the ABS light does not turn on when the the engine.
Page 156 154 UNDERSTANDING YOUR INSTRUMENT PANEL The gauge pointer will likely indicate a higher tempera- WARNING! ture when driving in hot weather, up mountain grades, or when towing a trailer. It should not be allowed to A hot engine cooling system is dangerous. You or exceed the upper limits of the normal operating range.
Page 157 UNDERSTANDING YOUR INSTRUMENT PANEL 155 as it was before the repair or service. If s/he cannot do so, 28. Fuel Gauge / Fuel Door Reminder then the odometer must be set at zero, and a sticker must The fuel door reminder indicates that the fuel filler door be placed in the door jamb stating what the mileage was is located on the right side of the vehicle.
Page 158: Electronic Vehicle Information Center (Evic)
156 UNDERSTANDING YOUR INSTRUMENT PANEL 30. Speedometer The Speedometer shows the vehicle speed in miles per hour (mph) and/or kilometers per hour (km/h). ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the instrument cluster.
Page 159: Evic Control Buttons
UNDERSTANDING YOUR INSTRUMENT PANEL 157 • Outside Temperature Display • To increase or decrease values during settings. • Trip Computer Functions NOTE: When opening one of the front doors, the EVIC display will turn on the clock and the miles or kilometers EVIC Control Buttons covered (for versions/markets, where provided) for a Press the MENU button briefly to access the menu...
Page 160 158 UNDERSTANDING YOUR INSTRUMENT PANEL • Set Time 1. Selecting An Option Of The Main Menu Without Submenu • Set Date 1. Briefly press the MENU button to select the main • See Radio menu option to set. • Speed Display 2.
Page 161: Change Engine Oil Indicator System
UNDERSTANDING YOUR INSTRUMENT PANEL 159 3. Briefly press the MENU button to select the displayed scheduled oil change interval. The engine oil change submenu option and to open the relevant setup menu. indicator system is duty cycle based, which means the engine oil change interval may fluctuate, dependent 4.
Page 162: Trip Computer
160 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If the indicator message illuminates when you New Trip start the vehicle, the oil change indicator system did not To reset: reset. If necessary, repeat this procedure. • Press and hold the TRIP button to reset the system Trip Computer manually.
Page 163: Trip Functions
UNDERSTANDING YOUR INSTRUMENT PANEL 161 Start Of Trip Procedure “Trip A” can be used to display the figures relating to: With the ignition on, press and hold the TRIP button for • Range over one second to reset. • Trip distance A Exit Trip •...
Page 164: Values Displayed
162 UNDERSTANDING YOUR INSTRUMENT PANEL Average Consumption Values Displayed This value shows the approximate average consumption Range since the last reset. This indicates the distance which may be traveled with the fuel remaining in the tank, assuming that driving Instant Consumption conditions will not change.
Page 165: Personal Settings (Customer-Programmable Features)
UNDERSTANDING YOUR INSTRUMENT PANEL 163 2. Briefly press the MENU button to go back to the menu Personal Settings (Customer-Programmable screen or press and hold the MENU (approximately Features) one second) to go back to the main screen without Dimmer storing settings.
Page 166 164 UNDERSTANDING YOUR INSTRUMENT PANEL speed. Pressing the UP or DOWN buttons 2. Press the DOWN button. “Off” will flash on the selects the speed limit. Press MENU to confirm display. selection. 3. Briefly press the MENU button to go back to the menu NOTE: The setting can be increased or decreased by screen, or press and hold the MENU button (approxi- 5 mph or km/h each time the UP/DOWN button is...
Page 167 UNDERSTANDING YOUR INSTRUMENT PANEL 165 3. Briefly press the MENU button to go back to the menu 4. When accessing the “Time” sub-menu item, briefly screen, or press and hold the MENU button (approxi- press the MENU button and “hours” will flash on the mately one second) to go back to the main screen display.
Page 168 166 UNDERSTANDING YOUR INSTRUMENT PANEL • When accessing the “Mode” submenu, briefly press 2. Press the UP or DOWN button for setting. the MENU button. The previously set display format 3. Briefly press the MENU button and “month” will flash will flash on the display.
Page 169 UNDERSTANDING YOUR INSTRUMENT PANEL 167 • Briefly press the MENU button to go back to the menu 3. Briefly press the MENU button to go back to the menu screen, or press and hold the MENU button (approxi- screen, or press and hold the MENU button (approxi- mately one second) to go back to the main screen mately one second) to go back to the main screen without storing the settings.
Page 170 168 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Briefly press the MENU button to go back to the menu Units (Set Units) screen, or press and hold the MENU button (approxi- This function may be used to set the measurement unit in mately one second) to go back to the main screen.
Page 171 UNDERSTANDING YOUR INSTRUMENT PANEL 169 6. Briefly press the MENU button to return to the 3. When accessing the “Temperature” submenu: briefly sub-menu. press the MENU button. Either “°F” or “°C” will appear on the display (according to the previous 7.
Page 172 170 UNDERSTANDING YOUR INSTRUMENT PANEL Language (Selecting The Language) Buzzer Volume (Adjusting The Failure/Warning Buzzer Volume) The messages can be displayed in the following lan- guages: Italian, English, German, Portuguese, Spanish, With this function the volume of the buzzer accompany- French, Dutch, Polish.
Page 173 Indication) This function may be used to adjust the volume of the beep accompanying the buttons. MENU, UP This function will only be displayed after a FIAT Group DOWN buttons can be adjusted according to 8 Automobiles dealer has deactivated the S.B.R. system.
Page 174 172 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Briefly press the MENU button to go back to the menu GSI Shift Up screen, or press and hold the button (approximately With this function active, the boost gauge will display a one second) to go back to the main screen without shift up message and up arrow at the appropriate time of storing the settings.
Page 175 UNDERSTANDING YOUR INSTRUMENT PANEL 173 Daytime Running Lamps (DRL) Exit Menu This function may be used to activate / deactivate the This function closes the initial menu screen. Daytime Running Lamps. Briefly press the MENU button to go back to the main Proceed as follows to switch this function on or off: screen.
Page 176: Sales Code (Rab) Radio
174 UNDERSTANDING YOUR INSTRUMENT PANEL If the radio has BLUE&ME™, refer to the appropriate SALES CODE (RAB) RADIO “BLUE&ME™ User’s Manual” for further information. The instructions for use are given below and we recom- mend you to read them carefully. Suggestions Road Safety Please, learn how to use all different radio functions (e.g.
Page 177 UNDERSTANDING YOUR INSTRUMENT PANEL 175 • Clean every CD thoroughly removing any finger WARNING! marks or dust using a soft cloth. Hold CDs by the outside and clean them from the middle outwards. Having the volume turned up high can cause the driver to not be able to hear important traffic sounds, •...
Page 178: Technical Specifications
176 UNDERSTANDING YOUR INSTRUMENT PANEL • The use of original CD media is required for the best • The CD player is capable of reading most compression quality audio production. Correct operation is not systems currently in use, following the development of guaranteed when CD-R/RW media are used that were these systems, the reading of all compression formats not correctly burned and/or with a maximum capacity...
Page 179: Quick Guide
UNDERSTANDING YOUR INSTRUMENT PANEL 177 With Alpine Premium Audio system (if equipped): • An amplifier in the trunk on the right-hand side panel. • Two 165 mm diameter midwoofer speakers. • Antenna on the car roof. • Two 11 mm tweeter speakers in the front pillars. •...
Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL BUTTON GENERAL FUNCTIONS MODE MEDIA CD/AUX/Media Player (if Short repeated button press equipped and present) source selection BUTTON GENERAL FUNCTIONS MODE (Mute/Pause Button) Volume activation/deactivation Short button press (Mute/Pause) AUDIO Audio adjustments: low tones Menu activation: short button press (BASS), high tones (TREBLE), Adjustment type selection: press left/right balance (BALANCE),...
Page 181 UNDERSTANDING YOUR INSTRUMENT PANEL 179 BUTTON GENERAL FUNCTIONS MODE MENU Advanced functions adjustment Menu activation: short button press Adjustment type selection: press Adjustment of values: press +Vol/–Vol Volume adjustment Press + button: volume increase Press – button: volume decrease BUTTON RADIO FUNCTIONS MODE Radio Station Search:...
