National Instruments TB-4300/C User Manual

Datasheet
USER GUIDE AND TERMINAL BLOCK
SPECIFICATIONS
NI PXIe-4300 and TB-4300/B/C
8 Ch, 250 kS/s, 300 V Ch-Ch Isolated Analog Input Module
This document describes how to install, configure, and set up the NI PXIe-4300 with the
TB-4300/4300B/4300C (TB-4300/B/C) terminal block, connect signals, and verify that the
system is working properly. Current versions of NI documents are available at
.
manuals
The TB-4300/B/C terminal blocks are designed for use with the following module as specified:
NI PXIe-4300 ................................................... 10 V maximum voltage measurement range,
TB-4300.................................................... 10 V maximum voltage measurement range,
TB-4300B ................................................. 300 V maximum voltage measurement range,
TB-4300C ................................................. 20 mA maximum current measurement range,
Note
modules that could be damaged by the voltage present on the terminal block.
However, you should only use these terminal blocks with their supported modules.
Caution
insulated from human contact.
Caution
terminal, safety low-voltage (≤30 V
any other terminal.
Caution
terminal block without the terminal block being connected to the NI PXIe-4300.
