- Page 1 Prep Connect Complete Techne Installation Manual Model: 52310 Matte Silver 52311 Flat Matte Black 52312 Matte Fresh White Fan weight ±2 lbs: 23.4 lbs (10.6 kg) ©2022 Hunter Fan Co. M3994-01 r120522...
- Page 2 Congratulations on purchasing your new Hunter ceiling fan! ® The ceiling fan you purchased will provide comfort and performance in your home or office for many years. This instruction manual contains complete instructions for installing and operating your fan. We are proud of our work and appreciate the opportunity to supply you with the best ceiling fan available anywhere in the world.
-
Page 3: Tools Needed For Installation
Tools Needed for Installation Box Outlet Mount Building Structure Mount 9/64" Box Contents Hardware Included Parts Included Canopy Mount Canopy Remote Fan Body Wood Screw x2 Small Flat Head Snap-on Blades Screwdriver Washer x2 Light Kit Glass Cover Socket Ring Light Bulb threadlocker... -
Page 4: Before Beginning Installation
Before Beginning Installation Standard Mount This installation is for flat ceilings using the short pre-installed Turn Power OFF, breaker and light switch. downrod ceiling fans. WARNING IMPORTANT The longest accessory downrod that can be used with To avoid possible electrical shock, before installing your fan, fans is 12-inches. -
Page 5: Installation
Installation – Canopy Mount and Terminal Wiring 1a 1a Building Structure Mount Building Structure Mount Prep Connect Comple • You must be able to secure the fan to building structure or fan-rated outlet box. • You have two options for installation. Pick which one works best for your location. - Page 6 Installation – Canopy Mount and Terminal Wiring (continued) Single Switch Wiring Single Switch Wiring Connect wiring from ceiling to terminal block (on side of canopy mount) and tighten using flathead screwdriver (included). Green, Green Yellow Stripe, or Bare (grounding) Green, Green Yellow Stripe, or Bare (grounding) WARNING White (grounded) White (grounded)
- Page 7 Installation – Fan Body, Wiring Harness, Canopy Cover, and Blades Connect Complete NOTICE To prevent damage to fan, ALWAYS lift holding either the fan housing or the downrod. Connect wiring harness from canopy mount (A) to wiring harness Install snap-on canopy (B) over downrod on fan body (C). Place the down from fan body (C).
- Page 8 Installation – Light Kit Notch Complete Remove the cardboard plug guard before proceeding! Raise the light kit to the bottom of the fan. Align the notch on the mounting ring on the top of the light kit with the pin in the mounting bracket on the bottom of the fan.
- Page 9 Installation – Glass Cover Socket Glass Bulb Socket Ring Install a bulb into each of the sockets. When necessary, Remove the socket rings from the sockets. Install the glass replace with bulbs of same wattage. onto the sockets. Install the socket rings onto the sockets. Tighten them by turning clockwise by hand.
- Page 10 Operation – Remote NOTICE Remote Function Guide Key Press Function • Always purchase the + Quick Press Light On/Off correct size and grade of battery most suitable for + Long Press Light Dimming the intended use. + Quick Press Fan On/Off •...
- Page 11 Follow the onscreen prompts to set up your fan. (fan style may vary). Heading Hunter Pro Tip: Need to install the app later? When ready, turn the wall switch off and then on. Wait three minutes before downloading the app.
-
Page 12: Troubleshooting
Hunter instructions, accidental damage caused by the fan owner or related parties, Please do not ship your fan or any fan parts to Hunter. Delivery will be refused. modifications to the fan, improper or incorrectly performed maintenance or repair,... - Page 13 Installation - Long Downrod 1. Loosen set screw (1) and remove ball screw (2). 4. Remove ball, inner sleeve and downrod from fan body (8) and wiring harness. 2. Slide ball down (3), remove small metal pin (4) and ground screw (5). 5.