Page 182: General Information
180 UNDERSTANDING YOUR INSTRUMENT PANEL BUTTON CD FUNCTIONS MODE CD ejection Short button press Previous/next track play Short button press CD track fast forward/rewind Long button press Previous/next folder play (for CD- Short button press MP3) • Manual storing of 25 stations (base radio) and 40 General Information stations (if equipped with Satellite): 15 on FM band (5 The radio offers the following functions:...
Page 183 UNDERSTANDING YOUR INSTRUMENT PANEL 181 CD Section CD/MP3 Section • Track selection (forward/backward) • MP3-Info function (ID3-TAG) • Fast forward/rewind through tracks • Folder selection (previous/next) • CD Display function: display of track number and on • Track selection (forward/backward) mp3 discs (song title, artist) and time elapsed since •...
Page 184: Functions And Adjustments
182 UNDERSTANDING YOUR INSTRUMENT PANEL • Separate bass/treble tone adjustment • AM, FM and Satellite Bands (if equipped) • Right/left channel balancing Selecting The CD Function By briefly pressing the MEDIA button, the CD audio • Front/rear fader source can be selected (only if a CD is loaded). Functions And Adjustments Volume Adjustment Turning The Car Radio On...
Page 185 UNDERSTANDING YOUR INSTRUMENT PANEL 183 When the volume level is changed using the dedicated The functions managed by the Audio Menu are: controls, the Mute function is deactivated and the vol- • BASS (Bass adjustment) ume is adjusted to the new level selected. •...
Page 186 184 UNDERSTANDING YOUR INSTRUMENT PANEL Tone Adjustment 3. Press the button to increase the sound from the left speakers or the button to increase the sound Proceed as follows: from the right speakers. 1. Press AUDIO button. By pressing the buttons briefly, the levels will 2.
Page 187 UNDERSTANDING YOUR INSTRUMENT PANEL 185 By pressing the buttons briefly, the levels will Preset/User/Classic/Rock/Jazz Functions — If change progressively. By pressing them down longer, Equipped the levels will change quickly. The built-in equalizer can be activated/deactivated. When the equalizer function is off, the audio settings can Select the value “0”...
Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL • “Jazz” (equalizer preset for optimal jazz music sound) 6. To store the setting, press the MENU or AUDIO buttons. When one of the equalizer adjustments is activated the Menu wording “EQ” lights up. MENU Button Functions User EQ Settings Function —...
Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 • Sat ID • Low: function activated (low sensitivity) • SiriusXM Telephone Number • High: function activated (high sensitivity) • System Reset On Volume Limit This function makes it possible to activate/deactivate the • Speed Volume maximum volume limit when turning the radio on.
Page 190 188 UNDERSTANDING YOUR INSTRUMENT PANEL • “On volume limit: off” – The radio will come on at the The chosen mode appears on the display: same volume as before it was switched off. The • “Radio off: 00 min” — The radio turns off in connection volume level can be between 0 and 40.
Page 191: Radio
UNDERSTANDING YOUR INSTRUMENT PANEL 189 Each time the button is pressed the following bands are Radio selected cyclically: (Tuner) Introduction • AM, FM or SAT (if equipped) When the car radio is turned on, the last function that was selected before turning it off (Radio, CD, CD MP3, Each band is highlighted by the corresponding wordings AUX) is activated.
Page 192: Siriusxm Satellite Radio - If Equipped
190 UNDERSTANDING YOUR INSTRUMENT PANEL By pressing the preset button for more than 2 seconds, the desired direction. If the button is pressed the tuned station will be stored. Pressing the A-B-C longer, the fast search starts and then stops when the button will change between the preset memory group in button is released.
Page 193 UNDERSTANDING YOUR INSTRUMENT PANEL 191 SiriusXM Satellite Radio Conditions available at sirius.com/service terms. Siri- usXM Radio U.S. service only available to those at least With over 130 channels, SiriusXM Satellite Radio brings 18 years of age in the 48 contiguous United States, D.C., you more of what you love.
Page 194 New vehicle purchasers or lessees will receive a free CAUTION! limited time subscription to SiriusXM Satellite Radio Neither SIRIUS nor FIAT is responsible for any with their radio. Following expiration of the free services, errors in accuracies in the SIRIUS data services or its it will be necessary to access the information on the use in vehicles.
Page 195: Cd Player
• Load a CD with the equipment switched on. The first The following are instructions for retrieving the Electronic Serial Number (ESN) from FIAT 500 NAFTA model radios: track will start to play. To retrieve the ESN of SIRIUS Satellite Receiver Module tune to Channel 0.
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL It is advisable to use original CDs to ensure optimal Press the button with the radio turned on, to playing. If CD-R/RWs are used, we recommend using activate the motorized CD ejection system. After ejec- good quality media that are burned at the slowest speed tion, the last audio source listened to before playing possible.
Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 A CD which cannot be read will not be ejected until these If the track has been played for more than 3 seconds, functions are over. At the end, with the CD mode pressing the button, starts the track again from the activated, the display will show the wording “CD Disc beginning.
Page 198: Cd Mp3 Player
196 UNDERSTANDING YOUR INSTRUMENT PANEL The specifications and operating conditions for playing CD MP3 Player MP3 files are the following: Introduction • The CD-ROMs used should be burned in accordance This chapter describes the operation of the CD MP3 with ISO standard 9660. player.
Page 199 UNDERSTANDING YOUR INSTRUMENT PANEL 197 Selecting MP3 Sessions With Hybrid Discs When one of the ID3-TAG pieces of information is chosen to be displayed (Title, Artist, Album) and this informa- If a hybrid disc is inserted (Mixed Mode, Enhanced, tion has not been recorded for the track played, the text CD-Extra) also containing MP3 files, the radio automati- UNKNOWN will be displayed for that field.
Page 200: Troubleshooting
198 UNDERSTANDING YOUR INSTRUMENT PANEL Structure Of The Folders Source Can Not Be Selected The radio with MP3 player: Nothing has been loaded. Load the CD or the MP3 CD to be listened to. • Recognizes only the folders that effectively contain MP3 format files.
Page 201: Ipod®/Usb/Media Player Control - If
UNDERSTANDING YOUR INSTRUMENT PANEL 199 MP3 File Reading Personal/Portable Navigation Device (PND) — If Equipped Track Skips While Playing Mp3 Files: A Personal/Portable Navigation Device (PND) is avail- The CD is scratched or dirty. able as optional equipment for this vehicle, refer to the The Duration Of The Mp3 Tracks Is Not Correctly Navigation User Guide for further information.
Page 202: Steering Wheel Audio Controls
200 UNDERSTANDING YOUR INSTRUMENT PANEL STEERING WHEEL AUDIO CONTROLS The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. 1 — iPod® Or External USB Device Holder 2 —...
Page 203: Radio Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 201 The right-hand control is a rocker-type switch with a Radio Operation pushbutton in the center and controls the volume and Pressing the top of the switch will “Seek” up for the next mode of the sound system. Pressing the top of the rocker listenable station and pressing the bottom of the switch switch will increase the volume, and pressing the bottom will “Seek”...
Page 204: Operating Instructions - Hands-Free Phone (If Equipped)
202 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Do not use solvents such as benzene, thinner, cleaners, Operating Instructions — Hands-Free Phone (If or anti-static sprays. Equipped) Refer to the appropriate Blue&Me™ User’s Manual for 5. Store the disc in its case after playing. further information.
Page 205: Radio Operation And Mobile Phones
UNDERSTANDING YOUR INSTRUMENT PANEL 203 RADIO OPERATION AND MOBILE PHONES Manual Heating And Air Conditioning Under certain conditions, the mobile phone being on in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the mobile phone antenna.
Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Temperature Control NOTE: • Continuous use of the Recirculation mode may make Rotate this control to regulate the temperature of the air the inside air stuffy and window fogging may occur. inside the passenger compartment. Rotating the dial to Extended use of this mode is not recommended.
Page 207 UNDERSTANDING YOUR INSTRUMENT PANEL 205 4. Mode Control • Bi-Level Air is directed through the panel and floor Rotate this control to change the system between Modes outlets. (Panel, Bi-Level, Floor, Mix, Defrost). • Floor • Panel Air is directed through the floor outlets with a Air is directed through the outlets in the small amount flowing through the defrost and instrument panel.
