StarTech.com USB32HD2 Quick Start Manual

USB to HDMI / DP / VGA Adapter - Supports Windows Only
This Quick-Start Guide covers the following StarTech.com Products:
Product ID
USB32HD2 USB 3.0 to Dual HDMI Adapter
•
USB32HDES Slim USB 3.0 to HDMI External Video Card
•
USB32HDEH USB 3.0 to HDMI® Adapter with USB Hub Port
•
USB32HD4 USB 3.0 to 4x HDMI Adapter - 1080p
•
USBC2HD4 USB-C to 4x HDMI Adapter - 1080p
•
USB32DPES2 USB 3.0 to DisplayPort Video Adapter
•
USB32VGAES Slim USB 3.0 to VGA External Video Card
•
Requirements
For the latest drivers/software, technical specifications, and declarations of conformance,
please visit: www.StarTech.com/Support
Driver Installation
Installation is automatic for Windows 10 & up, in most situations. If the drivers do not
automatically install, contact your IT administrator or department to allow the driver
installation. If you are using another supported operating system, the latest drivers are
available at: www.StarTech.com/Support
Installation
Installing the Video Adapter
Connect the USB Host Connection to an available USB Port, on the Host Computer.
1.
Note: This adapter is supported on Windows only
Connect an HDMI, DisplayPort, or VGA Cable (sold separately) from the Video Output
2.
on the USB Video Adapter, to the HDMI, DisplayPort, or VGA Input on the Display.
Arrange the display using Windows built-in Display Settings.
3.
(Optional) Change the default Audio Device to the USB Video Adapter using Windows
4.
built-in Sound Settings.
Note: VGA does not support audio output
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Title
Quick-Start Guide
Manual Revision: May 31, 2023 10:46 AM
