Thank you for purchasing this quality product.Be sure to check all packing material carefully for small parts which
may have come loose inside the carton during shipment.Identify and count all parts and compare with hardware
list as below:
(BOX 1) BOX OF HEADBOARD
ITEM DRAWING
DESCRIPTION
QTY
HEAD
A
1
BOARD
HB LEG
B
2
POST (L/R)
(BOX 1) BOX OF HEADBOARD
(HARDWARE LIST)
ITEM DRAWING
DESCRIPTION
DIMENSION
JCBC (M8)
C
8 x P1.0 x 35MM
WITH WASHER
D
ALLEN KEY M5
5 x 120MM
NOTE:MUST TIGHTEN SCREW PERIODICALLY.WITH USE SCREWS WILL
BECOME LOOSE CHECK THIGHT OF ALL SREWS EVERY 6-8 WEEKS.
After assembled,clean & polish the complete parts if necessary with soft clotch ang industrial recognized furniture polish.
A
SSEMBLY
CROWN MARK (CRWN)
MODEL:B6580-Q-HB / B6580-K-HB
STEP 1
QTY
4
1
A
BACK VIEW
C
C
B
C
R
D
4x
I
NSTRUCTIONS
C
C
B
L
C
D
4x
Step 1 :Attach and tighten the Leg
Post (L/R) (B) to the Head Board
(A).Insert JCBC (M8) With Washer
(C&D) to affix.
COMPLETED
ASSEMBLY
MADE IN MALAYSIA
