Outline Structure And Installation - Microsensor MPM483DM Operation Manual

Sealed
gauge (S)
Power Supply: 8V~28V DC (The intrinsically safe type is powered by a
safety barrier)
Output Signals: analogue 4mA~20mA DC (2-wire); digital RS485
interface
Display Range: -19999 ~ 19999 (4 and half digits LCD display)
Load Resistance: (U-8V) /0.02A (Ω) (U is the supply power)
Compensated Temperature: -10 ℃ ~ 70 ℃
Application Temperature: -30 ℃ ~ 80 ℃ (non-explosive type and intrinsic
safety type)
Storage Temperature: -40 ℃ ~85 ℃
Insulation Resistance: 100MΩ@100V
Long-term Stability: ±0.25%FS/year
Vibration: 10g, 20Hz~2000Hz
Shock：20g, 11ms
Housing Protection: IP65

3 Outline Structure and Installation

3.1 Outline dimensions
1bar＜X≤10bar
10bar＜X≤1000bar
35bar＜X≤1000bar
-30 ℃ ~ 60 ℃ (flameproof type)
5
±0.25FS%
±0.25FS%(default)
±0.1FS%
±0.25FS%(default)
±0.1FS%
unit:mm
