- Page 1 User’s Manual OL1000XL OL1500XL OL2200XL OL3000XL CyberPower Systems (USA), Inc. 4241 12th Avenue East Suite 400 Shakopee, MN 55379 Phone: 877-297-6937 Fax: 952-403-0009 www.CPSww.com K01-0000356-00...
- Page 2 重要安全警語 本手冊包含重要的操作說明，應遵循安裝並維護 UPS 和電池。請仔細閱讀並遵守所有的安裝指引與 警示。安裝前需仔細閱讀本手冊再進行安裝與操作。 注意！ UPS 須接到具地線的電源插座，並有保險絲或斷路器等過電流保護器。 注意！ 如需關閉連接到 UPS 的設備時，請先關閉 UPS 電源再拔掉插頭。 注意！ 不得使用在醫療或生命維護設備！ CyberPower 並不銷售產品在生命維護或醫療應用上， 任何影響生命維護、醫療應用或病人護理等皆不得使用。 注意！ 在 UPS 電池模式下，電池接頭斷開可以切斷危險的帶電元件。 注意！ 為了防止火災或觸電危險，UPS 需安裝在溫度和濕度合理控制下的室內環境。 （請參閱規格 可接受的溫度和濕度範圍） 。 注意！ 為了減少觸電危險，勿取下上蓋。除電池可替換外，內部無其他可供使用者維修的零件。 注意！ 為了避免觸電危險，在更換電池或作為電腦設備備用電源前，請先關閉 UPS 電源開關。 注意！ 不得使用在水族箱或相關水源設備上！為降低發生火災的風險，任何有潛在水源處皆不得 使用，如壓縮機冷凝水會導致機器短路起火。 注意！ 交流輸出電纜使用長度不得超過 10 米。...
- Page 3 規格說明 Smart App Online UPS 型號 額定電壓/電流 最大功率 AC 120V(＋6%/－10%), 8.4A MAX, 50/60Hz 輸入 OL1000XL AC 120V, 8.4A MAX, 50/60Hz 1000VA/900W 輸出 AC 120V (＋6%/－10%), 12.5A MAX, 50/60Hz 輸入 OL1500XL AC 120V, 12.5A MAX, 50/60Hz 1500VA/1350W 輸出 AC 120V (＋6%/－10%), 18.4A MAX, 50/60Hz 輸入...
-
Page 4: Important Safety Instructions
SUPERVISED BY PERSONNEL KNOWLEDGE OF BATTERIES AND REQUIRED PRECAUTIONS. KEEP UNAUTHORIZED CAUTION! Do not use an improper size power cord as it may cause PERSONNEL AWAY FROM BATTERIES! damage to your equipment and cause fire hazards. Copyright © 2014 CyberPower Systems, Inc. -
Page 5: Safety Precautions
CAUTION! Do not work alone under hazardous conditions. CAUTION! In case of the risk of electric shock, do not remove the top cover. CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected. Copyright © 2014 CyberPower Systems, Inc. -
Page 6: Installing Your Ups System
UPS will continuously emit two beeps per second. For resetting the unit, unplug some equipment from the outlets. Make sure your equipment carries a load current within the unit’s safe range, (refer to the technical specifications). Copyright © 2014 CyberPower Systems, Inc. -
Page 7: Basic Operation
12. Extended Runtime Battery Module Connector reserves are transferred to specified outlets during a power outage. The Connection for additional CyberPower XL Battery modules. unit can be programmed to provide additional runtime for equipment connected to the “CRITICAL” outlets, while stopping the power supply to 13. - Page 8 BASIC OPERATION OL1000XL / OL1500XL OL2200XL OL3000XL Copyright © 2014 CyberPower Systems, Inc.
-
Page 9: Led Indicators - Ups Status
Press this button to scroll up in the LCD menu. ▼ Press this button to scroll down in the LCD menu. ENTER Press this button to select an option. Press this button to cancel or return to previous LCD menu. Copyright © 2014 CyberPower Systems, Inc. -
Page 10: Lcd Setup Functions
Date & Time Displays the present Date & Time - - - - / - - / - - - -:- - Next BAT Change Displays the next Battery Change Date & Time XXX / XXXX Copyright © 2014 CyberPower Systems, Inc. -
Page 11: Lcd Event Log
You may be prompted to save the selection, if so press the “ENTER” button to save the setting. Some options are saved and started automatically. (See the following table for additional details.) Press the “ESC” button to cancel or return to the previous LCD menu. Copyright © 2014 CyberPower Systems, Inc. - Page 12 **) This function can’t be set when Manual Bypass, Generator Mode or Converter Mode is enabled. ***) UPS has no bypass when Generator Mode is enabled. ****) UPS has no bypass when Converter Mode is enabled. This function can only be set before the UPS is on. Copyright © 2014 CyberPower Systems, Inc.
-
Page 13: Silencing Audible Alarms
The LCD screen displays the battery capacity during charging with a graphical icon while on Line Mode. Discharging Capacity The LCD screen displays the remaining battery capacity with a graphical icon while on Battery Mode. Copyright © 2014 CyberPower Systems, Inc. -
Page 14: Lcd Module Remote Control And Wall-Mounting Instructions
Step 4: Mount LCD Module on the Wall SAFETY PRECAUTIONS CAUTION! It must be done by qualified personnel. CAUTION! To avoid electric shock, turn off and unplug the unit before installing REMOTE CONTROL or WALL-MOUNTING INSTRUCTIONS. Copyright © 2014 CyberPower Systems, Inc. -
Page 15: Maintenance
Only use replacement batteries which are certified by proper disposal and recycling of batteries. Do not dispose of batteries CyberPower Systems. Use of incorrect battery type is an electrical in fire. hazard that could lead to explosion, fire, electric shock, or short circuit. -
Page 16: Technical Specifications
15.6 x 6.6 x 9.1in. (397 x 167 x 232mm) 16.3 x 8.3 x 13.2in. (414 x 212 x 336mm) Net Weight 34.1lbs(15.5Kg) 66.0lbs(30.0Kg) Safety Conformance Approvals UL, VCCI, BSMI *)100V are derated by 20%, 110 V are derated by 10% Copyright © 2014 CyberPower Systems, Inc. -
Page 17: Troubleshooting
Internal Fan has failed. CyberPower Systems Inc. www.cpsww.com © Entire contents copyright 2014 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part ® ® without permission is prohibited. PowerPanel Business Edition and PowerPanel Personal Edition are trademarks of CyberPower Systems Inc.
