- Page 1 CASA Active Speaker Cabinets Item ref: CASA-8A 178.108UK CASA-10A 178.110UK CASA-12A 178.112UK CASA-15A 178.115UK User Manual Version 1.1 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Introduction Thank you for choosing a CASA active speaker cabinet as part of your sound system. This product is designed to provide flexible, powerful and efficient output for a wide range of sound reinforcement applications. Please read this manual to achieve optimum performance from your speaker cabinet and avoid damage through misuse.
-
Page 3: Rear Panel Layout
Rear panel layout CASA-12/15A Media player display Media player controls DSP setting indicator LEDs LINE A input combo Jack/XLR RCA line input (L+R) MIC/LINE B input combo Jack/XLR MIX line output XLR IEC mains inlet & fuse holder SD card slot USB port Amplifier status LEDs DSP rotary selector... -
Page 4: Operation
Setting up Position your CASA active speaker cabinet(s) on a stable surface capable of supporting the load and vibrations from the cabinet or ideally on a strong 35mmØ pole mount or speaker stand with an adequate safe working load to support the cabinet. Aim the cabinet towards the audience or listeners and not in direct line of sight with any microphones that are connected to the sound system. - Page 5 Media player CASA active cabinets each have a media player section at the top of the rear control panel. The output of the media player is controlled by the RCA/LINE A/ MEDIA volume control (13) or AUX/MEDIA volume control (30) Six buttons beneath the display control the media player, as described below.
-
Page 6: Specifications
The goods must be disposed of according to your local council guidelines. Hereby, AVSL Group Ltd. declares that the radio equipment type 178.108UK, 178.110UK, 178.112UK and 178.115UK is in compliance with Directive 2014/53/EU The full text of the EU declaration of conformity for 178.108UK is available at the following internet...