Page 208 206 UNDERSTANDING YOUR INSTRUMENT PANEL • Defrost 5. A/C Button Air is directed through the windshield and Press this button to engage the Air Conditioning. A light side window demister outlets. Use this mode will illuminate when the Air Conditioning system is with maximum blower and temperature settings for engaged.
Page 209: Operating Tips Chart
UNDERSTANDING YOUR INSTRUMENT PANEL 207 Operating Tips Chart...
Page 210: Automatic Temperature Control (Atc) - If Equipped
208 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control (ATC) — If Equipped • The Automatic Temperature Control (ATC) allows the driver to select individual comfort settings. • The system provides set-and-forget operation for op- timum comfort and convenience. • The system can be controlled manually, if desired. The ATC system automatically maintains the interior comfort level desired by the driver and passenger.
Page 211 UNDERSTANDING YOUR INSTRUMENT PANEL 209 2. A/C Button reducing moisture on the windshield. Performing this function will cause the ATC to switch into manual mode. Press and release to change the current Air Conditioning 6. Front Defrost (A/C) setting. Performing this function will cause the ATC to switch into manual mode.
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The center instrument panel outlets can be aimed NOTE: so that they are directed toward the rear seat passengers • When in Defrost mode, the Recirculation button will for maximum airflow to the rear. flash if pressed.
Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 3. When the system is set up for your comfort level, it is on low until the engine warms up. The blower will not necessary to change the settings. You will experi- increase in speed and transition into AUTO mode. ence the greatest efficiency by simply allowing the Manual Operation system to function automatically.
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL up button and decreases when you press or hold the Floor Mode blower control down button. Air comes from the floor outlets. A slight amount The blower fan speed can be set to any fixed speed by of air is directed through the defrost and side pressing the blower control up or down buttons.
Page 215 UNDERSTANDING YOUR INSTRUMENT PANEL 213 Defrost Mode Air Conditioning (A/C) The Air Conditioning (A/C) button allows the operator Air comes from the windshield and side window to manually activate or deactivate the air conditioning demister outlets. Use Defrost mode with maxi- system.
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation Control NOTE: In cold weather, use of Recirculation mode may lead to excessive window fogging. The recirculation feature may be unavailable (indicator light shall blink) if When outside air contains smoke, odors, or conditions exist that could create fogging on the inside of high humidity, or if rapid cooling is desired, the windshield.
Page 217: Operating Tips Chart
UNDERSTANDING YOUR INSTRUMENT PANEL 215 Operating Tips Chart...
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Regular cleaning of the inside of the windows with a non-filming cleaning solution (vinegar and water works Windows will fog on the inside when the humidity inside very well) will help prevent contaminates (cigarette the vehicle is high.
Page 219 UNDERSTANDING YOUR INSTRUMENT PANEL 217 Summer Operation Vacation Storage Anytime you store your vehicle, or keep it out of service NOTE: In some cases during high temperature opera- (i.e., vacation) for two weeks or more, run the air tion, the air conditioning system performance may be conditioning system at idle for about five minutes in the reduced.
Page 221 STARTING AND OPERATING CONTENTS STARTING PROCEDURES ....222 ▫ Recommended Shift Speeds ....226 ▫...
Page 222 220 STARTING AND OPERATING SPORT MODE ......234 ▫ Tire Identification Number (TIN)...247 BRAKE SYSTEM .
Page 223 STARTING AND OPERATING 221 ▫ Tire Spinning ......259 ▫ E-85 Usage In Non-Flex Fuel Vehicles ..271 ▫...
Page 224: Starting Procedures
222 STARTING AND OPERATING STARTING PROCEDURES Manual Transmission Before starting your vehicle, adjust your seat, adjust both Apply the parking brake, place the shift lever in NEU- inside and outside mirrors, and fasten your seat belts. TRAL, and press the clutch pedal before starting the vehicle.
Page 225: Cold Weather Operation
STARTING AND OPERATING 223 Cold Weather Operation CAUTION! To prevent possible engine damage while starting at low Use of the recommended SAE 5W-40 synthetic en- temperatures, this vehicle will inhibit engine cranking gine oil and adhering to the prescribed oil change when the ambient temperature is less than –22°...
Page 226: If Engine Fails To Start
224 STARTING AND OPERATING 3. If the engine fails to start within 10 seconds, place the CAUTION! ignition to the STOP (OFF/LOCK) position, wait 5 seconds to allow the starter to cool, then repeat the • Do not attempt to push or tow your vehicle to get it Extended Park Starting procedure.
Page 227: Manual Transmission
STARTING AND OPERATING 225 shut off to circulate coolant through the turbocharger. Although the pump is rubber-mounted for quiet opera- tion, it is normal to hear it running during this time. MANUAL TRANSMISSION Five-Speed Manual Transmission WARNING! You or others could be injured if you leave the vehicle unattended without having the parking brake fully applied.
Page 228: Recommended Shift Speeds
226 STARTING AND OPERATING Use each gear in numerical order; do not skip a gear. Be Recommended Shift Speeds sure the transmission is in first gear, not third, when To use your manual transmission for optimal fuel starting from a standing position. Damage to the clutch economy, it should be upshifted as listed in the following can result from starting in third gear.
Page 229: Downshifting
STARTING AND OPERATING 227 When turning a corner or driving up a steep grade, Downshifting downshift early so that the engine will not be overbur- Proper downshifting will improve fuel economy and dened. prolong engine life. DRIVING ON SLIPPERY SURFACES CAUTION! Acceleration If you skip a gear while downshifting or downshift...
Page 230: Traction
228 STARTING AND OPERATING 4. Keep tires properly inflated. WARNING! (Continued) 5. Maintain sufficient distance between your vehicle and and possibly have a collision. Accelerate slowly and the vehicle in front of you to avoid a collision in a carefully whenever there is likely to be poor traction sudden stop.
Page 231: Shallow Standing Water
STARTING AND OPERATING 229 WARNING! (Continued) CAUTION! (Continued) Furthermore, flowing and/or rising water can carry • Determine the condition of the road or the path your vehicle away swiftly. Failure to follow this that is under water and if there are any obstacles in warning may result in injuries that are serious or the way before driving through the standing water.
Page 232: Power Steering
230 STARTING AND OPERATING CAUTION! (Continued) WARNING! (Continued) • Getting water inside your vehicle’s engine can • Failure to follow these warnings may result in cause it to lock up and stall out, and cause serious injuries that are serious or fatal to you, your pas- internal damage to the engine.
Page 233 STARTING AND OPERATING 231 Refer to “Electronic Vehicle Information (EVIC)” in “Un- WARNING! derstanding Your Instrument Panel” for further informa- tion. Continued operation with reduced or no power steer- ing assist could pose a safety risk to yourself and If the Steering icon is displayed and the “SERVICE others.
Page 234: Parking Brake
232 STARTING AND OPERATING PARKING BRAKE Before leaving the vehicle, make sure that the parking brake is fully applied. Also, be certain to leave manual transmission in REVERSE or first gear. The parking brake lever is located in the center console. To apply the parking brake, pull the lever up as firmly as possible.
Page 235 STARTING AND OPERATING 233 When parking on a hill, it is important to turn the front WARNING! (Continued) wheels toward the curb on a downhill grade and away • Do not leave the key fob in or near the vehicle or in from the curb on an uphill grade.
Page 236: Sport Mode
234 STARTING AND OPERATING CAUTION! If the Brake Warning Light remains on with the parking brake released, a brake system malfunction is indicated. Have the brake system serviced by an authorized dealer immediately. SPORT MODE In Sport mode, the engine is more responsive to the throttle pedal, and provides more maximum torque by increasing turbo boost pressure.
Page 237: Brake System
STARTING AND OPERATING 235 BRAKE SYSTEM Four-Wheel Anti-Lock Brake System (ABS) In the event power assist is lost for any reason (for The Four-Wheel ABS is designed to aid the driver in example; repeated brake applications with the engine maintaining vehicle control under adverse braking con- off), the brakes will still function.
Page 238: Electronic Brake Control System
236 STARTING AND OPERATING When you are in a severe braking condition involving the WARNING! use of the ABS, you will experience some pedal drop as the vehicle comes to a stop. This is the result of the • Pumping the Anti-Lock Brakes will diminish their system reverting to the base brake system.
