- Page 1 PAT SE RI ES USER MANUAL PAT 440-10 PAT 443-10 PAT 450-10 w w w . a m e r i c a n c o n t r o l e l e c t r o n i c s . c o m...
- Page 2 American Control Electronics®. The information and technical data in this document are subject to change without notice. American Control Electronics® makes no warranty of any kind with respect to this material, including, but not limited to, the implied warranties of its merchantability and fitness for a given purpose.
- Page 3 Follow sound maintenance procedures. It is possible for a drive to run at full speed as a result of a component failure. American Control Electronics strongly recommends the installation of a master switch in the main WARNING! power input to stop the drive in an emergency.
-
Page 4: Table Of Contents
PAT Series Table of Contents Section 1. Specifications ............. 1 Section 2. Dimensions ............3 Section 3. Installation ............6 Mounting ..................6 Wiring ..................7 Shielding Guidelines.............. 8 Line Fusing ................9 Connections.................11 Power Inputs ...............11 Motor ..................11 Field Output Connections .............12 Analog Input Signal (PAT440 and PAT450) ......13... - Page 5 PAT Series Section 5. Calibration ............25 Minimum Speed (MIN SPD) ............26 Maximum Speed (MAX SPD) ............26 Torque (TQ LIMIT) ................27 IR Compensation (IR COMP) ............28 Acceleration (ACCEL) ..............30 Deceleration (DECEL) ..............30 Section 6.Application Notes ..........31 Multiple Fixed Speeds ..............31 Adjustable Speeds Using Potentiometers In Series ......32...
- Page 6 PAT Series List of Tables Table 1 Recommended Line Fuse Sizes ........... 9 Table 2 Short Circuit Current Ratings ..........10 Table 3 Field Output Connections ..........12 Table 4 Minimum Recommended Dynamic Brake Resistor Values ...22...
- Page 7 PAT Series List of Figures Figure 1 PAT440 Dimensions ............3 Figure 2 PAT443 Dimensions ............4 Figure 3 PAT450 Dimensions ............5 Figure 4 Power Connections ............13 Figure 5 Analog Input Signal Connections (PAT440 and PAT450) ..14 Figure 6 Analog Input Signal Connections (PAT443) ......15...
-
Page 8: Section 1. Specifications
PAT Series Section 1. Specifications Maximum HP Range HP Range Armature with 90 VDC with 180 VDC Model Current (ADC) Motor Motor Enclosure PAT440 1/8 - 1 1/4 - 2 NEMA 4X PAT443 NEMA 4X PAT450 NEMA 4X AC Line Voltage 115/230 VAC ±... - Page 9 PAT Series Vibration 1G maximum (0 - 50 Hz) 0.1G maximum (> 50 Hz) Safety Certifications UL/cUL Listed Equipment, File # E132235 Ambient Temperature Range 10°C - 40°C...
-
Page 10: Section 2. Dimensions
PAT Series Section 2. Dimensions 5.63 [143] 5.16 [ 131] 0.19 [5.00] SLOTTED HOLES 4 PLACES 7.50 [191] 5.50 [140] BOTTOM PLATE 0.73 [18.5] CONDUIT HOLES 2 PLACES 4.56 [116] 2.12 [53.8] 2.20 [55.9] 3.40 [86.4] ALL DIMENSIONS IN INCHES [MILLIMETERS]... -
Page 11: Figure 2 Pat443 Dimensions
PAT Series 5.63 [143] 5.16 [ 131] 0.19 [5.00] SLOTTED HOLES 4 PLACES MANUAL SIGNAL 7.50 [191] 5.50 [140] BOTTOM PLATE 0.73 [18.5] CONDUIT HOLES 2 PLACES 4.56 [116] 2.12 [53.8] 2.20 [55.9] 3.40 [86.4] ALL DIMENSIONS IN INCHES [MILLIMETERS]... -
Page 12: Figure 3 Pat450 Dimensions
PAT Series 5.63 [143] 5.16 [ 131] 0.19 [5.00] SLOTTED HOLES 4 PLACES 7.50 [191] 5.50 [140] BOTTOM PLATE 0.73 [18.5] CONDUIT HOLES 2 PLACES 4.56 [116] 2.12 [53.8] 2.20 [55.9] 3.40 [86.4] ALL DIMENSIONS IN INCHES [MILLIMETERS] Figure 3. PAT450-10 Dimensions... -
Page 13: Section 3. Installation
PAT Series Section 3. Installation Do not install, rewire, or remove this control with input power applied. Failure to heed this warning may result in fire, explosion, or serious injury. Make sure you read and understand the Safety WARNING! Precautions on page i before attempting to install this product. -
Page 14: Wiring
PAT Series Wiring Do not install, rewire, or remove this control with input power applied. Failure to heed this warning may result in fire, explosion, or serious injury. WARNING! Circuit potentials are at 115 or 230 VAC above ground. To prevent the risk of injury or fatality, avoid direct contact with the printed circuit board or with circuit elements. -
