Model:
Output Amp. (max):
Load impedance:
Bandwidth:
Voltage gain (variable):
Input range:
Rise time (20%-80%, for max
output):
Output power, maximum:
Dual channel option:
DC offset option 1 :
Connectors:
Power:
Dimensions:
1) To specify the DC offset option, add the suffix -OS to the model number. The sum of the amplitude and the offset must remain within
the rated output amplitude range – i.e., this option does not change the minimum or maximum obtainable output voltage.

SPECIFICATIONS

AV-110C-PS-D
± 100 Volts
DC to 200 kHz
0 to ± 2 Volts (1 kΩ input impedance)
Yes (-D option)
-OS option: 0 to ± 25 Volts
-XOS option: 0 to ± 100 Volts
100 - 240 Volts,
100 mm x 430 mm x 375 mm
(3.9" x 17" x 14.8")
≥ 10 kΩ
×1 to ×100
0.6 us
1 W
BNC
50-60 Hz
6
