If you have installed the balcony solar system, you need to disconnect it
according to the following steps:
1
Unplug the cables of the Microinverter and the home grid.
1
Only unplug the cables of the first solar panel and the Microinverter.
2
Tips: The installation of the solar panel does not need to be moved unless
you want to change the location.
The same way to unplug the cables of the second solar panel and the
3
Microinverter.
Unscrew the mounting screws of the Microinverter, remove the
4
Microinverter fixed on the solar panel or metal bracket.
Tips: Ensure that the state after disconnection is as shown in following
figure.
10
3
4
2
