  • Page 1 owner’s manual J - 2 0 0 ™ s e r i e s J - 280 J - 270 J - 230 J - 220 J - 210 2530-277T Rev. A...
  • Page 2 Attention New Spa Owner! Congratulations on the purchase of your new Jacuzzi® spa! The following is a list of automated functions performed by your spa. These functions are listed below in an attempt to alleviate any operational concerns you may have during the first 24-hours of ownership! Also listed below are important maintenance recommendations you should observe on a regular basis to protect your new investment.

  • Page 3: Table Of Contents

    Standard Filtration/Heating Modes For Models Without Circulation Pump Option (All Models) ............ 24 11.2 Standard Filtration/Heating Modes For Models With Circulation Pump Option (J-230, J-270 & J-280 Only) ......24 11.3 Economy Filtration/Heating Modes (All Models) ........24 11.4 Lock Modes - L1-L2 (All Models) ............25 11.5...
  • Page 4 Water is Too Hot ..................37 15.5 No Heat ....................37 16.0 Circuit Board Diagrams ........... 38 16.1 North American J-230, J-270 & J-280 Models ......... 38 16.2 North American J-210 & J-220 Convertible Models ........ 39 16.3 Export 50Hz J-230, J-270 & J-280 Models ..........40 16.4...

  • Page 5: Important Spa Owner Information

    Jacuzzi premium insulating cover in place at all times when the spa is not in use. Read and carefully follow the requirements for your spa’ s support base found in section 4.0 titled, “Choosing A Location”...

  • Page 6: Important Safety Instructions

    J-200 Series 3.0 Important Safety Instructions READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY When installing and using this electrical equipment, basic safety precautions should always be followed, including: WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times.
  • Page 7 J-200 Series Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, pregnant or possibly pregnant women should limit spa water temperatures to 100°F (38°C). If pregnant, please consult your physician before using a spa. Before entering the spa, the user should measure the water temperature with an accurate thermometer since the tolerance of water temperature- regulating devices may vary as much as +/- 5°F (2°C).

  • Page 8: Important Csa Safety Instructions (Canada Only)

    J-200 Series 3.1 Important CSA Safety Instructions (Canada Only) When using this electrical equipment, basic safety precautions should always be followed, including the following: READ AND FOLLOW ALL INSTRUCTIONS. A green colored terminal or a terminal marked G, Gr, Ground, Grounding or the symbol* is located inside the supply terminal box or compart- ment.

  • Page 9: Hyperthermia

    A warning sign is provided in your warranty packet. Please install it at a location near your spa, where it is visible to the user of the spa. For addi- tional or replacement signs please contact your local Jacuzzi spas dealer and reference item number #6530-082.

  • Page 10: General Electrical Safety Instructions

    It contains the most advanced safety and self-protective equipment in the indus- try. Nonetheless, this spa must be installed properly to ensure dependable usage. Please contact your local Jacuzzi dealer or local building department should you have any questions regarding your installation.

  • Page 11: Choosing A Location

    J-200 Series 4.0 Choosing A Location IMPORTANT: Because of the combined weight of the spa, water and users, it is extremely important that the base upon which the spa rests be smooth, flat, level and capable of uniformly supporting this weight, without shifting or settling, for the entire time the spa is in place.

  • Page 12: Indoor Location

    J-200 Series 4.2 Indoor Location For indoor installations many factors need to be considered before installing a spa indoors: Proper Foundation: Consult a Structural Engineer when considering a foundation that will adequately support the spa the entire time it is in place. Proper support is critical especially if the spa is to rest on a second story or higher.

  • Page 13: General Electrical Safety Instructions

    J-200 Series 5.0 General Electrical Safety Instructions Your new Jacuzzi® spa is equipped with a “state-of-the-art” equipment system. It contains the most advanced safety and self-protective equipment in the indus- try. Nonetheless, this spa must be installed properly to insure dependable usage.

  • Page 14: Power Requirements

    J-200 Series 6.0 Power Requirements Jacuzzi® spas are designed to provide optimum performance and flexibility of use when connected to the maximum electrical service listed below. Minor circuit board modifications can be performed to allow your new spa to accept an electrical service other than the factory operation setting.
  • Page 15 J-200 Series All North American J-210 & J-220 Convertible Models (60Hz) 240V/40A ‡ 120V/15A† 240V/30A† 40A ‡ , 2-Pole Circuit Breaker: 15A†, 1-Pole 30A†, 2-Pole Number of Wires: 3 (15A GFCI 4 (Hard Wire 4 (Hard Wire Cord US Only*) Only) Only) Frequency: 60Hz...
  • Page 16 J-200 Series Export J-230 Models (50Hz) 230V/20A* 230V/30A** Circuit Breaker: 20A* 30A** Number of Wires: Frequency: 50Hz 50Hz Current Draw: In 20A configuration, the heater will not operate while either jets pump is running in high speed. This is the factory setting. Note: pump 2 runs only in high speed.

