Summary of Contents for Solplanet ASW45K-LT-G3
- Page 1 Quick Installation Guide ASW45K-LT-G3/ASW50K-LT-G3/ASW60K-LT-G3 Android...
-
Page 2: General Information
The contents of this guide may be updated or revised due to product development. The information in this guide is subject to change without notice. The latest version of this document and the manual for installation, commissioning, configuration and decommissioning are to be found in PDF format at www.solplanet.net. SAFETY 2.1 Intended use... - Page 3 The product must only be used in countries for which it is approved by AISWEI and the grid operator. The type label must be permanently attached to the product and must be in a legible condition. This document does not replace any regional, state, provincial, federal or national laws, regulations or standards that apply to the installation, electrical safety and use of the product.
- Page 4 ！ DANGER Danger to life due to electric shock when touching live system com- ponents in case of a ground fault！ If a ground fault occurs, parts of the system may still be live. Touching live parts and cables may result in death or lethal injuries due to electric shock. •...
- Page 5 2.3 Symbols on the label Beware of a danger zone This symbol indicates that the inverter must be additionally grounded if additional grounding or equipotential bonding is required at the installation site. Beware of high voltage and operating current The inverter operates at high voltage and current. Work on the inverter must only be carried out by skilled and authorized electricians.
-
Page 6: Eu Declaration Of Conformity
AISWEI Technology Co., Ltd. confirms here with that the products described in this document are in compliance with the fundamental requirements and other relevant provisions of the above mentioned directives. The entire EU Declaration of Confor- mity can be found at www.solplanet.net. QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223... -
Page 7: Scope Of Delivery
OVERVIEW PV1/40A PV2/32A PV3/32A PV4/40A PV5/32A Name DC-switch DC connector inputs LED指示灯 指示逆变器当前的工作状态 WiFi stick port Additional grounding screw RS485 communication port AC terminal SCOPE OF DELIVERY Mounting-bracket×1 AC/COM cover×1 DC connector×10 WiFi stick×1 Inverter×1 Screw accessory ×1 AC insulation sheet×3 Document packagex1 QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223... -
Page 8: Mounting Environment
MOUNTING ENVIRONMENT × × × √ √ √ ＞75° × × × √ √ √ × +60℃ -25℃ IP66 4K4H ≤100% No touching max.4000m by children ≥500mm ≥500mm ≥500mm QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223... - Page 9 DIMENSIONS Unit： mm MOUNTING 8.1 Mounting-bracket 4-Φ12 90° 70mm 4-φ10 19mm 13 N·m QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223...
- Page 10 8.2 Wall-Mounted Installation 2.5N·m 2.5N·m 90° SECOND PROTECTIVE GROUNDING L=E+(2~3)mm 2.5N · QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223...
- Page 11 AC CONNECTION 8.5mm<Φ<10.5mm 28-42mm 130mm 1.6N · 3.5N · · QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223...
- Page 12 1.6N · DC CONNECTION TYPE 1 click 2.5-6mm Φ - 5 8mm √ × TYPE 2 2.5-6mm Φ - 5 8mm QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223...
-
Page 13: Communication Setup
COMMUNICATION SETUP 12.1 WiFi/LAN/4G stick connection × √ QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223... - Page 14 12.2 RS485 cable connection 1.6N · 3-5.5mm 30~100mm A B G RS485 ..RS485 RS485 ..1.6N · QG0047_ASW45-60K-LT-G3_EN-540-300224-00_0223...
- Page 15 ——Inverter serial number ——Photovoltaic module model ——Photovoltaic modules number and strings number connected to each MPPT ——Fault code ——Installation location ——Warranty card EMEA Service email: service.EMEA@solplanet.net APAC Service email: service.APAC@solplanet.net LATAM Service email: service.LATAM@solplanet.net Aiswei Greater China Service email: service.china@aiswei-tech.com...
- Page 16 AISWEI Technology CO., Ltd...
