Before You Begin

Setup Guide
1 Before You Begin
In This Chapter
Install the WirelessN Discovery Tool ..................................................... 12
Start WirelessN Discovery Tool............................................................. 13
Plug In the Cables ................................................................................. 14
Detecting the Radio............................................................................... 15
Assign an IP Address ............................................................................ 16
Set Up a Repeater................................................................................. 17
Save the Radio Configuration................................................................ 20
The following components are included with your RLXIB-IH2N-W radio, and are
all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty. Part Name
1 RLXIB-IH2N-W Radio
1 Cable
1 Cable
1 Cable
1 Power-Over-Ethernet
Power Injector
1 ProSoft Solutions CD
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
In addition, you will need:
A personal computer equipped with an Ethernet port
IP address, Subnet Mask and Gateway information for each RLX device you
plan to install. You can obtain this information from your system
administrator.
Note: This Startup Guide is designed for use with two RLXIB-IH2N-W radios. One radio will be
setup as a Master (AP) while the other radio will be set up as a Repeater.
ProSoft Technology, Inc.
April 22, 2010
Part Number Part Description
RLXIB-IH2N-W Weatherproof Dual Industrial Hotspot
RL-CBL024 5 foot Ethernet Straight-Thru Cable (Red)
RL-CBL025 5 foot Ethernet Straight-Thru Cable (Gray)
RL-CBL029 5 foot RJ45 to M12 Straight Ethernet
POE-48i RLX Power Injector, Input: 90 to 264 VAC,
Output: 0.35 A max @ 48 VDC.
Contains sample programs, utilities and
documentation for the RLXIB-IH2N-W
module.
RLXIB-IH2N-W ♦ 802.11n
Weatherproof Dual Industrial Hotspot