Page 239: Anti-Lock Brake System (Abs)
STARTING AND OPERATING 237 “pump” the brakes). Do not reduce brake pedal pressure Anti-Lock Brake System (ABS) unless braking is no longer desired. Once the brake pedal This system aids the driver in maintaining vehicle control is released, the BAS is deactivated. under adverse braking conditions.
Page 240: Traction Control System (Tcs)
238 STARTING AND OPERATING the level of brake pressure the driver applied for a short Traction Control System (TCS) period of time after the driver takes his foot off the brake This system monitors the amount of wheel spin of each of pedal.
Page 241: Electronic Stability Control (Esc)
STARTING AND OPERATING 239 facing uphill is in forward gear; vehicle backing uphill Electronic Stability Control (ESC) is in REVERSE gear). This system enhances directional control and stability of the vehicle under various driving conditions. ESC cor- WARNING! rects for oversteering or understeering of the vehicle by applying the brake of the appropriate wheel to assist in There may be situations on minor hills with a loaded counteracting the oversteering or understeering condi-...
Page 242 240 STARTING AND OPERATING WARNING! The Electronic Stability Control System (ESC) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ESC cannot prevent all accidents, including those resulting from exces- sive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 243 STARTING AND OPERATING 241 ESC Operating Modes To turn ESC on again, momentarily press the switch again. This will restore the normal ESC On mode of The ESC system has three available operating modes. operation. Full On WARNING! This is the normal operating mode for ESC. Whenever the vehicle is started, the ESC system will be in On mode.
Page 244: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
242 STARTING AND OPERATING section. To enter the “Full Off” mode, depress and hold ESC Activation/Malfunction Indicator Light And the ESC OFF switch for five seconds. After five seconds, ESC OFF Indicator Light the ESC OFF Indicator Light will illuminate, and the “ESC OFF”...
Page 245: Tire Safety Information
STARTING AND OPERATING 243 Malfunction Indicator Light begins to flash during accel- TIRE SAFETY INFORMATION eration, ease up on the accelerator and apply as little Tire Markings throttle as possible. Be sure to adapt your speed and driving to the prevailing road conditions. NOTE: •...
Page 246 244 STARTING AND OPERATING NOTE: • Temporary spare tires are high-pressure compact spares designed for temporary emergency use only. • P (Passenger) - Metric tire sizing is based on U.S. Tires designed to this standard have the letter “T” or design standards.
Page 247 STARTING AND OPERATING 245 Tire Sizing Chart EXAMPLE: Size Designation: P = Passenger car tire size based on U.S. design standards ..blank..= Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T or S = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 248 246 STARTING AND OPERATING EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 249: Tire Identification Number (Tin)
STARTING AND OPERATING 247 EXAMPLE: Maximum Load— Maximum load indicates the maximum load this tire is designed to carry Maximum Pressure— Maximum pressure indicates the maximum permissible cold tire inflation pressure for this tire Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side.
Page 250 248 STARTING AND OPERATING EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation — This symbol certifies that the tire is in compliance with the U.S. Department of Transportation tire safety standards and is approved for highway use MA = Code representing the tire manufacturing location (two digits) L9 = Code representing the tire size (two digits) ABCD = Code used by the tire manufacturer (one to four digits)
Page 251: Tire Terminology And Definitions
STARTING AND OPERATING 249 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 252: Tire Loading And Tire Pressure
250 STARTING AND OPERATING Tire And Loading Information Placard Tire Loading And Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire And Loading Information Placard This placard tells you important information about the: 1.
Page 253 STARTING AND OPERATING 251 3. Tire size designed for your vehicle. To determine the maximum loading conditions of your vehicle, locate the statement “The combined weight of 4. Cold tire inflation pressures for the front, rear, and occupants and cargo should never exceed XXX lbs or spare tires.
Page 254 252 STARTING AND OPERATING 4. The resulting figure equals the available amount of NOTE: cargo and luggage load capacity. For example, if • If your vehicle will be towing a trailer, load from your “XXX” amount equals 1,400 lbs (635 kg) and there will trailer will be transferred to your vehicle.
Page 255 STARTING AND OPERATING 253...
Page 256: Tires - General Information
254 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 257: Tire Inflation Pressures
STARTING AND OPERATING 255 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the vehicle driver’s side B-Pillar. to the other can cause the vehicle to drift to the right or left.
Page 258: Tire Pressures For High Speed Operation
256 STARTING AND OPERATING defined as the tire pressure after the vehicle has not been Tire pressure may increase from 2 to 6 psi (13 to 40 kPa) driven for at least three hours, or driven less than 1 mile during operation.
Page 259: Radial Ply Tires
STARTING AND OPERATING 257 Tire Repair WARNING! If your tire becomes damaged, it may be repaired if it High speed driving with your vehicle under maxi- meets the following criteria: mum load is dangerous. The added strain on your • The tire has not been driven on when flat. tires could cause them to fail.
Page 260: All Season Tires - If Equipped
258 STARTING AND OPERATING Snow tires generally have lower speed ratings than what All Season Tires — If Equipped was originally equipped with your vehicle and should All Season tires provide traction for all seasons (spring, not be operated at sustained speeds over 75 mph summer, fall and winter).
Page 261: Spare Tire Matching Original Equipped Tire And Wheel - If Equipped
STARTING AND OPERATING 259 driving conditions. For more information, contact a au- Tire Spinning thorized dealer. Summer tires do not contain the all When stuck in mud, sand, snow, or ice conditions, do not season designation or mountain/snowflake symbol on spin your vehicle’s wheels above 30 mph (48 km/h) or the tire sidewall.
Page 262: Tread Wear Indicators
260 STARTING AND OPERATING These indicators are molded into the bottom of the tread Tread Wear Indicators grooves. They will appear as bands when the tread depth Tread wear indicators are in the original equipment tires becomes 1/16 in (2 mm). When the tread is worn to the to help you in determining when your tires should be tread wear indicators, the tire should be replaced.
Page 263: Replacement Tires
STARTING AND OPERATING 261 Information placard or the Vehicle Certification Label for WARNING! the size designation of your tire. The Load Index and Speed Symbol for your tire will be found on the original Tires and the spare tire should be replaced after six equipment tire sidewall.
Page 264: Tire Chains (Traction Devices)
262 STARTING AND OPERATING WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 265: Tire Rotation Recommendations
STARTING AND OPERATING 263 These effects can be reduced by timely rotation of tires. CAUTION! The benefits of rotation are especially worthwhile with aggressive tread designs such as those on all season type Damage to the vehicle may result if tire chains are tires.
Page 266: Tire Pressure Monitoring System (Tpms)
264 STARTING AND OPERATING The suggested rotation method is the “rearward cross” TIRE PRESSURE MONITORING SYSTEM (TPMS) shown in the following diagram. This rotation pattern The Tire Pressure Monitor System (TPMS) will warn the does not apply to some directional tires that must not be driver of a low tire pressure based on the vehicle recom- reversed.
Page 267 STARTING AND OPERATING 265 also increase as the vehicle is driven - this is normal and driven for up to 20 minutes above 15 mph (24 km/h) in there should be no adjustment for this increased pres- order for the TPMS to receive this information. sure.
Page 268 266 STARTING AND OPERATING NOTE: CAUTION! • The TPMS is not intended to replace normal tire care • The TPMS has been optimized for the original and maintenance, or to provide warning of a tire equipment tires and wheels. TPMS pressures and failure or condition.
Page 269: Base System
STARTING AND OPERATING 267 • Seasonal temperature changes will affect tire pressure, The TPMS consists of the following components: and the TPMS will monitor the actual tire pressure in • Receiver Module the tire. • Four Tire Pressure Monitoring Sensors Base System •...
Page 270 268 STARTING AND OPERATING vehicle may need to be driven for up to 20 minutes above 3. Snow or ice around the wheels or wheel housings. 15 mph (24 km/h) to receive this information. 4. Using tire chains on the vehicle. Check TPMS Warnings 5.
Page 271: General Information
STARTING AND OPERATING 269 Monitoring Telltale Light will flash on and off for 75 Enhanced TPM System seconds and then remain on solid and the Tire When the vehicle is equipped with an enhanced TPM Pressure Monitoring Unavailable message will be system, the driver can view text messages showing the displayed.
