Summary of Contents for ASROCK Rack Z690D4ID-2T/G5/X550
- Page 1 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 User Manual Version 1.0 Published December 2022 Copyright©2022 ASRock Rack INC. All rights reserved.
- Page 2 In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
- Page 3 The terms HDMI® and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE.
- Page 4 Licensee’s intellectual property rights, to incorporate or otherwise utilize those comments and suggestions. TERMINATION OF THIS LICENSE. Intel or the sublicensor may terminate this license at any time if Licensee is in breach of any of its terms or conditions. Upon termination, Licensee will immediately destroy or return to Intel all copies of the Software.
- Page 5 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant information based on regulation requirements.
-
Page 6: Table Of Contents
Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Expansion Slot (PCI Express Slot) Jumpers Setup Onboard Headers and Connectors ATX PSU / DC-IN Power Connections... - Page 7 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys Main Screen Advanced Screen 3.3.1 CPU Configuration 3.3.2 Chipset Configuration 3.3.3 PCH-FW Configuration 3.3.4 Storage Configuration 3.3.5 NVME Configuration 3.3.6 ACPI Configuration 3.3.7 USB Configuration 3.3.8 Super IO Configuration 3.3.9 Serial Port Console Redirection 3.3.10 H/W Monitor 3.3.11 Trusted Computing 3.3.12 Intel ME Configuration...
- Page 8 3.5.2 System Event Log 3.5.3 BMC Tools Event Logs Boot Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...
-
Page 9: Chapter 1 Introduction
In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. -
Page 10: Specifications
1.2 Specifications Z690D4ID-2T/G5/X550 / W680D4ID-2T/G5/X550 Physical Status Form Factor Deep mini-ITX Dimension 6.7" × 8.2" (170.18 x 208.28 mm) Processor System Z690D4ID-2T/G5/X550: Supports 12 & 13 Gen Intel® Core™, Pentium® and Celeron® series processors W680D4ID-2T/G5/X550: Supports 12 & 13 Gen Intel® Core™ series processors... - Page 11 AMI 256Mb SPI Flash ROM Features Plug and Play, ACPI 6.4 and above compliance wake up events, SMBIOS 2.8 and above , ASRock Rack Instant Flash Internal Connectors/Headers PSU connector 1 Micro-Fit (4-pin, ATX PSU signal) w/ ATX 24-pin adapter...
- Page 12 NMI button COM header 1 (9-pin) Speaker header Fan header 3 (4-pin) Thermal sensor header TPM header 1 (13-pin, SPI) SGPIO header SMbus header PMbus header IPMB header Clear CMOS 1 (2-pin) Others 1 UID_LED, 1 IPMI_LED, 1 NC-SI LED Indicators Standby Power LED 1 (5VSB) Fan Fail LED...
-
Page 13: Unique Features
. With this utility, you can press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility. -
Page 14: Motherboard Layout
1.4 Motherboard Layout Z690D4ID-2T/G5/X550 / W680D4ID-2T/G5/X550 20.8 cm (8.2 in) UID_HD NCSI1 PSU_SMB1 ATX4PIN1 ATX12V1 ATX12V2 DDR5_B2 DDR5_B1 Intel UID1 X550 DDR5_A2 UID_LED1 DDR5_A1 Z690D4ID-2T/X550 LAN1 LAN2 W680D4ID-2T/X550 FAN1 M2_1 BAT1 COM1 M2_2 BMC_SMB1 SPEAKER1 Intel Z690/W680 ASPEED AST2600 OCU1... - Page 15 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Description 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) NCSI Header (NCSI1) PSU SMBus Header (PSU_SMB1) UID Header (UID_HD) ATX 4-PIN Power Connector (ATX4PIN1 (ATX 24pin-to-4pin) ATX 12V Power Connector (ATX12V1)
- Page 16 Description BMC SMBus Header (BMC_SMB1) Serial Port Header (COM1) *The BMC ROM is on the bottom side of the motherboard.
-
Page 17: Onboard Led Indicators
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 1.5 Onboard LED Indicators Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550... - Page 18 Item Status Description LED_FAN1 FAN1 failed SB_PWR1 Green STB PWR ready LED_FAN3 FAN3 failed LED_FAN2 FAN2 failed BMC_LED1 Green BMC heartbeat LED...
