4. INSTRUCTIONS FOR USE

NOTE: Always read this instruction manual before use.
PREPARATION FOR USE

4.1 Check Battery:

Insert a fresh 9V alkaline or rechargeable battery into the battery compartment. Make
sure you are installing the battery properly. The battery is inserted in the casing on the
foot of the stimulator unit.
BE SURE TO MATCH THE POSITIVE AND NEGATIVE ENDS OF THE BATTERY TO
THE MARKINGS IN THE BATTERY COMPARTMENT OF UNIT.
CONNECTING THE STIMULATOR

4.2 Connect electrodes to lead wires:

Insert the lead wire connector into electrodes connector (standard 0.08 inch female
connection). MAKE SURE NO BARE METAL OF THE PINS IS EXPOSED
Caution:
Always use the electrodes with the requirements of the EN60601-1 and EN60601-2, such as with
CE mark, or which are legally marketed in the US under 510(K) procedure.
9
