New Classic Furniture ARIES B561-500 Assembly Instructions

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the parts list and/or hardware list shown.
PARTS LIST
No
A Headboard
B Footboard
C Headboard Leg(L&R)
Bed Roll-Out Slats
D
Side Rail Left
E
Side Rail Right
F
G Side Rail Leg
Attach Head Board Leg ( C ) to Head Board ( A ) as shown using JCBC BOLT( 1 )with
STEP 1.1 :
Flat washer (2)and securing with ALLEN KEY ( 3 ) .
STEP 1.2 : Fix the other holes with Csk Screw (5) as shown.
A
RIGHT
NOTE : MUST TIGHTEN SCREWS PERIODCALLY WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
ASSEMBLY INSTRUCTIONS
B561-500 ARIES 3/3 T PANEL BED-HB/FB/RAILS
ITEM Qty
1 pc
1 pc
2 pcs
2 sets
2 pcs
2 pcs
2 pcs
C
LEFT
BACK VIEW
STEP 1.1 :
HARDWARE LIST
No ITEM
JCBC M6 x 30mm
1
Flat Washer 1/4"ID x
2
19mmOD Blk
ALLEN KEY
m4x65mm Blk
3
(FOR HB LEG)
ALLEN KEY
m5x65mm Blk
4
(FOR SIDE RAIL)
Flat Head Chipboard
5
Screw m4x32mm Rbw
C
2
4x
Qty
12 pcs
12 pcs
1 pc
1 pc
32 pcs
3
1
C
8x
STEP 1.2 :
5
1 OF 2