  • Page 17: Electrical Wiring Instructions

    J-200 Series 7.0 Electrical Wiring Instructions IMPORTANT NOTICE: The electrical wiring of this spa must meet the requirements of the National Electrical Code/USA (NEC) and any applicable state or local codes. The electrical circuit must be installed by a qualified electri- cian and approved by a local building/electrical inspection authority.
  • Page 18 J-200 Series To gain access to the spa’ s power terminal block, remove the screws secur- ing the synthetic cabinet panel under the control panel (Figure A). Then remove the four control box door screws and door (Figure B). Select the power supply inlet you want to use (Figure A). Feed power cable to control box, then install it through the large opening provided in the bot- tom side of the box.
  • Page 19 Install control box door and screws and reinstall the cabinet side panels. Congratulations! You are now all set to get your new spa ready to use. Simply follow the step-by-step procedure in Section 8.0, before long, you will be enjoy- ing your first glorious experience in your Jacuzzi J-200 Series spa.

  • Page 20: Spa Fill Up Procedure

    Turn on jets pump(s) to ensure proper mixing when adding start-up chemicals in step 5. 5. Add Start-Up Chemicals Add the spa water chemicals as recommended by your authorized Jacuzzi dealer. See section 13.0 “Water Quality Maintenance” (page 33) for general guidance.
  • Page 21 J-200 Series 6. Establish A Stable Sanitizer Reading Establish a stable sanitizer reading between 3.0-4.0 ppm chlorine or 2.0-4.0 ppm bromine. To ensure healthy water conditions, always maintain a constant sanitizer reading within the levels recommended by the Association of Pool And Spa Professionals/USA printed on the inside cover of this manual.
  • Page 22 Water Fill Volume by Model Spa Model Approximate Fill Volume Sodium Dichlor J-270 & J-280 390 US Gallons (1,476 Liters) 10.0 oz J-230 380 US Gallons (1,438 Liters) 9.5 oz J-220 335 US Gallons (1,438 Liters) 8.5 oz J-210 220 US Gallons (1,438 Liters) 5.5 oz...
  • Page 23 Jacuzzi dealer. 13. Consult your authorized Jacuzzi dealer for chemical recommendations, then add chemicals to spa water to achieve a constant sanitizer reading within the lev- els recommended by the Association of Pool And Spa Professionals/USA printed on the inside cover of this manual.

  • Page 24: Control Functions

    J-200 Series 9.0 Control Functions 9.1 Control Panel LED Display: Can display current water temperature (default display), water temper- ature set point, selected filtration/heating mode, and error messages. Heat Indicator: Lit when heater is on. Jets 1 Button: Turns jets pump #1 on and off. Press once for low speed; press a second time for high speed;...

  • Page 25: General Spa Features And Controls

    J-200 Series 9.2 General Spa Features And Controls J-280 model illustrated - Jet locations and features will vary by model. Control Panel Suction Fittings & Filters Headrest Pillows (4 ea.) (Filters protect massage selectors from Air Controls (4 ea.) debris entrapment/damage. Filters Cup Holders (4 ea.) require periodic cleaning.) Massage Selector (1 ea.)

  • Page 26: Operating Instructions

    J-200 Series 10.0 Operating Instructions The spa control system has automatic functions that operate upon start-up and normal operation to protect the system. Upon power up, the readout displays the following information: Spas with Spas with Spas without Spas without Circulation Circulation Circulation Circulation...

  • Page 27: Optional Multi-Colored Led Light System Operation

    J-200 Series 10.4 Optional Multi-Colored LED Light System Operation The multi-colored LED spa light offers seven constant color variations and three unique random modes for enhanced spa enjoyment. Press the light button once to activate the first light mode “Random Fade”, then continue pressing the button to either turn the light off or to select one of seven constant colors, random solid color mode or strobe mode as illustrated below.

