Certification
6.2 EMC and Environmental Type Tests
a
Siemens-specified severity levels.
EMC Immunity Type Tests for IEEE 1613
Note
The RUGGEDCOM RX1510 meets Class 2 requirements for an all-fiber
configuration and Class 1 requirements for copper ports. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
Dielectric Strength
Environmental Type Tests
IEC 60068-2-30
IEC 60255-21-1
IEC 60255-21-2
54
All manuals and user guides at all-guides.com
Test
HV Impulse
Description
HV Impulse
Fast Transient
Oscillatory
Radiated RFI
ESD
Test
IEC 60068-2-1 Cold Temperature
IEC 60068-2-2
Humidity (Damp
Heat, Cyclic)
Description
Signal ports
DC Power Ports
AC Power Ports
Signal ports
DC Power Ports
AC Power Ports
Signal ports
DC Power Ports
AC Power Ports
Signal ports
DC Power Ports
AC Power Ports
Earth ground ports
Signal ports
DC Power Ports
AC Power Ports
Enclosure ports
Enclosure Contact
Enclosure Air
Description
Test Ad
Dry Heat Test Bd
Test Db
Vibration
Shock
Bump
Test Levels
5 kV (Failsafe Relay output)
5 kV
Test Levels
5 kV (Failsafe Relay Output)
5 kV
2 kV
1.5 kV
2 kV
± 4 kV @ 2.5 kHz
± 4 kV
2.5 kV common mode @1MHz
2.5 kV common
1 kV differential mode @ 1 MHz
35 V/m
± 8 kV
± 15 kV
Test Levels
-40 °C (-40 °F), 16 Hours
85 °C (185 °F), 16 Hours
95% (non-condensing),
55 °C (131 °F), 6 cycles
2 g @ 10-150 Hz
30 g @ 11 ms
10 g @ 16 ms
RUGGEDCOM RX1510
Installation Manual, 04/2021, C79000-G8976-1055-20
Severity
Levels
Severity
Levels
Class 2
Class 2
Class 1