Page 272: Fuel Requirements
270 STARTING AND OPERATING The tire pressure sensors are covered under one of the Light spark knock at low engine speeds is not harmful to following licenses: your engine. However, continued heavy spark knock at high speeds can cause damage and immediate service is United States MRXC4W4MA4 required.
Page 273: Gasoline/Oxygenate Blends
STARTING AND OPERATING 271 The manufacturer supports the use of reformulated gaso- Problems that result from using methanol/gasoline lines. Properly blended reformulated gasolines will pro- blends are not the responsibility of the manufacturer. vide excellent performance and durability of engine and While MTBE is an oxygenate made from Methanol, it fuel system components.
Page 274: Mmt In Gasoline
272 STARTING AND OPERATING To fix a Non-FFV vehicle inadvertently fueled once with without MMT be used in your vehicle. The MMT content E-85 perform the following: of gasoline may not be indicated on the gasoline pump, therefore, you should ask your gasoline retailer whether •...
Page 275: Fuel System Cautions
STARTING AND OPERATING 273 Fuel System Cautions CAUTION! (Continued) • The use of fuel additives, which are now being CAUTION! sold as octane enhancers, is not recommended. Follow these guidelines to maintain your vehicle’s Most of these products contain high concentrations performance: of methanol.
Page 276: Carbon Monoxide Warnings
274 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! (Continued) • Guard against carbon monoxide with proper main- WARNING! tenance. Have the exhaust system inspected every Carbon monoxide (CO) in exhaust gases is deadly. time the vehicle is raised. Have any abnormal Follow the precautions below to prevent carbon conditions repaired promptly.
Page 277: Adding Fuel
STARTING AND OPERATING 275 ADDING FUEL CAUTION! Fuel Filler Cap (Gas Cap) • Damage to the fuel system or emission control The gas cap is located on the passenger side of the system could result from using an improper fuel vehicle.
Page 278: Loose Fuel Filler Cap Message
276 STARTING AND OPERATING Loose Fuel Filler Cap Message WARNING! (Continued) After fuel has been added, the vehicle diagnostic system • Never add fuel when the engine is running. It may can determine if the fuel filler cap is possibly loose, cause the MIL to turn on and could cause a fire.
Page 279: Recreational Towing (Behind Motorhome, Etc.)
STARTING AND OPERATING 277 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Ground Manual Transmission Flat Tow NONE Transmission in NEUTRAL Dolly Tow Front Rear NOT ALLOWED On Trailer NOTE: Vehicles equipped with manual transmissions CAUTION! may be recreationally towed (flat towed) at any legal highway speed, for any distance, if the manual transmis-...
Page 281 WHAT TO DO IN EMERGENCIES CONTENTS HAZARD WARNING FLASHERS ...280 JACKING AND TIRE CHANGING — IF EQUIPPED ......293 IF YOUR ENGINE OVERHEATS .
Page 282: Hazard Warning Flashers
280 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS IF YOUR ENGINE OVERHEATS The Hazard Warning flasher switch is located on the In any of the following situations, you can reduce the instrument panel below the radio. potential for overheating by taking the appropriate ac- tion.
Page 283: Tirefit Kit - If Equipped
WHAT TO DO IN EMERGENCIES 281 CAUTION! WARNING! (Continued) to cool. Never try to open a cooling system pressure Driving with a hot cooling system could damage cap when the radiator or coolant bottle is hot. your vehicle. If the pointer rises to the H (red) mark, the instrument cluster will sound a chime.
Page 284: Tirefit Storage
282 WHAT TO DO IN EMERGENCIES TIREFIT Storage TIREFIT Kit Components And Operation The TIREFIT kit is located under the front driver’s seat. TIREFIT Components TIREFIT Kit Location 1. Sealant Bottle 2. Deflation Button 3. Pressure Gauge...
Page 285 WHAT TO DO IN EMERGENCIES 283 4. Power Button Selecting Sealant Mode 5. Mode Select Knob Push in the Mode Select Knob (5) and turn to this position to inject the TIRE- 6. Sealant Hose (Clear) FIT Sealant and to inflate the tire. Use 7.
Page 286: Tirefit Usage Precautions
284 WHAT TO DO IN EMERGENCIES the vehicle or tire and wheel components. Once the TIREFIT Usage Precautions sealant dries, it can easily be peeled off and properly • Using the TIREFIT sealant may cause the Tire Pressure discarded. Monitoring System (TPMS) to become inoperable. It is recommended that you take your vehicle to an autho- •...
Page 287 WHAT TO DO IN EMERGENCIES 285 WARNING! WARNING! (Continued) • Keep TIREFIT away from open flames or heat • Do not attempt to seal a tire on the side of the source. vehicle closest to traffic. Pull far enough off the •...
Page 288: Sealing A Tire With Tirefit
286 WHAT TO DO IN EMERGENCIES kit when injecting the sealant into the deflated tire and WARNING! (Continued) running the air pump. Move the vehicle as necessary • TIREFIT Sealant solution contains latex. In case of to place the valve stem in this position before proceed- an allergic reaction or rash, consult a physician ing.
Page 289 WHAT TO DO IN EMERGENCIES 287 4. Remove the cap from the valve stem and then screw NOTE: Sealant may leak out through the puncture in the the fitting at the end of the Sealant Hose (6) onto the tire. valve stem.
Page 290 288 WHAT TO DO IN EMERGENCIES NOTE: If the Mode Select Knob (5) is on Air Mode and If the tire does not inflate to at least 26 psi (1.8 Bar) the pump is operating, air will dispense from the Air pressure within 15 minutes: Pump Hose (7) only, not the Sealant Hose (6).
Page 291 WHAT TO DO IN EMERGENCIES 289 CAUTION! WARNING! TIREFIT is not a permanent flat tire repair. Have the • The metal end fitting from Power Plug (8) may get tire inspected and repaired or replaced after using hot after use, so it should be handled carefully. TIREFIT.
Page 292 290 WHAT TO DO IN EMERGENCIES 3. Uncoil the Air Pump Hose (7) (black in color) and 2. Disconnect the TIREFIT kit from the valve stem, screw the fitting at the end of hose (7) onto the valve reinstall the cap on the valve stem and unplug from 12 stem.
Page 293: Wheel And Tire Torque Specifications
WHAT TO DO IN EMERGENCIES 291 (F) Sealant Bottle And Hose Replacement: 6. Verify that the cap is installed on the fitting at the end of the Sealant Hose (6) and return the hose to its 1. Uncoil the Sealant Hose (6) (clear in color). storage area (located on the bottom of the air pump).
Page 294: Torque Specifications
292 WHAT TO DO IN EMERGENCIES Inspect the wheel mounting surface prior to mounting Torque Specifications the tire and remove any corrosion or loose particles. Lug Nut/Bolt Torque **Lug Nut/ Lug Nut/ Bolt Size Bolt Socket Size 66 Ft-Lbs (90 N·m) M12 x 1.25 17 mm Steel Wheels Only...
Page 295: Jacking And Tire Changing - If
WHAT TO DO IN EMERGENCIES 293 Tighten the lug nuts/bolts in a star pattern until each WARNING! nut/bolt has been tightened twice. To avoid the risk of forcing the vehicle off the jack, do not tighten the lug nuts fully until the vehicle has been lowered.
Page 296: Jack Location
294 WHAT TO DO IN EMERGENCIES Jack Location WARNING! (Continued) The jack and jack wrench tool are stowed in a bag under • Being under a jacked-up vehicle is dangerous. The the front driver’s seat. vehicle could slip off the jack and fall on you. You could be crushed.
Page 297: Preparations For Jacking
WHAT TO DO IN EMERGENCIES 295 5. Turn Off the ignition. Preparations For Jacking 1. Park the vehicle on a firm level surface, avoiding ice or slippery areas. Block both the front and rear of the wheel diagonally opposite the jacking WARNING! position.
Page 298: Jacking Instructions
296 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! (Continued) • Do not let anyone sit in the vehicle when it is on a WARNING! jack. Carefully follow these tire changing warnings to • Do not get under the vehicle when it is on a jack. If help prevent personal injury or damage to your you need to get under a raised vehicle, take it to a vehicle:...