Page 15: Shielding Guidelines
PAT Series Shielding Guidelines Under no circumstances should power and logic level leads be bundled together. Induced voltage can cause unpredictable behavior in any electronic device, including motor controls. WARNING! As a general rule, it is recommended to shield all conductors. If it is not practical to shield power conductors, it is recommended to shield all logic-level leads. -
Page 16: Line Fusing
PAT Series Line Fusing Drives are preinstalled with 15 amp fuses. Preinstalled line fuses are rated for maximum horsepower. If the horsepower rating of the motor being used is less than the maximum horsepower rating of the drive, the line fuse may have to be replaced with a lower rated one. -
Page 17: Table 2 Short Circuit Current Ratings
PAT Series Short-circuit current rating (SCCR) is the maximum short-circuit current that the speed control can safely withstand when protected by a specific over-current protective device(s). WARNING! Table 2. Short Circuit Current Ratings Short Circuit Current Rating Maximum Types of Branch... -
Page 18: Connections
PAT Series Connections Do not connect this equipment with power applied. Failure to heed this warning may result in fire, explosion, or serious injury. WARNING! Power Input Connect the AC line power leads to screw terminals L1 and L2 115 if using a 115 VAC line or to terminals L1 and L2 230 if using a 230 VAC line. -
Page 19: Field Output Connections
PAT Series Field Output Connections The field output is for shunt wound motors only. Do not make any connections to F1 and F2 when using a permanent magnet motor. WARNING! See Table 3 for field output connections. Use 18 AWG wire to connect the field output to a shunt wound motor. -
Page 20: Figure 4 Power Connections
PAT Series MOV501 F502 L2 FRM SW L1 A2 TO SW A1 L2 TO SW L1 A2 FRM SW A1 F501 MOV503 TB501 230 VAC 115 VAC EARTH GROUND FIELD LINE VOLTAGE INPUT MOTOR (GREEN SCREW) OUTPUT (115 or 230 VAC) -
Page 21: Analog Input Signal (Pat440 And Pat450)
(+) to S2. Make no connection to S3. A potentiometer can be used to scale the analog input voltage. An interface device, such as American Control Electronics model ISO202-1, may be used to scale and isolate an analog input voltage. -
Page 22: Figure 6 Analog Input Signal Connections (Pat443)
PAT Series Analog Input Signal (PAT443) Instead of using a speed adjust potentiometer, the drive may be wired to follow an analog input voltage or current signal that is either isolated SIG MIN. SIG MAX or non-isolated from earth ground. Connect the signal common (-) to S1. -
Page 23: Section 4. Operation
PAT Series Section 4. Operation Change voltage switch settings only when the drive is disconnected from AC line voltage. Make sure both switches are set to their correct position. If the switches are improperly set to a lower voltage position, the motor will not run at full voltage WARNING! and may cause damage to the transformer. -
Page 24: Select Switches
PAT Series Select Switches Input Voltage Select (SW501) Set the input voltage select switch SW501 to either 115 or 230 to match the AC line voltage. See Figure 7. Armature Voltage Select (SW502) IL502 IC501 CURRENT C502 Set the armature voltage select switch SW502 to either 90 or 180 to... -
Page 25: Startup
PAT Series Startup PAT440 Turn the speed adjust potentiometer to “0” (full CCW) or set the input voltage signal to minimum. Set the POWER switch to the ON position. Slowly advance the speed adjust potentiometer clockwise (CW) or increase the input voltage signal. The motor slowly accelerates as the potentiometer is turned CW or as the input voltage signal is increased. -
Page 26: Pat450
PAT Series PAT450 Do not change direction while the motor is running. The motor must come to a complete stop before reversing. Changing motor direction before allowing the motor to completely stop will cause WARNING! excessively high current to flow in the armature circuit, and will damage the drive and/or motor. -
Page 27: Starting And Stopping Methods