  • Page 28: Air Controls

    11.2 Standard Filtration/Heating Modes For Models With Circulation Pump Option (J-230, J-270 & J-280 Only) Standard filtration/heating modes (F0-F3) are typically selected by customers in cold climates where heat up times are extended due to lower ambient tempera- tures.

  • Page 29: Lock Modes - L1-L2 (All Models)

    J-200 Series only while a programmed filtration/heating cycle is running. Note: these modes can be used to conserve energy while on vacation or out of town for several weeks since heater operation is minimized. During such times, you can also minimize the spa set temperature to maximize energy savings! 11.4 Lock Modes - L1-L2 (All Models) These modes are designed for use during spa service or to prevent unauthorized...

  • Page 30: Filtration Modes For Spas With Circulation Pump Option (J-230, J-270 & J-280 Only)

    9:58 AM. Note: start time is approximate and may vary slightly from day to day. 11.7 Filtration Modes for Spas With Circulation Pump Option (J-230, J-270 & J-280 Only) If your spa is not equipped with the circulation pump option, disregard this section and refer to page for filter cycle programming details.

  • Page 31: Spa Maintenance

    12.0 Spa Maintenance Proper and regular maintenance of your spa will help it retain its beauty and performance. Your authorized Jacuzzi dealer can supply you with all the infor- mation, supplies, and accessory products you will need to accomplish this.
  • Page 32 J-200 Series J-230, J-270 & J-280 Models: These model spas are equipped with a skimmer bag and one high performance pleated filter cartridge located under the filter cover as illustrated below. Debris are filtered by the optional circulation pump (when equipped) drawing water through the skimmer bag and filter cartridge 24-hours a day, or by Jets pump 1 when running a programmed filter cycle or when manually activated by spa use.
  • Page 33 “F”, followed by soaking the filter overnight in a plastic container filled with a solution of water and specially formulated filter cleanser available from your authorized Jacuzzi dealer. The average life expectancy of each filter is approxi- mately two years with proper care and water quality maintenance. Replacement...

  • Page 34: Draining And Refilling

    J-200 Series 12.2 Draining and Refilling About every 3 months, you will want to replace the spa’ s water. The frequency depends on a number of variables including the amount of use, attention paid to water quality maintenance, etc. You will know it is time for a change when you cannot control sudsing and/or you can no longer get the normal feel or sparkle to the water even though the key water balance measurements are all within the proper parameters.

  • Page 35: Pillow Care

    12.5 Maintaining the Cover Using the Jacuzzi insulating spa cover anytime the spa is not in use will signifi- cantly reduce your operating costs, heat-up time and maintenance requirements. To prolong the life of the cover, handle it with care and clean it regularly using mild soap and water.

  • Page 36: Restarting Your Spa In Cold Weather

    For expert winterization of your spa, contact your authorized Jacuzzi dealer. In emergency situations, damage can be minimized by taking the following steps: Follow the directions on page for draining the spa.

  • Page 37: Water Quality Maintenance

    Many other additives are available for your spa. Some are necessary to compensate for out-of-balance water, some aid in cosmetic water treatment and others simply alter the feel or smell of the water. Your authorized Jacuzzi dealer can advise you on the use of these additives.

  • Page 38: Optional Cd Ozone Water Maintenance System

    J-200 Series 13.3 Optional CD Ozone Water Maintenance System If you have elected to have your spa equipped with the optional Jacuzzi CD ozone water purification system you will find that your water stays fresh and clear with significantly less chemical sanitizer usage. You will also probably be able to go longer between complete spa drainings.

  • Page 39: Panel Displays Sn2

    J-200 Series 14.5 Panel Displays SN2 Open or shorted sensor (heater disabled). The temperature sen- sor is not functioning. Contact your authorized Jacuzzi dealer or qualified service technician. 14.6 Panel Flashes FL1 or FL2 (Spas Without Circulation Pump Option) A flashing “FL1” display means the pressure switch is not closed when the jets pump 1 is activated.

  • Page 40: Panel Displays

    Jacuzzi dealer or qualified service technician. 15.0 Troubleshooting Procedures In the event your Jacuzzi® spa is not working the way it should, please first review all the installation and operating instructions in this manual and check the message on the panel display. If you are still not satisfied it is working prop- erly, please follow the appropriate troubleshooting instructions below.

  • Page 41: Water Is Too Hot

    Nonetheless, we are always striving to improve the quality and features of our products. Your input as a Jacuzzi spa owner is a cherished part of this process. If you have any comments or suggestions, or if you wish to be informed on any new prod- ucts for your spa, please write to us.

