AFNOR CERTIFICATION - 11, RUE FRANCIS DE PRESSENSE 93571 LA PLAINE SAINT-DENIS CEDEX FICHE INFORMATIVE La marque NF garantit la qualité de cet article suivant les normes françaises NF 128 45 / 02 et Règles de certification de l’application NF 128 CONFORME A LA NORME NF D 35-300 ET AUX SPECIFICATIONS COMPLEMENTAIRES DEFINIES PAR LES REGLES DE CERTIFICATION DE LA MARQUE NF 128...
Page 3
Thank you for choosing a “TOYOTOMI” product! Toyotomi products are used by satisfied customers worldwide. In order to assure the comfortable and safe use of our products by customers in each country, our products conform to the safety standards not only in Japan but also in every country around the world we do business with.
GENERAL DIRECTIONS FOR USE Below you will find the main steps to be taken for using your heater. For more details, please refer to the MANUAL. Remove all packaging materials (refer to Section A, Fig. A). Fill the removable tank 6 (refer to Section B, Fig. C). Insert the plug into the wall-socket.
WHAT YOU NEED TO KNOW IN ADVANCE ventilate sufficiently This heater is equipped with an air quality control system . When there is insufficient ventilation in the room or when the heater is being used in a room which is too small, the heater will shut off automatically. For comfortable and safe heating ensure that there is sufficient ventilation.
Page 6
MANUAL installinG tHe HeateR Carefully remove your heater from the box and check the contents. In addition to the heater you also need to have: a transportation cap these directions for use Keep the box and the packaging materials (Fig. A) for storage and/or transportation.
Page 7
6 Check whether the fuel cap is straight and tightened properly. Reinstall the removable tank in the heater (cap down). Close the lid. settinG tHe clOcK It is only possible to set the correct time, when the heater is connected to the mains and not burning.
usinG tHe tiMeR The timer allows you to switch on the heater automatically at a preset time. In order to switch on the timer, the correct time must have been set (refer to Section C) and the heater should be off. Follow the procedure below: Press the button L and then the TIMER key O immediately after that.
e - 5 Tipping-over protection. Re-ignite the heater. e - 6 Poor burning. Contact your dealer. e - 7 Room temperature If necessary, above 32°C. re-ignite the heater. e - 8 Defective booster. Contact your dealer. e - 9 Air filter dirty; or Clean filter.
tHe ‘fuel’ inDicatOR When the FUEL indicator appears, it means that there is only fuel left for 10 more minutes. The count-down of the remaining heating time can be seen in the information display K (Fig. J). If you do not react, the heater will extinguish by itself. The heater will also J: When the FUEL sound a warning signal, when it switches off.
Page 11
stORaGe (enD Of tHe HeatinG seasOn) At the end of the heating season, you must store the heater in a dust-free place, if possible in its original packaging. Unused fuel cannot be used in the next heating season. We therefore recommend that you burn up all fuel. If there is still some fuel left, do not throw it away, but dispose of it in accordance with the local regulations for the disposal of domestic chemical waste.
Page 12
sPecificatiOns Ignition electrical Dimensions (mm) width Fuel paraffin including base plate: depth Capacity (kW) max. 3.00 height Capacity (kW) min. 0.80 Accessories: - transportation cap Suitable space (m 50-120 Mains 230 V Fuel consumption (l/hr) 0.313 -- AC / 50 Hz Fuel consumption (g/hr) Electrical consumption: Burning time per tank (hr)
14 tiPs fOR safe use Children should be supervised to ensure that they do not play with the appliance. Do not move the heater when it is burning or still hot. Do not refill nor service the heater when it is burning or still hot. Position the front of the heater at a distance of minimum 1.5 metres from walls, curtains, and furniture.
Main cOMPOnents front plate Grid Base plate lid for removable tank Operation panel Removable tank fuel gauge removable tank vent filter thermostat Plug + cord ...
Page 15
Distributed in Europe by TOYOTOMI EUROPE SALES B.V. Should you require further information or should particular problems occur that are not dealt with in this operating manual, please visit our website www .toyotomi .eu or contact our Sales Support (you find its phone number on www .toyotomi .eu) Falls Sie weitere Informationen wünschen, oder sollten besondere Probleme auftreten, die in dieser Bedienungsanleitung nicht ausfürhrlich genug behandelt werden, besuchen Sie bitte unsere Website (www .toyotomi .eu), oder fordern Sie die benötigte Auskunft von...