-
Page 19: I/O Panel
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 1.6 I/O Panel Z690D4U-2L2T/G5/X550 / W680D4U-2L2T/G5/X550 No. Description No. Description UID Switch (UID1) VGA Port (VGA1) UID LED HDMI Port 10G LAN RJ-45 Port (LAN1)** USB 3.2 Gen1 Ports (USB3_1_2) 10G LAN RJ-45 Port (LAN2)** LAN RJ-45 Port (IPMI_LAN1)* LAN Port LED Indications *There are two LED next to the LAN port. - Page 20 **There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port 10G LAN Port LED Indications Activity / Link LED Speed LED Status Description Status Description No Link 100Mbps connection or...
-
Page 21: Block Diagram
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 1.7 Block Diagram Z690D4ID-2T/X550 Z690D4ID-2T/G5/X550/ W680D4ID-2T/G5/X550 DDR5 4800 (1DPC) / 4000 (2DPC) [ECC/non-ECC] C C h h a a n n n n e e l l A A DDR5 4800 (1DPC) / 4000 (2DPC) [ECC/non-ECC] PCI-E X16... -
Page 22: Chapter 2 Installation
Chapter 2 Installation This is a deep mini ITX form factor (6.7" × 8.2") motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components. -
Page 23: Installing The Cpu
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 2.3 Installing the CPU 1. Before you insert the 1700-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. - Page 24 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.
-
Page 25: Installing The Cpu Fan And Heatsink
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 2.4 Installing the CPU Fan and Heatsink... -
Page 26: Installing Memory Modules (Dimm)
2.5 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2. - Page 27 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
-
Page 28: Expansion Slot (Pci Express Slot)
2.6 Expansion Slot (PCI Express Slot) There is 1 PCI Express slot on this motherboard. PCIE slot: PCIE7 (PCIe 5.0 x16 slot) is used for PCI Express x1 lane width cards. Slot Generation Mechanical Electrical Source PCIE 7 Installing an expansion card Step 1. -
Page 29: Jumpers Setup
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 2.7 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper... - Page 30 The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.
-
Page 31: Onboard Headers And Connectors
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 2.8 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header... - Page 32 ATX12V1/V2 ATX 12V Power The motherboard provides Connectors two 8-pin 12V power (8-pin ATX12V1) connectors which are required (see p.6, No. 7) input for either DC-IN 12V or (8-pin ATX12V2) ATX +12V power source. (see p.6, No. 8) When using ATX power, it is necessary to use a 24pin-to-4pin power cable to connect between the...
- Page 33 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 SATA Power Connector Please use a SATA power (DC-IN mode) cable (4-pin ATX4PIN2) to connect this SATA Power +12V (see p.6, No. 9) Connector and your SATA HDD for supplying power from the motherboard, when using DC-IN mode without SATA power supply.
- Page 34 CMOS Battery Connector The server board comes VBAT (BAT1) with external CMOS battery VBAT (see p.6, No. 32) connector. This 2-pin connector is used to connect the external cable battery. PSU SMBus Header PSU SMBus monitors the ALERT SMBCLK (PSU_SMB1) status of the power supply, fan (see p.6, No.4) and system temperature.
- Page 35 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Thermal Sensor Header Please connect the thermal (3-pin TR1) sensor cable to either pin 1-2 (see p.6, No. 27) or pin 2-3 and the other end to the device which you wish to monitor its temperature. OCuLink Connectors...
- Page 36 UID Header This 4-pin header is used for LOCATORLED- LOCATORBTN# (4-pin UID_HD) the Unit Identification LED +5VSB (see p.6, No. 5) and switch functions. NCSI Header The onboard NCSI header is (9-pin NCSI1) used for external (see p.6, No. 3) connections..