PAT Series Starting and Stopping Methods Dynamic braking, coasting to a stop, or decelerating to minimum speed is recommended for frequent starts and stops. Do not use any of these methods for emergency stopping. They may not stop WARNING! a drive that is malfunctioning. -
Page 28: Dynamic Braking
PAT Series Dynamic Braking Wait for the motor to completely stop before switching back to RUN. This will prevent high armature currents from damaging the motor or drive. WARNING! Dynamic braking may be used to rapidly stop a motor (Figure 8 on page 22). -
Page 29: Table 4 Minimum Recommended Dynamic Brake Resistor Values
PAT Series Table 4. Minimum Recommended Dynamic Brake Resistor Values Motor Armature Voltage Dynamic Brake Resistor Value 90 VDC 15 ohms 180 VDC 30 ohms For motors rated 1/17 horsepower and lower, a brake resistor is not necessary since the armature resistance is high enough to stop the motor without demagnetization. -
Page 30: Inhibit Terminals
18 inches (46 cm). If shielded cable is used, ground only one end of the shield to earth ground. Do not ground both ends of the shield. American Control Electronics offers two accessory plug harnesses for connecting to the INHIBIT terminals: part number 201-0024 [plug with 18 in. -
Page 31: Decelerating To Minimum Speed
PAT Series Decelerating to Minimum Speed The switch shown in Figure 10 may be used to decelerate a motor to a minimum speed. Closing the switch between S1 and S2 decelerates the motor from set speed to a minimum speed determined by the MIN SPD trim pot setting. -
Page 32: Section 5. Calibration
BE ALERT. High voltages can cause serious or fatal injury. PAT series drives have user-adjustable trim pots. Each drive is factory calibrated to its maximum current rating. Readjust the calibration trim pot settings to accommodate lower current rated motors. -
Page 33: Minimum Speed (Min Spd)
PAT Series Minimum Speed (MIN SPD) The MIN SPD setting determines the minimum motor speed when the speed adjust potentiometer or input voltage signal is set for minimum speed. It is factory set for zero speed. To calibrate the MIN SPD: Set the MIN SPD trim pot full CCW. -
Page 34: Torque (Tq Limit)
Continuous operation beyond this rating may damage the motor. If you intend to operate beyond the rating, contact your WARNING! American Control Electronics representative for assistance. The TQ LIMIT setting determines the maximum torque for accelerating and driving the motor. To calibrate TORQUE, refer to the recommended... -
Page 35: Ir Compensation (Ir Comp)
PAT Series IR Compensation (IR COMP) The IR COMP setting determines the degree to which motor speed is held constant as the motor load changes. Use the following procedure to recalibrate the IR COMP setting: Set the IR COMP trim pot to minimum (full CCW). -
Page 36: Figure 11 Recommended Torque And Ir Comp Settings
PAT Series MODELS PAT440-10, PAT443-10, PAT450-10 1 HP 2 HP 90 VDC 180 VDC 10.0 AMPS 10.0 AMPS TQ LIMIT IR COMP TQ LIMIT IR COMP 1/2 HP 1 HP 90 VDC 180 VDC 5.00 AMPS 5.00 AMPS TQ LIMIT... -
Page 37: Acceleration (Accel)
PAT Series Acceleration (ACCEL) The ACCEL setting determines the time the motor takes to ramp to a higher speed. See Specifications on page 1 for approximate acceleration times. ACCEL is factory set for the shortest acceleration time (full CCW). To set the acceleration time: Set the speed adjust potentiometer or input voltage signal for minimum speed. -
Page 38: Section 6.Application Notes
PAT Series Section 6.Application Notes Multiple Fixed Speeds Replace the speed adjust potentiometer with a series of resistors with a total series resistance of 10K ohms (Figure 12). Add a single pole, multi- position switch with the correct number of positions for the desired number of fixed speeds. -
Page 39: Adjustable Speeds Using Potentiometers In Series
PAT Series Adjustable Speeds Using Potentiometers In Series Replace the speed adjust potentiometer with a series of resistors with a total series resistance of 10K ohms (Figure 13). Add a single pole, multi- position switch with the correct number of positions for the desired number of fixed speeds. -
Page 40: Independent Adjustable Speeds
