Recliner System

1. Place the Recliner System on the chair with the air cells facing up and the non-skid
surface of the cover facing the chair seat and chair back.
Warning: When possible, use the hook or loop fasteners to further secure the
cover to the seating surface. On the back cushion, hook and loop fasteners are
located inside the cover and on the back of the cushion.
2. Slide the hand pump nozzle over the inflation valve.
Open the inflation valve, at least one full rotation.
Inflate until all of the air cells feel firm. Close the
inflation valve until it comes to a stop. Remove the
hand pump. Make sure the inflation valve is closed.
Repeat for all inflation valves.
3. Confirm that the individual is in their usual position.
Confirm correct placement of the Recliner System.
4. Slide your hand between the cushion and the
individual and feel for bony prominences. With your
hand in place, open the inflation valve, releasing air
as prescribed. Close the inflation valve. Repeat for all
inflation valves.
Warning: CHECK INFLATION! Make sure that there is at least ½ in. (1.5 cm) of
air between the cushion base and the individual's bony prominences. Follow the
prescriber's recommended inflation levels.
Cover Removal and Replacement
Cover Removal: Unsnap and remove the covers from the cushions.
Cover Replacement:
1. The zipper on the Back Cushion cover should be closed. For the Seat Cushion
and Back Cushion: The non-skid cover material should face up and the snapped
opening of the cover should face you. The air cells should face down: Insert each
cushion into its cover, inflation valve(s) first. Pull the inflation valve(s) and Yellow
Rope through the corner opening(s). The inflation valves will protrude at the front of
the Seat Cushion and at the top of the Back Cushion.
2. Place the two cushions with the snapped openings next to each other. Snap the
Back Cushion to the Seat Cushion. Snap the bottoms of the covers together. Turn
the cushions over so the air cells face up. Snap the tops of the covers together. The
cushions should lie flat inside the covers.
Open
6
Close
The seated figure
shows standard
orientation.