-
Page 37: Atx Psu / Dc-In Power Connections
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 2.9 ATX PSU / DC-IN Power Connections This motherboard supports both +12V DC and ATX power input. Please refer to the table below for the required connections between the motherboard and the power supply. Connector DC-IN ATX PSU... -
Page 38: Unit Identification Purpose Led/Switch
2.10 Unit Identification purpose LED/Switch With the UID button, You are able to locate the server you’re working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED (UID_ front or rear panel is pressed, LED1)/Switch the front/rear UID blue LED (UID1) -
Page 39: Dua Lan And Teaming Operation Guide
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 2.11 Dua LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection(s) for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images. -
Page 40: Ssd Module Installation Guide
2.12 M.2 SSD Module Installation Guide The M.2 Socket (M2_1/M2_2, Key M) supports type 2280 M.2 PCI Express module up to Gen4 x4 (16GT/s x4). Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the screw. Step 2 Gently insert the M.2 SSD module into the M.2 slot. -
Page 41: Chapter 3 Uefi Setup Utility
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del> during the Power-On-Self-Test (POST) to enter the UEFI SETUP UTILITY;... -
Page 42: Navigation Keys
3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>... -
Page 43: Main Screen
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows you to set the system time and date. Mother Board Information Enter this item to view the motherboard information. -
Page 44: Advanced Screen
3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configura- tion, Chipset Configuration, PCH-FW Configuration, Storage Configuration, NVMe Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, Trusted Computing, Intel ME Configuration, Network Stack Configuration, VMD Condiguration, Driver Health and Insant Flash. -
Page 45: Cpu Configuration
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.3.1 CPU Configuration Processor P-Core Information This item displays the P-Core Information. Processor E-Core Information This item displays the E-Core Information. Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. - Page 46 CPU C States Support Enable CPU C States Support for power saving. It is recommended to keep C6 and C7 enabled for better power saving. Enhanced Halt State (C1E) Enable Enhanced Halt State (C1E) for lower power consumption. CPU C6 State Support Enable C6 deep sleep state for lower power consumption.
- Page 47 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Hardware Prefetcher Automatically prefetch data and code for the processor. Enable for better performance. Adjacent Cache Line Prefetch Automatically prefetch the subsequent cache line while retrieving the currently requested cache line. Enable for better performance. Legacy Game Compatibility Mode When enabled, pressing the scroll lock key will toggle the Efficient cores between being parked when Scroll Lock LED is on and un-parked when LED is off.
-
Page 48: Chipset Configuration
3.3.2 Chipset Configuration SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support. Onboard VGA (D-Sub) Use this to enable or disable the Onboard VGA function. Intel IGFX Select disable to disable the integrated graphics when an external graphics card is installed. Or select enable to keep the integrated graphics enabled at all times. - Page 49 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 VT-d Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance. OCU Mode Selection Switch the COU link to PCIE or SATA.
-
Page 50: Pch-Fw Configuration
3.3.3 PCH-FW Configuration Intel(R) Platform Trust Technology Use this item to configure Intel PTT funciton. Select Enabled to use Intel PTT in ME. Disable this option to use discrete TPM Module. -
Page 51: Storage Configuration
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.3.4 Storage Configuration SATA Controller(s) Enable or disable the SATA controllers. Hybrid Storage Detection and Configuration Mode This item allows you select Hybrid Storage Detection and Configuration Mode. SATA Aggressive Link Power Management SATA Aggressive Link Power Management allows SATA devices to enter a low power state during periods of inactivity to save power. -
Page 52: Nvme Configuration
3.3.5 NVME Configuration The NVMe Configuration displays the NVMe controller and Drive information. -
Page 53: Acpi Configuration
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.3.6 ACPI Configuration Suspend to RAM Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving. PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. -
Page 54: Usb Configuration
3.3.7 USB Configuration This page displays the information of the USB controllers and USB devices. -
Page 55: Super Io Configuration
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.3.8 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of COM. Serial Port Use this item to enable or disable the serial port (COM). Change Settings Use this item to select an optimal setting for Super IO device. -
Page 56: Serial Port Console Redirection
3.3.9 Serial Port Console Redirection COM1 / SOL Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how your computer and the host computer to which you are connected exchange information. - Page 57 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Data Bits Use this item to set the data transmission size. The options include [7] and [8] (Bits). Parity Use this item to select the parity bit. The options include [None], [Even], [Odd], [Mark] and [Space]. A parity bit can be sent with the data bits to detect some transmission errors.
- Page 58 Redirection After BIOS POST If the [LoadBooster] is selected, legacy console redirection is disabled before booting to legacy OS. If [Always Enabled] is selected, legacy console redirection is enabled for legacy OS. The default value is [Always Enabled]. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console Redirection EMS Use this option to enable or disable Console Redirection.
