AK12 Ductless Recirculation Conversion

NOTE: Skip the recirculating preparation pages if you are ducting the air out of your home.
(2)
(2)
(4)
(4)
(4)
1. For AK12, an air recirculation kit (optional) must
be purchased before using the hood in recirculation
mode.
Recirculation kit - ZRC-0012
and place it over the safety grille body.
5. Remove each screw from recirculating top plate.
Plate is located on top of hood towards the front.
Breeze I & Breeze II Use, Care, and Installation Guide
Installation Instructions
2. Secure each of the (2) spring clips to the safety
grille body. Do this by inserting the screw through
the spring and into the clip. Secure each clip to the
safety grille body by using a Phillips head
screwdriver.
by lifting up on spring clips and twisting. The clip
securely.
19
