Tolga - 22R
Assembly Instructions
Dimensions
Width - 75cm
Depth - 51,75cm
Height - 180cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 03456 400 800
- Please keep for future reference
323/6132
BLUE
332/9489
PINK
338/8509
OAK
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
323/6132
332/9489
338/8509
Issue 1 - 27/11/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Tolga 323/6132
Summary of Contents for Argos Tolga 323/6132
- Page 1 332/9489 PINK 338/8509 Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 03456 400 800 Issue 1 - 27/11/14...
-
Page 2: Handy Hints
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed or put weight on the product, the likelihood of on the following pages. - Page 3 Components - Panels If you have damaged or missing components, 03456 400 800 call the Customer Helpline: Please check you have all the panels listed below Left Side x 1 Right Side x 1 Back x 1 (1800 x 497 x 15mm) (1800 x 497 x 15mm)
-
Page 4: Tools Required
Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. FK1011 FK1010 FK1012 15mm 12mm Locking screw x 26 Locking nut x 4 Large locking nut x 22... - Page 5 Assembly Instructions Step - 1 Insert large locking nuts C into plinth 9. Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of 9. Put drop of glue L into the 2 holes of plinth 9. Put dowels F into the holes of plinth 9.
- Page 6 Assembly Instructions Step - 3 Attaching runners a: Fix runner left part A N on left side 1 as shown usesing 10mm fixing screw drawer E into left side 1. Note: look carreful for the right postion. Screw 24mm locking Finished screw A into left side 1.
- Page 7 Assembly Instructions Step - 5 Insert large locking nuts C into top 5. Make sure the ‘arrow’ on locking nuts C points towards the hole in the edge of 5. Step - 6 Attaching panels Put drop of glue L into the 2 holes of left side 1 and right side 2 on the bottom of the sides.
- Page 8 Assembly Instructions Step - 7 Fitting back panel Attach back 3 to the back with the coloured surface facing the inside using nails G. Use nail holder M to hold the nails G vertical and at correct distance as you secure the back 3. Nails G should be spaced about 150mm apart.
- Page 9 Assembly Instructions Step - 9 Preparing drawer Insert locking nuts B into left drawer side 0 and right drawer side @. Make sure the ‘arrow’ on locking nuts B points towards the hole in the edge of 0 and @. Put drop of glue L into the 3 holes of left drawer side 0 and right drawer side @.
- Page 10 Assembly Instructions Step - 12 Turn over drawer. Fix runner left part B O on left drawer side 0 as shown using 12,5mm pozi screw D. Fix runner right part B Q on right drawer side @ as shown using 12,5mm pozi screw D.
- Page 11 Assembly Instructions Step - 13 Hanging doors With help, slot hinge door U onto hinge back T. Note: Look firts to ‘assemble’ on page ‘hinge 20kg instructions’ For adjusting the doors 4 see ‘adjustment’ on page ‘hinge instructions’ Inserting hanger rail Insert hange rail large S into hanger rail support M.
- Page 12 Assembly Instructions Step - 14 Inserting drawers as shown. For adjusting the drawers see ‘adjustment’ on page ‘drawer adjustment’. Position L-bracket J on top 5 as shown, fix using screw F. Note: there is no pre-drilled hole for screw F. Use V to fix on the wall, please see last page for more information.
- Page 13 A Guide to - Hinge instructions Assemble Hinge back x 6 Hinge door x 6 a: Hook hinge door correctly to the hinge back as shown. b: Tighten screw to lock hinges in position. Note: The nick screw of hinge door should slide into the recess of hinge back.
- Page 14 A Guide to - Drawer adjustment Adjustment Runner left part A x 2 Runner right part A x 2 Note: Each drawer can be adjust for approximately 1mm up or down on each site of the drawer. Remove drawer, adjust the wheel from runner left part and runner right part as shown.
-
Page 15: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
