D E S C R I P T I O N
632 Luminous Shield is economical and is ADA compliant.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Solid aluminum construction
with matte white acrylic diffuser.
F i n i s h
Standard: Natural Aluminum
(NA). [Sustainable Design]
Premium: Matte White (MW),
Matte Black (MB), Silver Metallic
(SM), Bronze Metallic (BM) Gold
Metallic (GM) or Custom Color
(CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate the
specified lamp wattage.
O R D E R I N G I N F O R M AT I O N
Sample Number: 632-CFL/1/26-277V-MB
Series
Lamp
Voltage
632 Luminous
=
CFL/1/13
120V
Shield
CFL/1/26
277V
INC/1/60
347V
Notes:
1
Available with CFL only.
2
Consult the factory for available options.
3
26W only.
4
Supplied by others.
L a m p / S o cke t
One (1) 13W (2GX7) 4-pin low
wattage CFL or 26W (G24q-3) 4-
pin quad tube CFL lamp, or one
(1) 60W A-19 lamp. CFL socket
injection molded plastic. INC
socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
O p t i o n s
CFL Dimming Ballast (26W only)
- Contact the factory for ballast
options (DM), Remote
Emergency Battery - Supplied by
others (REM), Damp Location
(DL): All Painted Finishes only.
Energy Star Rating - Consult
factory. MRI Applications (INC
only) - Contact Factory.
Finish
Options
Standard
DL Damp Location
1
NA Natural Aluminum
=
DM CFL Dimming Ballast
1
Premium
REM Remote Emergency Battery
BM Bronze Metallic
=
CC Custom Color
=
GM Gold Metallic
=
MB Matte Black
=
MW Matte White
=
SM Silver Metallic
=
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
=
2, 3
=
4
=
shaperlighting.com
Type
Date
632 SERIES
I n t e r i o r W a l l L u m i n a i r e
S t a r t e r C o l l e c t i o n
L u m i n o u s S h i e l d
AMERICAN DISABILITIES
ACT (ADA)
Shaper offers a large selection of ADA
interior and exterior wall luminaires.
ADA requires all fixtures below 68" to
have a maximum projection of 4".
STARTER
COLLECTION
Shaper's exclusive Starter Collection fixtures
are featured throughout the Shaper product
line. The concept of offering highly styled,
affordable fixtures was introduced over
fourteen years ago and has become one of
our fastest growing lines. The design
premise, basic construction, clean lines
and unadorned shapes are highly desirable
in modern architectural environments.
SUSTAINABLE
DESIGN
Shaper has a long-standing history of
offering environmentally-friendly fixtures.
The copper and bronze alloys used in our
exterior luminaires feature up to 98% re-
cycled content, contribute less undesirable
air emissions compared to painted alumi-
num and are easy to recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety
of fixtures that can be provided
with an Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
ADS042665
2008-09-15 10:01:22
