8. MAINTENANCE

ATTENTION!
Disconnect the unit from the mains prior to
cleaning.
1. When cleaning the air conditioner, do not use
gasoline, solvents and other chemically active
substances.
2. To avoid electric shock and damage to electrical
components, do not pour water on the air conditioner
from a tap or a hose.
3. Do not use the air conditioner if the power cord is
damaged. On the
subject of replacing a damaged power cord, contact
an authorized service center.
Air filter
Air filter clogging with dust particles impairs the air
conditioner operation efficiency, therefore clean the
filter no less than once in two weeks.
Filter removal/installation
Remove the air filter in the direction, indicated by the
arrow. Slightly push it and then take it out from the
device for cleaning.
Installation of the filter is performed in the reverse order.
Filter cleaning
At first, carefully clean the filters by means of vacuum cleaners. Then
immerse the filter in warm water (about 40°C) with a soft detergent,
wash it and dry it without exposure to direct sunlight.
Air intakes (heat exchangers)
Use a vacuum cleaner for cleaning.
Case
Wipe the surface by a damp cloth and dry it by a soft dry cloth.
Automatic condensate removal
Condensate is automatically removed from the unit. Moisture inside the
unit starts to evaporate and is removed from the unit through an air duct
(or an air diffuser) in the form of steam.

9. TROUBLESHOOTING

Trouble
The tank fill-up
indicator is flashing, the
condensate collection
The air conditioner is not switched on
tray is filled up
when Power button is pressed
Actual room temperature
is higher than the set one
(in heating mode)
The air conditioner is
Loud noise or strong vibration installed on an inclined or
unsmooth surface
Noise emerges due to
A noise, resembling a gurgle of water
refrigerant flow in pipes
www.timberk.com • Electric air conditioner
Cause Troubleshooting method
Drain water from the tray
Set the temperature correctly
Install the air conditioner on a
smooth horizontal surface
It is normal
