Avsl adastra BCV Series User Manual

BCV-SERIES
100V Indoor Speakers
BC3V 75mm (3"), 60Wmax
BC4V 100mm (4"), 70Wmax
BC5V 130mm (5.25"), 90Wmax
BC6V 165mm (6.5"), 120Wmax
Introduction
Thank you for choosing the BC-series indoor speakers. These speakers have been designed to offer high
quality sound for low impedance installations. Please read and follow the
instructions in this manual to achieve the best results and avoid damage through
misuse.
Installation
The BC-series speakers are each supplied with a wall-mounting bracket which
allows 90° lateral adjustment. When fixing to a wall or ceiling, use the bracket to
mark out the fixing points and use appropriate fixings for the substrate that the
speaker will be attached to, ensuring that the fixing is strong enough to bear the weight.
Once the bracket is fitted, support the speaker in position and attach top and bottom using the supplied
screw caps and adjust to the required angle. Further mounting points are available at the rear of the
speaker, should it be preferred to use different mounting methods (e.g. 129.130 – 129.124UK)
Note: Do not over-tighten the screw caps as this can cause the threaded inserts to fail.
White
Black
White
Black
White
Black
White
Black
User Manual
952.710
952.711
952.712
952.713
952.714
952.715
952.716
952.717
