- Page 1 User’s Manual OL6000RT3UPDU OL8000RT3UPDU OL10000RT3UPDU OL6KRT3UHW OL8KRT3UHW OL10KRT3UHW CyberPower Systems (USA), Inc. 4241 12th Avenue East Suite 400 Shakopee, MN 55379 Phone: 877-297-6937 Fax: 952-403-0009 www.CPSww.com K01-0000597-00...
-
Page 2: Important Safety Instructions
CAUTION! Do not use an improper size power cord as it may cause ACCESSIBLE DISCONNECT DEVICE SHALL BE INCORPORATED IN damage to your equipment and cause fire hazards. THE BUILDING INSTALLATION WIRING. CAUTION! Wiring must be done by qualified personnel. Copyright © 2017 CyberPower Systems, Inc. - Page 3 Screw hole dust covers (10) * 2 sets USB communication cable Power cord * PowerPanel® Business Edition software is available on our website. Please visit www.cpsww.com and go Serial Interface Cable (RS-232) to the Software Section for FREE download. Copyright © 2017 CyberPower Systems, Inc.
-
Page 4: Hardware Installation
Tighten the front rail screws on the rack. Step 2: Rackmount ears & hanging brackets installation Attach two rackmount ears to the UPS using the provided M5X7L*8pcs screws and tighten two hanging brackets with the M5X6L*6pcs screws. Copyright © 2017 CyberPower Systems, Inc. - Page 5 Slide the hanging brackets on the UPS into the rails mounted in the rack with the front of the unit facing toward you. Secure the UPS to your rack with four M5X12L*4pcs screws at the front of the rack. (Located in position 5 & position 7) Copyright © 2017 CyberPower Systems, Inc.
-
Page 6: Vertical/Tower Installation
Secure the tie bracket with the screws (M5X7*4pcs). Insert dust covers into the screw holes that are not being used. ELECTRICAL INSTALLATION After completing the hardware installation of the UPS, you are now ready to plug in the UPS and connect your equipment. Copyright © 2017 CyberPower Systems, Inc. - Page 7 CAUTION! Do not work alone under hazardous conditions. CAUTION! In case of the risk of electric shock, do not remove the top cover. CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected. Copyright © 2017 CyberPower Systems, Inc.
-
Page 8: Installing Your Ups System
Make sure your equipment carries a load current within the unit’s safe temperature occurs, please check the Trouble Shooting section on page range, (refer to the technical specifications). 24. If the condition persists, please contact CyberPower for technical support. This UPS is equipped with an auto-charge feature. When the UPS is plugged into an AC outlet, the battery will automatically charge, even when the unit is switched off. -
Page 9: Hardwiring The Input/ Output Terminals
Step 1: Remove the inspection window cover Step 2: Remove the terminal block cover Loosen the four screws to remove the inspection window cover. Loosen the four screws to remove the terminal block cover. Copyright © 2017 CyberPower Systems, Inc. - Page 10 Tighten the four screws to fix the inspection window cover on the PDU’s. Step 4: Output configuration Insert the output cable through the appropriate cable gland (not included) and connect the three wires to the output terminal block. Copyright © 2017 CyberPower Systems, Inc.
-
Page 11: Backfeed Protection
3. Hardwire the input terminals and “Backfeed Protection Connector” as shown in the following diagram. 4. The external isolation device must be installed in the Mains path. Mains L1 L2 PE IP-L1 IP-L2 PSDR 2A Fuse Backfeed (Slow Blow) AC-L1 AC-L2 Copyright © 2017 CyberPower Systems, Inc. -
Page 12: Basic Operation
UPS and the connected computer. It is recommended to 12. Extended Runtime Battery Module Connector install the PowerPanel® Business Edition Agent software on the Connection for additional CyberPower XL Battery modules. PC/Server connected with the USB cord. 13. Input / Output Connectors 6. - Page 13 “CRITICAL” outlets, while stopping the power supply to 6. Input / Output Connectors equipment connected to “NONCRITICAL” outlets after a designated Use these connectors to attach the PDU or HW PDU to the Power period of time. module. Copyright © 2017 CyberPower Systems, Inc.
