5. HANDLING AND STORAGE

Keep this device in the carrying case and store it at room temperature.

6. SPECIFICATION

Channel
Pulse Amplitude
Pulse Frequency (Hz)
Pulse Width (µs)
Waveform
Timer Control (mins)
Power Supply
Size (D x W x H)
Weight (including battery)
Safety standard
Operation Ambient Temperature Range
Operation Ambient Humidity Range
Storage & Transportation Temperature Range
Storage & Transportation Humidity Range
All values have ±10% tolerance.
Dual channels, isolated between channels
0 ~ 80 mA = 0 ~ 40 volts, adjustable (at 500 ohm load)
2 ~ 150
60 ~ 250
Asymmetric biphasic square pulse.
30, 60, or Constant
9V DC square shape battery
1.0" x 2.4" x 3.6" (26 mm x 62 mm x 91 mm)
4.4 oz (126 g)
EN 60601-1, EN 60601-1-2, IEC 60601-2-10
50 ~ 95ºF (10 ~ 35ºC)
20 ~ 90% RH
32 ~ 158º F (0 ~ 70ºC)
20 ~ 90% RH