Page 299 WHAT TO DO IN EMERGENCIES 297 NOTE: There are front and rear jacking locations on each side of the body (as indicated by the triangular lift point symbol on the sill molding). Jack Warning Label CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle.
Page 300 298 WHAT TO DO IN EMERGENCIES 3. Turn the jack screw to the left until the jack can be placed under the jacking location. Once the jack is positioned, turn the jack screw to the right until the jack head is properly engaged with the lift area closest to the wheel to be changed.
Page 301 WHAT TO DO IN EMERGENCIES 299 WARNING! WARNING! Raising the vehicle higher than necessary can make To avoid the risk of forcing the vehicle off the jack, the vehicle less stable. It could slip off the jack and do not fully tighten the wheel bolts until the vehicle hurt someone near it.
Page 302: Jump-Starting Procedure
300 WHAT TO DO IN EMERGENCIES correctly, have them checked with a torque wrench by NOTE: When using a portable battery booster pack, your authorized dealer or service station. follow the manufacturer’s operating instructions and precautions. 9. Disassemble the jack and tools and place them in the bag.
Page 303: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 301 Preparations For Jump-Start WARNING! The battery in your vehicle is located on the left side of • Take care to avoid the radiator cooling fan when- the engine compartment. ever the hood is raised. It can start anytime the ignition switch is ON.
Page 304: Jump-Starting Procedure
302 WHAT TO DO IN EMERGENCIES 1. Set the parking brake, shift the transmission into gear Jump-Starting Procedure and turn the ignition to OFF/LOCK. WARNING! 2. Turn off the heater, radio, and all unnecessary electri- cal accessories. Failure to follow this procedure could result in per- sonal injury or property damage due to battery ex- 3.
Page 305 WHAT TO DO IN EMERGENCIES 303 3. Connect the negative end (-) of the jumper cable to the 5. Start the engine in the vehicle that has the booster negative (-) post of the booster battery. battery, let the engine idle a few minutes, and then start the engine in the vehicle with the discharged 4.
Page 306: Freeing A Stuck Vehicle
304 WHAT TO DO IN EMERGENCIES If frequent jump-starting is required to start your vehicle, FREEING A STUCK VEHICLE you should have the battery and charging system in- If your vehicle becomes stuck in mud, sand or snow, it spected at your authorized dealer. can often be moved using a rocking motion.
Page 307 WHAT TO DO IN EMERGENCIES 305 NOTE: Press the ESC Off switch, to place the Electronic WARNING! Stability Control (ESC) system in Partial Off mode, before rocking the vehicle. Refer to “Electronic Brake Fast spinning tires can be dangerous. Forces gener- Control”...
Page 308: Towing A Disabled Vehicle
306 WHAT TO DO IN EMERGENCIES TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial wrecker service. Towing Condition Wheels OFF The Ground MANUAL TRANSMISSION Flat Tow NONE If transmission is operable: • Transmission in NEUTRAL •...
Page 309: Manual Transmission
WHAT TO DO IN EMERGENCIES 307 If you must use the accessories (wipers, defrosters, etc.) Manual Transmission while being towed, the ignition must be in the ON/RUN • Vehicle can be flat towed (all four wheels on the position, not the ACC position. ground) with the transmission in NEUTRAL.
Page 311 MAINTAINING YOUR VEHICLE CONTENTS ENGINE COMPARTMENT — 1.4L TURBO ..311 ▫ Maintenance-Free Battery ....319 ONBOARD DIAGNOSTIC SYSTEM — OBD II . .312 ▫ Air Conditioner Maintenance ... . .320 EMISSIONS INSPECTION AND MAINTENANCE ▫...
Page 312 310 MAINTAINING YOUR VEHICLE ▫ Appearance Care And Protection From ▫ Front Turn Signal, Parking And Daytime Running Corrosion ......338 Lamps .
Page 313: Engine Compartment - 1.4L Turbo
MAINTAINING YOUR VEHICLE 311 ENGINE COMPARTMENT — 1.4L TURBO 1 — Engine Coolant Reservoir 5 — Battery 2 — Engine Oil Dipstick 6 — Engine Oil Fill 3 — Brake Fluid Reservoir 7 — Washer Fluid Reservoir 4 — Front Distribution Unit (Fuses)
Page 314: Onboard Diagnostic System - Obd Ii
312 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors further damage to the emission control system. It the performance of the emissions, engine, and automatic could also affect fuel economy and driveability.
Page 315 MAINTAINING YOUR VEHICLE 313 NOTE: If you crank or start the engine, you will have to For states that require an Inspection and Mainte- start this test over. nance (I/M), this check verifies the “Malfunction Indicator Light (MIL)” is functioning and is not 2.
Page 316: Replacement Parts
314 MAINTAINING YOUR VEHICLE If your OBD II system is not ready, you should see your use of parts which are not quality-equivalent to genuine authorized dealer or repair facility. If your vehicle was parts for maintenance and repairs will not be covered by recently serviced or had a battery failure or replacement, the manufacturer’s warranty.
Page 317: Maintenance Procedures
MAINTAINING YOUR VEHICLE 315 WARNING! CAUTION! You can be badly injured working on or around a • Failure to properly maintain your vehicle or per- motor vehicle. Only do service work for which you form repairs and service when necessary could have the knowledge and the proper equipment.
Page 318: Engine Oil
316 MAINTAINING YOUR VEHICLE of the indicated range will result in the oil level at the full Engine Oil end of the indicator range. Checking Oil Level To assure proper engine lubrication, the engine oil must CAUTION! be maintained at the correct level. Check the oil level at Do not overfill the engine with oil.
Page 319 MAINTAINING YOUR VEHICLE 317 Engine Oil Selection engine oil filler cap location, refer to “Engine Compart- ment” in “Maintaining Your Vehicle” for further informa- For best performance and maximum protection for tur- tion. bocharged engines under all types of operating condi- tions, the manufacturer recommends synthetic engine Materials Added To Engine Oil oils that are API Certified and meet the requirements of...
Page 320: Engine Oil Filter
318 MAINTAINING YOUR VEHICLE Engine Oil Filter WARNING! The engine oil filter should be replaced with a new filter The air induction system (air cleaner, hoses, etc.) can at every engine oil change. provide a measure of protection in the case of engine Engine Oil Filter Selection backfire.
Page 321: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 319 Maintenance-Free Battery WARNING! (Continued) Your vehicle is equipped with a maintenance-free battery. • Battery gas is flammable and explosive. Keep You will never have to add water, nor is periodic main- flame or sparks away from the battery. Do not use tenance required.
Page 322: Air Conditioner Maintenance
320 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance CAUTION! For best possible performance, your air conditioner • It is essential when replacing the cables on the should be checked and serviced by an authorized dealer battery that the positive cable is attached to the at the start of each warm season.
Page 323 MAINTAINING YOUR VEHICLE 321 Refrigerant Recovery And Recycling WARNING! R-134a Air Conditioning Refrigerant is a hydrofluoro- • Use only refrigerants and compressor lubricants carbon (HFC) that is endorsed by the Environmental approved by the manufacturer for your air condi- Protection Agency and is an ozone-saving product. How- tioning system.
Page 324 322 MAINTAINING YOUR VEHICLE The A/C air filter is located in the fresh air inlet on the 2. Pull the console closeout cover rearward to disengage lower right of center console. Perform the following the front retaining tab and remove the cover. procedure to replace the filter: 1.
Page 325 MAINTAINING YOUR VEHICLE 323 Air Filter Cover Screw Locations A/C Air Filter 4. Remove the A/C air filter by pulling it straight out of 5. Install the A/C air filter with the air filter position the housing. Take note of the air filter position indica- indicators pointing in the same direction as removal.
Page 326: Body Lubrication
324 MAINTAINING YOUR VEHICLE be wiped clean to remove dust and grit; after lubricating CAUTION! excess oil and grease should be removed. Particular attention should also be given to hood latching compo- The A/C air filter is identified with an arrow to nents to ensure proper function.
Page 327 MAINTAINING YOUR VEHICLE 325 Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades. Always use washer fluid when using the wipers to remove salt or dirt from a dry windshield. Avoid using the wiper blades to remove frost or ice from the windshield.
