particular maintenance since it is heatproof, scratch proof and stain
proof.
Underneath The Existing Worktop
(When fitting beneath a worktop) In most modern fitted kitchens there
is a single worktop cabinet in which an electrical appliance can be
fitted there. In this case, remove the worktop of the dishwasher by
unscrewing the screws on the top rear side (a).
ATTENTION!
After removing the top, the screws must be installed again on the
top edge of the rear side (b).
The height will then be reduced to 815 mm, according to the
International Regulations (ISO) and the dishwasher will fit perfectly
under the kitchen working top.
Selecting The Best Installation Location
The installation position of dishwasher should be near the existing inlet
and drain hoses and power cord. Illustrations of cabinet dimensions
and installation position of the dishwasher.
1. Less than 5 mm between the top of dishwasher and cabinet and
the outer door aligned to cabinet
