User Guide & Warranty
DANGER
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to
follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which may
result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not cut power
cords. Do not submerge in water or get wet.
Explosion. Unmonitored, incompatible, or damaged batteries can explode if used with product. Do not leave
product unattended while in use. Do not attempt to jump start a damaged or frozen battery. Use product only with
batteries of recommended voltage. Operate product in well ventilated areas.
Fire. Product is an electrical device that emits heat and is capable of causing burns. Do not cover product. Do not
smoke or use any source of electrical spark or fire when operating product. Keep product away from combustible
materials.
Eye Injury. Wear eye protection when operating product. Batteries can explode and cause flying debris. Battery
acid can cause eye and skin irritation. In the case of contamination of eyes or skin, flush affected area with
running clean water and contact poison control immediately.
Explosive Gases. Working in the vicinity of a lead-acid is dangerous. Batteries generate explosive gases during
For more information and
normal battery operation. To reduce risk of battery explosion, follow all safety information instructions and those
support visit:
published by the battery manufacturer and manufacturer of any equipment intended to be used in the vicinity of
battery. Review wcautionary markings on these products and on engine.
www.no.co/support
Advertisement
Table of Contents
Related Manuals for NOCO Genius BOOST PLUS GB40
Summary of Contents for NOCO Genius BOOST PLUS GB40
- Page 1 GB40 User Guide & Warranty DANGER READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT. Failure to follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY DAMAGE. Electrical Shock.
-
Page 2: Important Safety Warnings
Important Safety Warnings Proposition 65. WARNING: This product can expose you to chemicals including lead and exhaust fumes, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. Personal Precaution. Only use product as intended. Someone should be within range of your voice or close enough to come to your aid in case of emergency. - Page 3 injury. Always allow adequate ventilation around power adapters when using them.To ensure maximum battery life, avoid charging your product for more than a week at a time, as overcharging may shorten battery life. Over time, an unused product will discharge and must be recharged before use. Disconnect the product from power sources when not in use. Use the product only for their intended purposes.
-
Page 4: How To Use
How To Use Step 1: Charge the GB40. The GB40 comes partially charged out of the box and needs to be fully charged prior to use. Connect the GB40 Charger Rating: using the included USB Charge Cable to the USB IN port and the USB car charger. It can also be recharged from any USB powered port, like an AC adapter, car charger, laptop and more. - Page 5 Step 3: Jump Starting. 1. Make sure all of the vehicle's power loads (headlights, radio, air conditioning, etc.) are turned off before attempting to jump start the vehicle. 2. Press the Power Button to begin jump starting. All LEDs will flash, indicating that all LEDs are properly functioning. If you are properly connected to the battery, the White Boost LED will illuminate.
- Page 6 1. Internal Battery Level Indicates the charge level of the internal battery. 2. Error LED Illuminates Red if reverse polarity is detected, or blinks “On” and “Off” when the internal battery temperature is too high. 3. Power Button Push to turn unit "On" & "Off". 4.
-
Page 7: Troubleshooting
Troubleshooting Error Reason/Solution Error LED: Solid Red Reverse polarity/Reverse the battery connections. Error LED: Blinking Red w/Cables Connected The internal battery is too hot/ Allow the unit to cool. Bring the unit into cooler environment. Properly Boost Light Does Not Come On w/Cables Connected battery is below 2-volts/ Remove all loads, and try again, or use Manual Override Mode. - Page 8 GB40 Brugervejledning og garanti FARE LÆS OG FORSTÅ ALLE SIKKERHEDSINFORMATIONER, FØR DU ANVENDER DETTE PRODUKT. Hvis Dansk du ikke følger disse sikkerhedsanvisninger, kan det resultere i ELEKTRISK STØD, EKSPLOSION, BRAND, som kan resultere i alvorlig skade, død eller ejendomsskade. Elektrisk stød. Produktet er en elektrisk enhed, der kan give stød, og forårsage alvorlig skade. Skær ikke i strømledninger.
-
Page 9: Vigtige Sikkerhedsadvarsler
Vigtige sikkerhedsadvarsler Forslag 65. Batteriposter, terminaler og tilhørende tilbehør indeholder kemikalier, herunder bly. Disse materialer er kendt for i staten Californien, at forårsage kræft og fødselsdefekter, samt anden reproduktiv skade. Personlig sikkerhedsforanstaltning. Brug kun produktet som anvist. Nogen skal være indenfor rækkevidden af din stemme, eller tæt nok til at komme til din hjælp, i tilfælde af en nødsituation. - Page 10 det i stikkontakten. Strømadaptere kan blive varme under normal brug, og langvarig hudkontakt kan forårsage personskade. Sørg altid for tilstrækkelig ventilation omkring strømadapterne, når du bruger dem. For at sikre maksimal batterilevetid, skal du undgå at oplade dit produkt i mere end en uge ad gangen, da overopladning kan forkorte batteriets levetid.
- Page 11 Sådan bruges det Trin 1: Oplad GB40-enheden. GB40 leveres delvis opladet i kassen, og skal være fuldt opladet før brug. Tilslut GB40 med det medfølgende Opladning vurdering: USB-opladningskabel til USB IN-porten og USB-bil opladeren. Den kan også oplades fra enhver USB-port som en vekselstrømsadapter, biloplader, bærbar pc, m.m.
- Page 12 Trin 3: Kabel start 1. Sørg for, at alle køretøjets strømbelastninger (forlygter, radio, klimaanlæg, osv.) er slukket, før du forsøger at starte bilen. 2. Tryk på tænd/sluk-knappen for at begynde at starte. Alle lysdioder blinker, hvilket indikerer, at alle lysdioder fungerer korrekt. Hvis du er korrekt forbundet til batteriet, lyser White Boost-LED'en.
- Page 13 1. Internt batteriniveau Angiver opladningsniveauet for det interne batteri. 2. Fejl LED lyser rødt, hvis omvendt polaritet detekteres, eller blinker "On" og "Off", når den interne batteritemperatur er for høj. 3. Tryk på Tænd/sluk-knap, for at at tænde for "On" & "Off". 4.
-
Page 14: Tekniske Specifikationer
Fejlfinding Fejl Årsag / Løsning Fejl LED: Fast rød Omvendt polaritet /Slår batteriets tilslutninger tilbage. Fejl LED: Blinker rød med cabler forbundet Det interne batteri er for varmt /Lad enheden køle af. Opbevar enheden i køligere omgivelser. korrekt Boost lys tændes ikke med kabler korrekt Tilsluttet batteri er under 2 volt /Fjern alle belastninger, og prøv igen, eller brug manuel overstyringstilstand. - Page 15 Garanti NOCO One (1) års begrænset garanti. NOCO virksomheden ("NOCO") garanterer, at dette produkt ("Produktet") er fri for fejl i materiale og udførelse, i en periode på et (1) år fra købsdatoen ("Garantiperioden"). For mangler, der indberettes i garantiperioden, vil NOCO efter eget skøn og underlagt NOCOs tekniske supportanalyse enten reparere eller udskifte defekte Produkter. Udskiftningsdele og produkter vil blive brugt som nyt eller anvendeligt, sammenlignelige i funktion og ydeevne til den oprindelige del og garanteret for den resterende del af den oprindelige garantiperiode.
