PREMIER DL 109/110
DIESEL ENGINE
OPERATOR'S MANUAL
Compatibility
This engine will operate on any
traditional O-31 Gauge track system,
including M.T.H.'s RealTrax® or
ScaleTrax™ or traditional tubular
track. It is also compatible with most
standard AC transformers. See pages
46 and 47 for a complete list of
compatible transformers, power packs
and wiring instructions.
PFA
Passenger/Freight
Announcements
PLEASE READ BEFORE USE AND SAVE
www.mthtrains.com