Page 328: Adding Washer Fluid
326 MAINTAINING YOUR VEHICLE 3. Grab the bottom of the wiper blade and rotate it 4. Install the wiper blade pivot pin into the wiper blade forward to unsnap the blade pivot pin from the wiper holder at the end of the wiper arm, and firmly press blade holder.
Page 329: Exhaust System
MAINTAINING YOUR VEHICLE 327 exhaust system inspected each time the vehicle is raised WARNING! (Continued) for lubrication or oil change. Replace as required. must be exercised when filling or working around the washer solution. WARNING! Exhaust System • Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and The best protection against carbon monoxide entry into odorless.
Page 330 328 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure • The catalytic converter requires the use of un- proper catalyst operation and prevent possible catalyst leaded fuel only.
Page 331: Cooling System
MAINTAINING YOUR VEHICLE 329 To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in • When working near the radiator cooling fan, dis- motion.
Page 332 330 MAINTAINING YOUR VEHICLE Coolant Checks Refer to the “Maintenance Schedule” for the proper maintenance intervals. Check engine coolant (antifreeze) protection every 12 months (before the onset of freezing weather, where NOTE: Some vehicles require special tools to add cool- applicable).
Page 333 MAINTAINING YOUR VEHICLE 331 CAUTION! CAUTION! (Continued) • Do not use water alone or alcohol-based engine • Mixing of engine coolant (antifreeze) other than coolant (antifreeze) products. Do not use additional specified Organic Additive Technology (OAT) en- rust inhibitors or antirust products, as they may not gine coolant (antifreeze), may result in engine be compatible with the radiator engine coolant and damage and may decrease corrosion protection.
Page 334 332 MAINTAINING YOUR VEHICLE you use the same engine coolant (OAT coolant conform- (antifreeze) solution. The use of lower quality water ing to MS-12106) throughout the life of your vehicle. will reduce the amount of corrosion protection in the engine cooling system. Please review these recommendations for using Organic Additive Technology (OAT) engine coolant (antifreeze) Please note that it is the owner’s responsibility to main-...
Page 335 MAINTAINING YOUR VEHICLE 333 have a authorized dealer drain, flush, and refill with WARNING! OAT coolant (conforming to MS-12106) as soon as possible. • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety precaution. Cooling System Pressure Cap Never add engine coolant (antifreeze) when the The cap must be fully tightened to prevent loss of engine...
Page 336 334 MAINTAINING YOUR VEHICLE Disposal Of Used Engine Coolant As long as the engine operating temperature is satisfac- tory, the coolant bottle need only be checked once a Used ethylene glycol-based engine coolant (antifreeze) is month. a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal When additional engine coolant (antifreeze) is needed to rules for your community.
Page 337: Brake System
MAINTAINING YOUR VEHICLE 335 • Do not overfill the coolant expansion bottle. • Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the • Check the coolant freeze point in the radiator and in condenser clean.
Page 338 336 MAINTAINING YOUR VEHICLE when the pads are replaced. However, low fluid level WARNING! may be caused by a leak and a checkup may be needed. Riding the brakes can lead to brake failure and NOTE: If your vehicle is equipped with a manual trans- possibly a collision.
Page 339 MAINTAINING YOUR VEHICLE 337 WARNING! WARNING! (Continued) cause it to boil unexpectedly during hard or pro- • Use only manufacturer’s recommended brake longed braking, resulting in sudden brake failure. fluid. Refer to “Fluids, Lubricants, and Genuine This could result in a collision. Parts”...
Page 340: Manual Transmission
338 MAINTAINING YOUR VEHICLE Add fluid, if necessary, to maintain the proper level. CAUTION! Frequency Of Fluid Change Use of improper brake fluids will affect overall Under normal operating conditions, the fluid installed at clutch system performance. Improper brake fluids the factory will give satisfactory lubrication for the life of may damage the clutch system resulting in loss of the vehicle.
Page 341 MAINTAINING YOUR VEHICLE 339 hot or cold weather and other extreme conditions will Washing have an adverse effect on paint, metal trim, and under- • Wash your vehicle regularly. Always wash your ve- body protection. hicle in the shade using MOPAR® Car Wash, or a mild car wash soap, and rinse the panels completely with The following maintenance recommendations will enable clear water.
Page 342 340 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, CAUTION! touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • Do not use abrasive or strong cleaning materials such as steel wool or scouring powder that will •...
Page 343 MAINTAINING YOUR VEHICLE 341 Wheel And Wheel Trim Care CAUTION! • All wheels and wheel trim, especially aluminum and Do not use scouring pads, steel wool, a bristle brush, chrome plated wheels, should be cleaned regularly or metal polishes. Do not use oven cleaner. These with a mild soap and water to prevent corrosion.
Page 344 342 MAINTAINING YOUR VEHICLE • For tough stains, apply MOPAR® Total Clean, or a Your leather upholstery can be best preserved by regular mild soap solution to a clean, damp cloth and remove cleaning with a damp soft cloth. Small particles of dirt stain.
Page 345 MAINTAINING YOUR VEHICLE 343 Glass Surfaces CAUTION! All glass surfaces should be cleaned on a regular basis Do not use Alcohol and Alcohol-based and/or Keton with MOPAR® Glass Cleaner, or any commercial based cleaning products to clean leather seats, as household-type glass cleaner.
Page 346 344 MAINTAINING YOUR VEHICLE Instrument Panel Bezels 1. Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive CAUTION! cleaners. If soap is used, wipe clean with a clean damp rag.
Page 347: Fuses
MAINTAINING YOUR VEHICLE 345 FUSES Interior Fuses The interior fuse panel is part of the Body Control WARNING! Module (BCM) and is located on the driver’s side under the instrument panel. • When replacing a blown fuse, always use an appro- priate replacement fuse with the same amp rating as the original fuse.
Page 348 346 MAINTAINING YOUR VEHICLE Vehicle Fuse Cavity Mini Fuse Description Number 7.5 Amp Brown Right Low Beam 5 Amp Tan Front and Rear Ceiling Lights Trunk and Door Courtesy Lights 5 Amp Tan Instrument Panel Node 20 Amp Yellow Central Door Locking 10 Amp Red Diagnostic Socket, Car Radio, Climate Con- trol System...
Page 349 MAINTAINING YOUR VEHICLE 347 Vehicle Fuse Cavity Mini Fuse Description Number 5 Amp Tan Car Radio Switch, Climate Control System, Stop Light, Clutch 5 Amp Tan Stop Light Switch, Instrument Panel Node 5 Amp Tan Exterior Mirror, GPS, Electric Mirror, Parking Sensor 5 Amp Tan Ignition, Climate Control...
Page 350: Underhood Fuses
348 MAINTAINING YOUR VEHICLE Underhood Fuses The Front Distribution Unit is located on the right side of the engine compartment, next to the battery. To access the fuses, press the release tabs and remove the cover. Front Distribution Unit The ID number of the electrical component correspond- ing to each fuse can be found on the back of the cover.
Page 351 MAINTAINING YOUR VEHICLE 349 Cavity Maxi Fuse Mini Fuse Description 60 Amp Blue Body Controller 20 Amp Yellow Audio Amplifier 20 Amp Yellow Ignition Switch 40 Amp Orange Anti-Lock Brake Pump 70 Amp Tan Electric Power Steering 20 Amp Yellow Radiator Fan - Single Speed 30 Amp Green Radiator Fan - Low Speed...
Page 352 350 MAINTAINING YOUR VEHICLE Cavity Maxi Fuse Mini Fuse Description 7.5 Amp Brown Transmission 25 Amp White Powertrain (Multiair – If Equipped) 15 Amp Blue Powertrain 15 Amp Blue Powertrain 5 Amp Tan Powertrain (Multiair – If Equipped) 7.5 Amp Brown Air Conditioning 15 Amp Blue Heated Seats –...
Page 353: Vehicle Storage
MAINTAINING YOUR VEHICLE 351 Cavity Maxi Fuse Mini Fuse Description 30 Amp Blue (ATO) Rear Defroster 5 Amp Tan Rear Defroster 5 Amp Tan Heated Mirrors – If Equipped VEHICLE STORAGE REPLACEMENT BULBS If you are leaving your vehicle dormant for more than 21 Interior Bulbs days, you may want to take these steps to protect your Bulb Number...