  • Page 42: Circuit Board Diagrams

    J-200 Series 16.0 Circuit Board Diagrams 16.1 North American J-230, J-270 & J-280 Models This wiring diagram is used for all J-230, J-270 & J-280 240V 60Hz North American spa models With or Without the Circulation Pump Option.

  • Page 43: North American J-210 & J-220 Convertible Models

    J-200 Series 16.2 North American J-210 & J-220 Convertible Models This wiring diagram is used for all J-210 & J-220 120/240V 60Hz North American convertible spa models. J1 Logic Jumper Settings (Factory Defaults Shown) JP1 1-2 ON = 30A Logic (4-wire 120/240 VAC operation only) Control JP1 1-2 OFF = 40A Logic (4-wire 120/240 VAC operation only) Panel...

  • Page 44: Export 50Hz J-230, J-270 & J-280 Models

    J-200 Series 16.3 Export 50Hz J-230, J-270 & J-280 Models This wiring diagram is used for all J-230, J-270 & J-280 230V 50Hz Export spa models With or Without the Circulation Pump Option.

  • Page 45: Export 50Hz J-210 & J-220 Models

    J-200 Series 16.4 Export 50Hz J-210 & J-220 Models This wiring diagram is used for all J-210 & J-220 230V 50Hz Export spa models. J1 Logic Jumper Settings JP1 1-2 ON = 20A Logic (Factory Setting) Control JP1 1-2 OFF = 30A Logic Panel JP1 7-8 ON = °C Temperature Display (Factory Setting)

  • Page 46: Optional Stereo Receiver Functions

    SOURCE EQ/LD DISP AQUATIC J-230, J-270 & J-280 Models Only: To start enjoying your new stereo receiver, please read the following operation instructions in their entirety. Power Button: Press PWR (Power) to turn deck on or off. Equalization Button: Repeatedly press EQ/LD to choose from DSP Off, Jazz, Pop, Classic, Rock or Vocal equalization options.
  • Page 47 J-200 Series DISP Button: Press DISP to switch between clock and station frequency. When selected, the clock will display for 5 seconds then automatically revert back to station frequency. Source Button: Press Source to change input from audio or CD mode to auxiliary mode.
  • Page 48 J-200 Series OPEN A/PS MUTE SOURCE EQ/LD DISP AQUATIC Preset 5/DN Button: In tuner mode, any station can be stored as preset 5 by simply pressing and holding this button for several seconds. To recall the station preset, simply press and release this button. In CD mode this button will browse the folders on CD-R and CD-RW disks.
  • Page 49 J-200 Series the bottom of the deck. To change bands: 1) Power down unit 2) Lift up sticker under the CD player. 3) Choose desired frequency band as indicated on the sticker. 4) Put sticker back in place and power up the unit. Setting The Clock (Unit Must be Off): To set the current time, press and hold Display (6) for 3 seconds until the clock display starts to blink, then set hours using the Track Up and/or Track Down button (17).
  • Page 50 J-200 Series OPEN A/PS MUTE SOURCE EQ/LD DISP AQUATIC Playback Order of The MP3 File: A directory that does not include an MP3 file is skipped. We recommend that you make no more than two levels for each disc. Maximum number of folders: 256 Maximum number of folder levels: 8 Maximum number of characters for MP3 file name and folder name: 32...
  • Page 51 J-200 Series Optional Audio Receiver Specifications • Marine Grade AM/FM/CD/CD-R/CD-RW/MP-3 • 7 Bands of Weather Band • Stainless Steel Sealed Chassis and Mounting Hardware • IPX5 Water Intrusion & CFR-46 Rated • Conformal Coated Printed Circuit Boards • ASTMB117 Salt Fog Tested 400 Hours •...
  • Page 52 J-200 Series...
  • Page 53 J-200 Series The following UL requirements must be observed for all spas with optional stereo components installed. “CAUTION - Risk of Electric Shock. Do not leave compartment door open”; “CAUTION - Risk of Electric Shock. Replace component only with identical compo- nents”;...
  • Page 54 J-200 Series Serial Number: _______________________________ Model Name: _______________________________ Dealer Name: _______________________________ Notes: _______________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
  • Page 56 14525 Monte Vista Avenue, Chino, California 91710 | U.S.A. Telephone 1.866.234.7727 | Fax 1.909.606.1095 P/N 2530-277T Rev. A © 2007 Jacuzzi Hot Tubs. All Rights Reserved. Printed In The U.S.A.