- Page 14 Step 5: Use a power cord to plug AC input inlet of the battery module into a wall receptacle. Step 6: Turn on the DC breaker of the Battery module. Copyright © 2017 CyberPower Systems, Inc.
- Page 15 EBM Number setting, select the appropriate number and Save. This operation can also be done if there is an RMCARD installed in the UPS, or via PowerPanel® Business Edition Agent. Please see their respective User Manuals for instructions. Copyright © 2017 CyberPower Systems, Inc.
-
Page 16: Led Indicators - Ups Status
Press this button to scroll up in the LCD menu. ▼ Press this button to scroll down in the LCD menu. ENTER Press this button to select an option. Press this button to cancel or return to previous LCD menu. Copyright © 2017 CyberPower Systems, Inc. -
Page 17: Lcd Setup Functions
Date & Time Displays the present Date & Time - - - - / - - / - - - -:- - Next BAT Change Displays the next Battery Change Date & Time XXX / XXXX Copyright © 2017 CyberPower Systems, Inc. -
Page 18: Lcd Event Log
You may be prompted to save the selection, if so press the “ENTER” button to save the setting. Some options are saved and started automatically. (See the following table for additional details.) Press the “ESC” button to cancel or return to the previous LCD menu. Copyright © 2017 CyberPower Systems, Inc. - Page 19 Configure “Audible Alarms” as “Disable” on the LCD module and it will stop warning of any malfunction audibly. MANUAL BATTERY TEST Configure “Battery Test” as “Active” on the LCD module; and it will perform the “Manual Battery Test” Copyright © 2017 CyberPower Systems, Inc.
-
Page 20: Lcd Module Remote Control And Wall-Mounting Instructions
Step 4: Mount LCD Module on the Wall SAFETY PRECAUTIONS CAUTION! It must be done by qualified personnel. CAUTION! To avoid electric shock, turn off and unplug the unit before installing REMOTE CONTROL or WALL-MOUNTING INSTRUCTIONS. Copyright © 2017 CyberPower Systems, Inc. -
Page 21: Maintenance
Only use replacement batteries which are certified by properly. Contact your local government for more information about CyberPower Systems. Use of incorrect battery type is an electrical proper disposal and recycling of batteries. Do not dispose of batteries hazard that could lead to explosion, fire, electric shock, or short circuit. - Page 22 CAUTION! Do not slide the Interlock Bracket when the LCD screen shows “Generator On” or “Converter On”. CAUTION! Do not turn the Manual Bypass Switch when hearing a warning beep from the Power module. Copyright © 2017 CyberPower Systems, Inc.
- Page 23 CAUTION! Do not slide the Interlock Bracket when the LCD screen shows “Generator On” or “Converter On”. CAUTION! Do not turn the Manual Bypass Switch when hearing a warning beep from the Power module. Copyright © 2017 CyberPower Systems, Inc.
-
Page 24: Technical Specifications
L x W x H = 6.3 x 7.8 x 10.4 / 5.2in. (16 x 19.8 x 26.4 / 13.2cm) Net Weight--Power Module 63lbs(28.5Kg) Net Weight--Battery Module 167.2lbs(76Kg) 171.6lbs(78Kg) Net Weight--PDU/HW PDU Module 9.9 / 5.5lbs(4.5 / 2.5Kg) Safety Conformance Approvals CE, UL1778, FCC part 15 Class A Copyright © 2017 CyberPower Systems, Inc. -
Page 25: Troubleshooting
Internal DC bus voltage is too high or too low. CyberPower Systems Inc. www.cpsww.com © Entire contents copyright 2017 CyberPower Systems Inc., All rights reserved. Reproduction in whole or in part ® ® without permission is prohibited. PowerPanel Business Edition and PowerPanel Personal Edition are trademarks of CyberPower Systems Inc. -
Page 26: Product Registration
If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required). - Page 27 (collectively, "High Risk Activities"). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums.
-
Page 28: Conformance Approvals
Cet appareil numerique de la class A respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada. This document is believed to be accurate, but CyberPower reserves the right to change or correct the contents and does not assume any responsibility for omissions or errors.
