7. Attach the two Handrails (74) to the Uprights (84)
with two of the 5/16" x 2" Screws (2) that you
removed in step 3 and two 5/16" Star Washers
(8); do not fully tighten the Screws yet. Be
careful not to pinch the Upright Wire (83) on
the right side.
Then, remove and discard the two indicated
screws (B).
8. Set the console assembly (C) face down on
a soft surface to avoid scratching the console
assembly.
Remove and discard the four indicated screws
(D). Then, remove the Pulse Crossbar (80).
7
2
8
74
B
8
D
80
12
74
2
83
8
B
84
C
D