PAT Series Independent Adjustable Speeds Replace the speed adjust potentiometer with a single pole, multi- position switch, and two or more potentiometers in parallel, with a total parallel resistance of 10K ohms. Figure 14 shows the connection of two independent speed adjust potentiometers that can be mounted at two separate operating stations. -
Page 41: Run/Jog Switch - Inhibit Connection
PAT Series RUN/JOG Switch - Inhibit Connection Using a RUN/JOG switch is recommended in applications where quick stopping is not needed and frequent jogging is required. Use a single pole, two position switch for the RUN/JOG switch, and a single pole, normally closed, momentary operated pushbutton for the JOG pushbutton. -
Page 42: Run/Jog Switch - Potentiometer Connection
PAT Series RUN/JOG Switch - Potentiometer Connection Connect the RUN/JOG switch and the JOG pushbutton as shown in Figure 16. When the RUN/JOG switch is set to JOG, the motor decelerates to minimum speed (minimum speed is determined by the MIN SPD trim pot setting). -
Page 43: Leader-Follower Application
PAT Series Leader-Follower Application In this application, use a PCM4 to monitor the speed of the leader motor (Figure 17). The ISO202-1 isolates the leader motor from the follower drive, and outputs a voltage proportional to the leader motor armature voltage. -
Page 44: Single Speed Potentiometer Control Of Multiple Drives
PAT Series Single Speed Potentiometer Control Of Multiple Drives Multiple drives can be controlled with a single speed adjust potentiometer using a ISO101-8 at the input of each drive to provide isolation (Figure 18). Optional ratio potentiometers can be used to scale the ISO101-8 output voltage, allowing independent control of each drive. -
Page 45: Reversing
PAT Series Reversing A dynamic brake may be used when reversing the motor direction (Figure 19). Use a three pole, three position switch rated for at least the maximum DC armature voltage and maximum braking current. Wait for the motor to stop completely before switching it to either the forward or reverse direction. -
Page 46: Section 7. Diagnostic Leds
PAT Series Section 7. Diagnostic LEDs PAT series drives are equipped with two diagnostic LEDs: • Power (POWER): Green LED lights whenever AC line voltage is applied to the drive. • Current Limit (TQ LIMIT): Red LED lights whenever the drive reaches current limit. -
Page 47: Section 8. Troubleshooting
PAT Series Section 8. Troubleshooting Dangerous voltages exist on the drive when it is powered. When possible, disconnect the drive while troubleshooting. High voltages can cause seroius or fatal injury. WARNING! Before Troubleshooting Perform the following steps before starting any procedure in this section: Disconnect AC line voltage from the drive. - Page 48 PAT Series PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS Line fuse 1. Line fuse is the wrong size. 1. Check that the line fuse is correct for the motor size. blows. 2. Motor cable or armature is 2. Check motor cable and shorted to ground.
- Page 49 PAT Series PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS Motor does not 1. MIN SPD is set too high. 1. Calibrate MIN SPD. stop when the speed adjust potentiometer is full CCW. Motor runs in 1. Motor connections to A1 1. Remove power. Reverse and A2 are reversed.
-
Page 50: Section 9. Accessories & Replacement Parts
PAT Series Section 9. Accessories & Replacement Parts Displays Closed Loop ................CLD100-1 Open Loop................OLD100-1 Kits Fuse 2 1.5 Amp 250V 3AG Fast-blow Glass Fuses ....... KTF-0001 2 3 Amp 250V 3AG Fast-blow Glass Fuses ......KTF-0002 2 5 Amp 250V 3AG Fast-blow Glass Fuses ......KTF-0003 2 8 Amp 250V 3AG Fast-blow Glass Fuses ...... -
Page 51: Unconditional Warranty
If for any reason any of the foregoing provisions shall be ineffective, American Control Electronics’s liability for damages arising out of its manufacture or sale of equipment, or use thereof, whether such liability is based on warranty, contract, negligence, strict liability in tort, or otherwise, shall not in any event exceed the full purchase price of such equipment. - Page 52 PAT 44 0-1 0 PAT44 3-10 PAT4 50-1 0 w w w. a m erican co nt ro l el ec t ro ni c s. com 1 430 0 D E L A TOU R D R IV E S OU TH B ELO IT, IL 6 1080 ( 844) A MC NTR L MA N-000 5 Rev 1...
