ASSEMBLY
INSTRUCTIONS
BOX OF DRESSER
ITEM
DRAWING
DESCRIPTION
A
DRESSER
FRONT LEG
B
(WITH "F/L" LABEL)
FRONT LEG
C
(WITH "F/R" LABEL)
BACK LEG
D
(WITH "B/L" LABEL)
BACK LEG
E
(WITH "B/R" LABEL)
SUPPORT LEG
F
(Packed underneath
bottom panel)
REMARK : 4 PCS LEG & SUPPORT LEG
INSIDE THE BOX WHICH IS LOCATED
ON THE BOTTOM PACKING PALLET.
THE HARDWARE IS LOCATED IN THE PACKING ITEMS
THE ANTI TIPPING HARDWARE IS LOCATED IN THE RIGHT SIDE DRAWER FRONT OF DRESSER
NOTE : MUST TIGHTEN SCREWS PERIODICALLY. WITH USE SCREW MAY BECOME LOOSE.
CHECK TIGHNESS OF ALL SCREW EVERY 6-8 WEEKS.
CLEANING INSTRUCTION
After assembly, clean & polish the completed parts if necessary with soft cloth and industrial recognized furniture polish
HARDWARE LIST
QTY
ITEM
DRAWING
1
1
1
2
1
3
1
1
1
"B/R" LABEL
E
C
"F/R" LABEL
A
ITEM NO : B8270 / B8280 - 1 DRESSER
DESCRIPTION
ALLEN WRENCH
1
(M4)
CONNECTION BOLT
(M6 x 60mm)
W/WASHER &
4
SPRING WASHER
Assembly Tool
1
Not Included
COMPLETED DRESSER
1
F
ASSEMBLY
2
D
"B/L" LABEL
B
"F/L" LABEL
MADE IN MALAYSIA
PAGE 1 OF 1