-
Page 59: H/W Monitor
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.3.10 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. -
Page 60: Trusted Computing
3.3.11 Trusted Computing NOTE: Options vary depending on the version of your connected TPM module. Security Device Support Enable to activate Trusted Platform Module (TPM) security for your hard diskdrives. Active PCR banks This item displays active PCR Banks. Available PCR Banks This item displays available PCR Banks. - Page 61 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Platform Hierarchy Use this item to enable or disable Platform Hierarchy. Storage Hierarchy Use this item to enable or disable Storage Hierarchy. Endorsement Hierarchy Use this item to enable or disable Endorsement Hierarchy. TPM 2.0 InterfaceType (CRB) Select the Communication Interface to TPM 2.0 Device Device Select Use this item to select the TPM device to be supported.
-
Page 62: Intel Me Configuration
3.3.12 Intel ME Configuration ME Subsystem screen displays the Intel ME Subsystem Configuration information, such as Operational Firmware Version, ME Firmware, ME Firmware Type, ME Firmware SKU and ME File System Integrity Value. -
Page 63: Network Stack Configuration
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.3.13 Network Stack Configuration Network Stack Use this item to enable or disable UEFI Network Stack. IPv4 PXE Support Use this item to enable or disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available. -
Page 64: Vmd Configuration
3.3.14 VMD Configuration Enable VMD Controller Use this item to enable or disable VMD Controller. When enabled, the options below appear. Enable VMD Global Mapping Use this item to enable or disable VMD Global Mapping. Map this Root Port under VMD Use this item to map or unmap Root Port to VMD. -
Page 65: Tls Auth Configuration
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.3.15 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert. -
Page 66: Instant Flash
3.3.16 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems first like MS- ® DOS or Windows . Just save the new UEFI file to your USB flash drive, floppy disk or hard drive and launch this tool, then you can update your UEFI only in a few clicks without pre- paring an additional floppy diskette or other complicated flash utility. -
Page 67: Security
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.4 Security In this section you may set or change the supervisor/user password for the system. You may also clear the user password. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. -
Page 68: Key Management
3.4.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode. Install Default Secure Boot Keys Please install default secure boot keys if it’s the first time you use secure boot. - Page 69 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed...
- Page 70 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed Forbidden Signatures Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3.
- Page 71 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed...
-
Page 72: Server Mgmt
3.5 Server Mgmt Wait For BMC Wait For BMC response for specified time out. In PILOTII, BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC interfaces. FRB-2 Timer Use this item to enable or disable FRB-2 timer (POST timer). - Page 73 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 OS Wtd Timer Policy Configure how the system should respond if the OS Boot Watchdog Timer expires. This item is not available if OS Boot Watchdog Timer is disabled. BMC Network Configuration Select this item to Configure BMC network parameters.
-
Page 74: Bmc Network Configuration
3.5.1 BMC Network Configuration Bonding Setting Use this item to enable or disable bonding, if you want to enable bonding please enable all Lan channel first. Bond0 Enable Setting Show you the Bond0 status is enabled or disabled. Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. - Page 75 Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 When [DHCP] or [Static] is selected, do NOT modify the BMC network settings on the IPMI web page. The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/faq.asp...
-
Page 76: System Event Log
3.5.2 System Event Log SEL Components Change this to enable ro disable all features of System Event Logging during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress or both. -
Page 77: Bmc Tools
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.5.3 BMC Tools KCS Control Select this KCS interface state after POST end. If [Enabled] us selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS interface after POST stage Restore AC Power Loss This allows you to set the power state after an unexpected AC/power loss. -
Page 78: Event Logs
3.6 Event Logs Change Smbios Event Log Settings This allows you to configure the Smbios Event Log Settings. When entering the item, you will see the followings: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot. -
Page 79: Boot
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.7 Boot In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1~#6 Use this item to set the system boot order. UEFI Application Boot Priorities Specifies the Boot Device Priority sequence from available UEFI Application. - Page 80 Boot Beep Select whether the Boot Beep should be turned on or off when the system boots up. Please note that a buzzer is needed. Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Enabled]. Boot Failure Guard Message If the computer fails to boot for a number of times the system automatically restores the default settings.
-
Page 81: Exit Screen
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 3.8 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. -
Page 82: Chapter 4 Software Support
4.3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your... -
Page 83: Chapter 5 Troubleshooting
Z690D4ID-2T/G5/X550 W680D4ID-2T/G5/X550 Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components. - Page 84 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...
-
Page 85: Technical Support Procedures
W680D4ID-2T/G5/X550 5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type. - Page 86 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrockrack.com/tsd.asp...
