- Page 1 CLARA Active Speaker Cabinets with DSP Item ref: CLARA-12A (178.712UK) Item ref: CLARA-15A (178.715UK) User Manual Version 1.0 Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
- Page 2 Introduction Thank you for choosing a CLARA active speaker cabinet as part of your sound system. This product is designed to provide high power output for a wide range of sound reinforcement applications. Please read this manual to achieve optimum performance from your speaker cabinet and avoid damage through misuse. Package Contents •...
-
Page 3: Rear Panel Layout
Rear panel layout DSP display DSP USB port Bluetooth on/off/pairing button INPUT A line input XLR/Jack socket MIX OUT line output XLR INPUT B mic/line input XLR/Jack socket IEC power inlet and fuse holder DSP control rotary selector LINE A input & Bluetooth level control Input B MIC or LINE level switch MIC/LINE B input level control POWER on/off switch... -
Page 4: Operation
Operation With both input volume controls turned fully down, switch on the power (12) to the CLARA speaker cabinet. The LCD display (1) will light up and show the VOLUME level. Use the rotary selector (8) to adjust the master output volume between 0dB and 60dB. - Page 5 Scrolling down the settings using the rotary selector will highlight “Freq:” for setting the centre frequency of the selected EQ band. Press the selector to adjust the frequency in Hertz (Hz). Press the selector again to save the setting. Scrolling down to “Q:” and pressing the selector allows the resonance setting to be adjusted, which shapes the steepness of the filter cutoff, varying effect between a wide band and a narrow focus either side of the centre frequency.
- Page 6 Before connecting the CLARA active speaker to a laptop, please download the “ADU” application from the AVSL website… https://www.avsl.com/assets/downloads/178152UK-software.zip. Please ensure the laptop is running Windows 10 or above. Connect the USB port of the speaker to the laptop via a USB A to B lead and switch the power on to the CLARA speaker cabinet.
- Page 7 The graphic user interface of the ADU software is as shown below, with the audio response shown as a Spectrum Graph to show the frequency response. There are 5 main drop-down options at the top left of the window. • File allows a DSP file to be saved to or opened from laptop memory.
- Page 8 The ADU software also has 2 more tabs for High and Low frequency sections (Tweeter and Woofer control) Each of these pages can be seen below, this time showing just the audio response of either the tweeter or woofer, again with 5 editable EQ nodes. Additionally, there are 2 more nodes called L and H for setting the highest and lowest frequencies that will be used for that specific driver (tweeter or woofer).
-
Page 9: Specifications
Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life. The goods must be disposed of according to your local council guidelines. Hereby, AVSL Group Ltd. declares that the radio equipment type 178.152UK and 178.155UK is in compliance with Directive 2014/53/EU The full text of the EU declaration of conformity for 178.152UK is available at the following internet...
