- Page 1 Quick Start Guide 8/16-19” LCD KVM Switch GCL1908 / GCL1916 PART NO. Q1323-a / Q1324-a www.iogear.com...
-
Page 2: Package Contents
Package Contents 1 x GCL1908 / GCL1916 19” LCD KVM with Rock Mount Kit 1 x USB KVM Cable; 1 x PS2 KVM Cable 1 x Power Cord 1 x Firmware Upgrade Cable 1 x Quick Start Guide 1 x Warranty Card 1 x Standard Long Rack Mount Kit Overview Front View:... -
Page 3: Hardware Installation
Hardware Installation Standard Rack Mounting: A standard rack mounting kit is provided with your GCL1908 / GCL1916 and can be mounted in 1U of rack space. The following diagram shows the required components to mount the LCD KVM to the rack. Note: It takes two people to mount the switch: one to hold it in place;... - Page 4 Step 2 While the first person still holds the switch in place, the second person slides the L brackets into the switch’s side mounting brackets from the rear until the bracket flanges contact the rack, then screw the L brackets to the rack. Final Step After the L brackets have been secured, tighten the front bracket screws.
-
Page 5: Open/Close Console
Open/Close Console Opening the Console The GCL1908 / GCL1916's console is located under the top cover. To access the console, slide the console module out and raise the cover. Note: As a safety precaution, to keep the console from accidentally sliding out, the console is locked into the In position. -
Page 6: Single Level Installation
Single Level Installation Please make sure the computers are powered off before you start. Step 1 Connect the power cord to the power outlet and the power socket of the LCD KVM. PS/2-USB PS/2-USB Step2 Connect a USB KVM Cable (with a green connector) or PS/2 KVM Cable (with a yellow connector) from the KVM switch to each of your computers. -
Page 7: Two Level Installation
Two Level Installation To control even more computers, up to 8/16 additional switches can be cascaded from the first GCL1908/GCL1916. As many as 128 (Cascaded with GCS1808) or 256 (Cascaded with GCS1716) computers can be controlled from a single console in a complete cascade installation. - Page 8 On-Screen Display (OSD) Operation OSD Functions OSD functions are used to configure and control the OSD. For example, you can rapidly switch to any port, scan selected ports, limit the list you wish to view, designate a port as a quick view port, create or edit a port name, or make OSD setting adjustments.
-
Page 9: Hotkey Summary Table
Invokes Skip Mode and skips from the cur- to it. [→] Invokes Skip Mode and skips from the cur- rent port to the next accessible port Note: For completed operation setting method, please download the user manual from IOGEAR support website. -
Page 10: Compliance Information
Important Product Information Product Model Serial Number Contact WE’RE HERE TO HELP YOU! NEED ASSISTANCE SETTING UP THIS PRODUCT? Make sure you: 1. Visit www.iogear.com for more product information 2. Visit www.iogear.com/support for live help and product support IOGEAR iogear.custhelp.com support@iogear.com www.iogear.com...
