- Page 1 Original instructions Panther FC 6 - 15 kW ..10 ..12 ..15 ..18 ..21 ..24 ..27 ..30 ..33 ..36 ..39 ..42...
- Page 2 Panther FC 6-15 Minimum mounting distance Wall 30° 1800 1000 Floor Ceiling FR: Distances minimales DE: Mindestabstand SE: Minimiavstånd NO: Minsteavstand DK: Minimumsafstande FI: Minimietäisyydet NL: Minimale afstand ES: Distancias mínimas IT: Distanze minime PL: Minimalne odległości 7,5° RU: Минимальные расстояния при установке...
- Page 3 Panther FC 6-15 Mark and drill holes Detach bracket from the unit ø7 ø14 ø6,5 Mount the bracket on the wall Hang the unit on the bracket Tighten all screws. Adjust the angle and fix it with the lower screws 0°...
- Page 4 Panther FC 6-15 Connection Frico Control PNF06 Resetting the overheat protection FR: Réinitialisation de la protection anti-surchauffe DE: Zurücksetzen des Überhitzungsschutzes SE: Återställning FC PC board överhettningsskydd 6.3A x 2 NO: Tilbakestille overopphetingsvernet PNF12 DK: Nulstilling af PNF09 PNF15 overophedningsbeskyttelsen...
- Page 5 Panther FC 6-15 Item Type Voltage Minimal cross Nominal cross section number section Cable Terminal block 400V3N~ 334026 PNF06 230V3~ 400V3N~ 334027 PNF09 230V3~ 400V3N~ 334028 PNF12 230V3~ 400V3N~ PNF15 334029 230V3~ FR: Section transversale minimale du câble. Section transversale nominale du bornier. DE: Mindestquerschnitt Kabel.
- Page 6 Panther FC 6-15 Control systems FC Frico control The fan heater must be supplemented with a FC control system. FCDF - FC Direct FCSF - FC Smart FCCF FCBC10 FCLAP FCCF FCBC05 FCPF - FC Pro FCBF - FC Building...
-
Page 7: Technical Specifications
Panther FC 6-15 Technical specifications Panther FC 6 - 15 (IP44) Item Type Output Airflow Sound Sound ∆t* Motor Voltage* Amperage Weight number steps power * pressure* [kW] [m³/h] [dB(A)] [dB(A)] [°C] [kg] 400V3N~ PNF06 334026 0/3/6 900/1300 39/47 20/14 230V3~ 15,3 400V3N~... -
Page 8: Internal Wiring Diagram
Panther FC 6-15 Internal wiring diagram Panther FC 6 kW Inlet sensor Outlet sensor Wiring diagrams for control system in the FC manual. - Page 9 Panther FC 6-15 Internal wiring diagram Panther FC 9-15 kW Inlet sensor Outlet sensor Wiring diagrams for control system in the FC manual.
-
Page 10: General Instructions
Panther FC 6-15 Installation and operating instructions General Instructions The power supply to the unit must Read these instructions carefully prior to be disconnected during all service, installation and use. Keep this manual for repair and maintenance work. future reference. The product may only be used as set out in the assembly and operating instructions. -
Page 11: Maintenance
Panther FC 6-15 Start-up Packaging When the unit is used for the first time or after Packaging materials are chosen with a long period of non-use, smoke or an odour consideration to the environment and are may result from dust or dirt which has collected therefore recyclable. - Page 12 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net...
