102 mm
127 mm
(4 in.)
(5 in.)
2. Bolt or screw the panel-mount accessory to a panel.
3. Connect the PE ground terminal on the cFP-1808 to safety ground.
Caution
panel.
cFP-1808 Quick Start Guide
Disconnect power before removing the backplane from the
457 mm (18 in.)
476 mm (18.7 in.)
6
ni.com