Page 354: Bulb Replacement
352 MAINTAINING YOUR VEHICLE Exterior Bulbs Bulb Number Bulb Number Center High Mounted Front Low and High HIR2 Stop Lamp Beam Headlamp License Plate Lamps LED (See Authorized Front Parking/Daytime W21/5W dealer) Running Lamps NOTE: Numbers refer to commercial bulb types that Front Fog Lamps can be purchased from your authorized dealer.
Page 355: Headlamps Low Beam And High Beam
MAINTAINING YOUR VEHICLE 353 Headlamps Low Beam and High Beam 1. Remove the plastic cap from the back of the headlamp housing. 2. Rotate the bulb counter-clockwise. 3. Remove the bulb and replace as needed. 4. Install the bulb and rotate clockwise to lock in place. 5.
Page 356: Front Fog Lamps
354 MAINTAINING YOUR VEHICLE 6. Install the bulb into socket, and rotate bulb/socket Rear Tail, Stop, Backup And Turn Signal Lamps clockwise into lamp locking it in place. 1. Open the liftgate. 7. Reinstall the plastic cap. 2. Remove the two screws and remove the tail lamp assembly.
Page 357: Center High Mounted Stop Lamp (Chmsl)
MAINTAINING YOUR VEHICLE 355 3. Remove the four screws (using a T20 driver) and 2. Remove the center high mounted stop lamp assembly. separate the backplate from the lamp housing. 3. Disconnect the electric connector. 4. Remove the tail, stop, or turn signal bulbs by pushing 4.
Page 358: Fluid Capacities
356 MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 10.5 Gallons 40 Liters Engine Oil with Filter 1.4 Liter Turbo Engine 4 Quarts 3.8 Liters Cooling System 1.4 Liter Turbo Engine (MOPAR® Antifreeze/Engine Coolant 4.6 Quarts 4.4 Liters 10 Year/150,000 Mile Formula) FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component...
Page 359: Chassis
MAINTAINING YOUR VEHICLE 357 Component Fluid, Lubricant, or Genuine Part Engine Oil We recommend you use API Certified SAE 5W-40 Full Synthetic Engine Oil, meeting the requirements of Chrysler Material Standard MS-12991. Refer to your engine oil filler cap for correct SAE grade. Engine Oil Filter We recommend you use a MOPAR®...
Page 361: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS MAINTENANCE SCHEDULE ... . .360 ▫ Maintenance Chart.....362...
Page 362 360 MAINTENANCE SCHEDULES Severe Duty All Models MAINTENANCE SCHEDULE Your vehicle is equipped with an automatic oil change Change Engine Oil at 4000 miles (6,500 km) if the vehicle indicator system. The oil change indicator system will is operated in a dusty and off road environment. This remind you that it is time to take your vehicle in for type of vehicle use is considered Severe Duty scheduled maintenance.
Page 363 MAINTENANCE SCHEDULES 361 Required Maintenance Intervals. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Refer to the Maintenance Schedules on the following pages for required maintenance. • Inspect engine cooling system protection and hoses. At Every Oil Change Interval As Indicated By Oil •...
Page 364 362 MAINTENANCE SCHEDULES Maintenance Chart Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary. Inspect brake linings, replace if needed. Inspect parking brake function, adjust as neces- sary.
Page 365 MAINTENANCE SCHEDULES 363 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Maintenance Replace cabin/air conditioning filter. Clean and lube sun roof tracks. Replace engine air filter. Replace the spark plugs. ** Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first.
Page 366 364 MAINTENANCE SCHEDULES WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent me- chanic.
Page 367 TIRE QUALITY GRADES ....371 ▫ FIAT CUSTOMER CENTER ....367 ▫ Treadwear......372 ▫...
Page 368: Suggestions For Obtaining Service For Your Vehicle
366 IF YOU NEED CONSUMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE FOR Be Reasonable With Requests YOUR VEHICLE If you list a number of items and you must have your vehicle by the end of the day, discuss the situation with Prepare For The Appointment the service advisor and list the items in order of priority.
Page 369: Fiat Customer Center
• If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer. FIAT CANADA CUSTOMER CENTER They want to know if you need assistance. P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1–800–...
Page 370: Service Contract
368 IF YOU NEED CONSUMER ASSISTANCE (TTY) in the United States, can communicate with the Hotline at 1-800-521-9922 (Canadian residents, call (800) manufacturer by dialing 1–800–380–CHRY. 465–2001 English / (800) 387–9983 French). Canadian residents with hearing difficulties that require The manufacturer will not stand behind any service assistance can use the special needs relay service offered contract that is not the manufacturer’s service contract.
Page 371: Warranty Information
However, NHTSA cannot become involved in individual problems between you, your authorized See the Warranty Information Booklet, located on the dealer, and the manufacturer. DVD, for the terms and provisions of FIAT Group Automobiles warranties applicable to this vehicle and market.
Page 372: In Canada
Canada, Motor Vehicle Defect Investigations and diagnosing/troubleshooting, problem solving, maintain- Recalls at 1-800-333-0510 or go to http://www.tc.gc.ca/ ing, servicing, and repairing FIAT Group Automobiles roadsafety/ vehicles. A complete working knowledge of the vehicle, system, and/or components is written in straightforward...
Page 373: Department Of Transportation Uniform
The following tire grading categories were established by assistance of service and engineering specialists to ac- the National Highway Traffic Safety Administration. The quaint you with specific FIAT Group Automobiles ve- specific grade rating assigned by the tire’s manufacturer hicles. Included are starting, operating, emergency and...
Page 374: Treadwear
372 IF YOU NEED CONSUMER ASSISTANCE Treadwear Traction Grades The Treadwear grade is a comparative rating, based on The Traction grades, from highest to lowest, are AA, A, B, the wear rate of the tire when tested under controlled and C. These grades represent the tire’s ability to stop on conditions on a specified government test course.
Page 375: Temperature Grades
IF YOU NEED CONSUMER ASSISTANCE 373 Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, The temperature grade for this tire is established for representing the tire’s resistance to the generation of heat a tire that is properly inflated and not overloaded. and its ability to dissipate heat, when tested under Excessive speed, under-inflation, or excessive load- controlled conditions on a specified indoor laboratory...
Page 377 INDEX...
Page 378 376 INDEX Adding Engine Coolant (Antifreeze) ... .331 Antifreeze (Engine Coolant) ....330 Adding Fuel ......275 Capacities .
Page 379 INDEX 377 Brake, Parking ......232 Cellular Phone ......203 Brakes .
Page 380 378 INDEX Coolant (Antifreeze) ..... . .356 Diagnostic System, Onboard ....312 Cooling System.
Page 381 INDEX 379 Jacking .......293 Temperature Gauge ..... .153 Jump Starting .
Page 382 380 INDEX Fluid Leaks ......83 Fueling ....... .275 Fluids, Lubricants and Genuine Parts .
Page 383 INDEX 381 Headlights ......111 Instrument Panel Cover .....343 Cleaning .
Page 384 382 INDEX Latches ....... . .83 Malfunction Indicator (Check Engine) ..149 Hood .
Page 385 INDEX 383 Lug Nuts .......291 Monitor, Tire Pressure System ....264 Multi-Function Control Lever .
Page 386 384 INDEX Recommendation ..... . .317 Windows ......23 Viscosity .
Page 387 INDEX 385 Power Convertible Top Function ... . .16 Seat Belts ....... .81 Remote Sound System (Radio) Controls .
Page 388 386 INDEX Shoulder Belts ......29 Storage ....... .351 Side Airbag .
Page 389 INDEX 387 General Information .....254 Towing ....... .276 High Speed .
Page 390 388 INDEX Unleaded Gasoline ......270 Water Untwisting Procedure, Seat Belt ....34 Driving Through .
Page 391 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 392 Chrysler Group LLC 14FX24-126-AC Third Edition Rev 1 Printed in U.S.A.

Fiat 500 abarth 2014 Owner's Manual

Introduction

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Maintaining Your Vehicle

If You Need Consumer Assistance

Quick Links

Chapters

Related Manuals for Fiat 500 abarth 2014

Summary of Contents for Fiat 500 abarth 2014
