Product Diagram
1
Screen
Protection
2
Ethernet port
3
USB Host port
4
Power Supply
Input
4
Front
A plastic sheet attached to the screen for protection. Remove it
during installation.
Enables you to connect the Display to the UniStream PLC via
Ethernet cable.
Note that USL-156-B05 has 2 Ethernet ports.
Provides the interface for system updates and system log access.
Note that USL-156-B05 has 2 USB Host ports.
Connection point for the Display power source.
Connect the Terminal Block supplied with the kit to the end of the
power cable.
