I-Tech BMil21730-8HDMI Quick Installation Manual

2U MILITARY GRADE DUAL SLIDES RUGGED RACKMOUNT LCD KEYBOARD DRAWER
17.3" FHD TFT LCD -1920x1080 , Brightness:400nits (Typ) View
angle:160(H)/140(V) Contrast ratio:600:1(Typ) Color:16.7 M
colors, Input Device:81 keys backlight plastic membrane
keyboard with 5 levels brightness adjustable, Stainless steel
Trackball, USB input Power input:110-220VAC input Tempered
glass to protect screen 20" deep. Design to meet: MIL-STD-810G
Wide temperature 0-60C, Vibration & Shock with 8-ports combo
HDMI + USB KVM, included KVM cables 6ft long
Model: BMil21730-8HDMI
The BMil21730-8HDMI only occupies a fraction of the space of traditional monitor and keyboard units, the installation of
the BMIL leaves ample room for other critical components. The monitor keyboard unit has a built-in slide rail and mounts
easily into any 19" rackmount cabinet.
The BMil21730-8HDMI is a 2U dual rail rack mount monitor drawer with a full HD 17.3" monitor, keyboard, and trackball. The
LCD is built into the cover and the keyboard and trackball are built into the base, allowing you to independently use the
monitor or keyboard thanks to the dual rail system.
FEATURES:
Built-in Dual rails to meet the flexible use needed
■
Mechanism meets EIA/ECA-310- 19" Rackmount 2U, depth: 500mm
■
Cabinet mounting: with fixed rear extend holder up to 600mm (Std) with Jonathan rails up to 600mm (Options)
■
Touch Panel ( Optional)
■
SPECIFICATIONS:
Ports
Weight
Dimensions
Power Supply
Construction
Keyboard
Pointing Device
Protection
Approvals
Display
Size
Resolution
Brightness
Contrast Ratio
Viewing Angles
Display Colors
*Specifications subject to change without notice, not responsible for typographical errors.
DESIGNED to MEET:
Temperature, MIL-STD-810G, Method 501.5, Procedure II (0 ~ +60C)
■
Temperature, MIL-STD-810G, Method 501.5, Procedure I (-20 ~+80C)
■
Vibration, MIL-STD-810G, Method 514.6, Procedure II , Random General vibration,
■
Shock, MIL-STD-810G, Method 516.6, Procedure II , Saw tooth wave, 20G/11ms,
■
8-ports combo HDMI + USB KVM
38 lbs
482.60 x 88.9x 500 mm (19"x 3.5"x 19.7")
110-220VAC input
Heavy Duty Steel Frame
81-backlight keys with 5 levels of adjustable brightness
Stainless steel Trackball
Tempered glass
CE, FCC, UL, RoHS
17.3" FHD TFT LCD
1920x1080
400 nits (Typ)
600 : 1 (Typ)
160(H)/140(V)
16.7 M colors
