USB 3.0 to HDMI® Video Adapter with USB Hub Port
Product Diagram (USB32HDEH)
1
Component
• Used to connect an HDMI Display Device to
1
HDMI Port 1
the Video Adapter.
USB 3.0 Pass Through
• Used to connect a USB Device to the Video
2
Port
Adapter.
• Used to connect the Video Adapter to a Host
Integrated USB 3.0
3
Computer.
Input Cable
Requirements
For the latest requirements, please visit
• One HDMI® display with cabling
• A computer system with an available USB 3.0 port
• Operating System:
• Windows® 10, 8.1, 8 or 7
Package Contents
• USB 3.0 to HDMI Adapter x 1
• HDMI to DVI Adapter x 1
• Software CD x 1
• Quick-Start Guide x 1
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
2
3
Function
www.startech.com/USB32HDEH
Installation
Notes: You may need to restart your computer during the software installation
process. Be sure to save any unsaved material before you install the software.
Ensure the Video Adapter is not connected to your computer. Download the latest
drivers from the
www.StarTech.com/USB32HDEH.
1. The software will be compressed in a .zip folder. Extract the contents of the folder
to a location on your computer that's easy to access, such as your Desktop or
Downloads folder.
2. Launch the Setup(.exe) file.
3. Follow the on-screen prompts to complete the installation.
4. Connect an HDMI Cable to the HDMI Output Port on the Video Adapter and to an
HDMI Display Device.
5. Once the Host Computer has restarted, connect the Integrated USB 3.0 Input
Cable to a USB 3.0 port on the Host Computer.
Notes: If connecting multiple USB video adapters or docking stations to a single
computer:
The Video Adapter uses a Trigger family chipset. If you're connecting this device to a
computer along with additional USB video adapters or docking stations, avoid using
devices with different family chipsets, such as DisplayLink® or Fresco Logic®.
To connect multiple USB display adapters to the same computer, you don't need to
install any additional drivers. Repeat steps 4 - 5 for each video adapter.
You may be prompted to restart your computer during the installation of each video
adapter.
Configuring the Video Adapter Settings
Video Configuration
1. Right-click on the Video Adapter icon
clock).
2. Click on Screen Resolution.
3. Select the monitor you want to change the settings on.
4. Adjust the screen resolution and orientation as needed.
Quick-Start Guide
on your Windows System Tray (next to
Manual Revision: July 24, 2019 2:12 PM
