1.3

System specifications

The ASUS ESC4000 DHD G4 server features the ASUS Z11PG-D16-HD Series server board
that supports Intel
family.
Model Name
Processor
Chipset
Memory
Expansion
Slots
1-4
LGA 3647 Xeon
® ®
2 x Socket P (LGA 3647)
1st and 2nd Gen Intel
UPI 10.4 GT/s
* Refer to support page for more information
Intel C621 PCH
®
16 (6-channel per CPU, 8 DIMM per CPU)
Total Slots
Maximum up to 2048GB
Capacity
DDR4 2933* (1 DIMM per Channel)
DDR4 2666/2400/2133 RDIMM/LRDIMM/LRDIMM 3DS
(2DIMM per Channel)
Memory Type
Intel Optane™ DC persistent memory (DCPMM)
®
* 2933MHz will drop to 2666MHz when using 2DPC configurations
** Refer to ASUS server AVL for the latest update
32GB, 16GB, 8GB, 4GB (RDIMM)
64GB, 32GB (LRDIMM)
Memory Size
128GB, 64GB (LRDIMM/RDIMM 3DS)
* Refer to ASUS server AVL for the latest update
Total PCI/PCI-X/
6
PCI-E Slots
4 x PCI-E x16 (Gen3 x16 Link)
Low-profile(Rear):
Slot Type
2 x Gen3 x16 Link
(continued on the next page)
processor from the Skylake F and Skylake-SP product
ESC4000 DHD G4
Xeon Processor Scalable Family (150W)*
® ®
Chapter 1: Product Introduction
