Model AV-143CP-PS-AVA is a customized DC-coupled fixed-gain linear amplifier, with a
gain (V /V ) of +6 V/V.
OUT IN
The input may range from 0 to +2V. The input impedance is 1 kΩ.
The corresponding output voltages are 0 to +12V. The maximum output current is +500
mA. The output will operate into resistive loads, or capacitive loads of up to 2.2 nF.
The output rise and fall times are 0.4 us or less.

SPECIFICATIONS

Model:
Output amplitude:
Voltage Gain:
Rise, fall time (20%-80%):
Input impedance:
Maximum output current:
Maximum load capacitance:
Bandwidth (-3 dB):
Maximum average output power:
Overshoot:
Prime power:
Connectors:
Dimensions:

INTRODUCTION

AV-143CP-PS-AVA
DC to > 500 kHz
12V × 500 mA = 6 Watts
100 - 240 Volts, 50 - 60 Hz
100 x 430 x 375 mm (3.9" x 17" x 14.8")
0 to +12V
+6 V/V
0.4 us
1 kΩ
+500 mA
2.2 nF
< 10%
BNC
