- Page 1 8/16 Port LCD KVM Switch JKP115-801e/117-801e JKP115-1601e/117-1601e LCD Control Console JKP115e/117e User Manual...
-
Page 3: Table Of Contents
JKP115-801e/117-801e & JKP115-1601e/117-1601e LCD KVM SWITCH MANUAL CONVENTIONS................P1 TECHNICAL SUPPORT..................P1 INTRODUCTION.................P1 APPLICATIONS................P2 OVERVIEW................P2 FEATURES ................P3 PACKAGE CONTENTS................P4 EQUIPMENT REQUIREMENTS..............P4 SPECIFICATIONS................P5 DISPLAY DIAGRAMS................P6 INSTALLATION................P8 HARDWARE INSTALLATION..............P9 LCD DISPLAY CONTROLS AND FUNCTIONS.............P10 SINGLE SWITCH INSTALLATION.............P13 MULTIPLE STAGE (CASCADING) INSTALLATION..........P14 CONNECTING EXTERNAL MOUSE..............P14 OPERATION..................P17... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing VeloxView LCD Console KVM server management solution. Designed for IT professionals the 8 (JKP115-801e/117-801e) and 16 (JKP115-1601e/117-1601e) port JKP1 series leverages the power of existing server networks with minimal intrusion. Highly efficient it allows centralized access and control of up to 128/256 computers (via Cascading) from an integrated 1U console drawer;... -
Page 5: Applications
APPLICATIONS The JKP115-801eJKP1/117-801e/115-1601eJKP1/117-1601e switch offers IT managers and MIS staff consolidated control of hundreds of computers via a single integrated console. Applications include: ISPs / IDCs Data centers & server firms Test labs OVERVIEW OSD (On Screen Display) An intelligent menu system designed to easily access and control multiple servers. Hot Keys Hot keys allow you to use designated key commands to switch computers. -
Page 6: Features
Control 8 and up to 16 computers directly from a single PS/2 console Multi Bank installation (Cascaded) - control up to 128 / 256 computers respectively Allows users to control up to 8 (JKP115-801e/117-801e) and up to 16 (JKP115-1601e / JKP117-1601e) computers directly from an integrated 1U console drawer... -
Page 7: Package Contents
PACKAGE CONTENTS Item Remark JKP115-801e / 117-801e/ 19”Rackmount LCD KVM drawer JKP115-1601e / 117-1601e Power adapter Bracket User Manual Flash Cable Power Cord Please check to make sure that each item of the above list is included in your JKP1 package. Contact your dealer immediately if any item is missing or damaged in shipment. - Page 8 Note: Specifications are subject to change without notice.
-
Page 9: Display Diagrams
DISPLAY DIAGRAMS M-115-801e/817/115-1601e/117-1601e Front View Console Drawer Handle LCD Display (15”/17”) LCD Display Control (see the LCD Display Guide for details) Power Switch LCD Bank Display External Mouse Port Touchpad Mouse & Touch Pad Switch Rack Mounting Brackets Manual Port selectors (1-8 / 1-16) - Page 10 617JKP1 Rear View 1. DC Input 2. Firmware Upgrade Port 3. PC Ports...
-
Page 11: Technical Support
INSTALLATION Where to Place the Switch The enclosure of the JKP1 Switch is designed for standalone or rack-mount configuration. The Switch is natively rack-mountable in a standard 1U (19”) server rack. Rack-mount hardware is included with your switch for a sturdy rack installation. Cautions and Warnings Avoid placing cables near machines that create electrical noise such as fluorescent lighting, air conditioning equipment, etc. - Page 12 Please follow these simple steps to install the JKP1 into a server rack: Adjust the sliding rack mount brackets to match the depth of your server cabinet. Fix both brackets at a desired height to the server cabinet rails. (Note: The slider brackets are extendable to a rack depth of 22” to 36”.) Gently slide the JKP1 chassis into the fixed brackets of the rack rail assembly.
- Page 13 LCD FLAT PANEL DIPSLAY Panel Controls and OSD Functions Press “MENU” Button, display will show following picture. Continue to press “ “ and “ ” button to select function. Then, press “ SEL” to enter these functions and adjust them to your personal Auto Brightness Contrast Horizontal...
- Page 14 Auto Brightness Contrast Horizontal Vertical Color OSDHP OSDVP OSD Time Language Recall Exit Press the “SEL” button to enter. Use the “ “ and “ ” button to adjust the brightness of the display. Press the “SEL” button to go back to main menu. Brightness Adjust LCD brightness level 0-255 of the image.
- Page 15 Horizontal Adjust LCD display horizontal level 0-255 Vertical Adjust LCD display vertical level 0-255 Recall Adjust LCD setting back to previous setting Color OSDHP Adjust OSD horizontal level 0-255 OSDVP Adjust OSD vertical level 0-255 OSD TIME Adjust OSD time 5-60 seconds Language Chinese, English Recall...
-
Page 16: Single Switch Installation
7/115-1601e/117-1601e SINGLE SWITCH INSTALLATION This section provides complete instructions for the hardware setup of a single JKP1-KVM switch in which there are no other KVM switches cascaded. Connecting the Computers Power off all computers. Using all-in-one KVM Cable set (Part No. K15C6P) take the male (HDDB-15pin) connector and plug it into the PC1 port indicated on the rear of the KVM Switch. -
Page 17: Multiple Stage (Cascading) Installation
This section provides complete instructions for the hardware setup of installing cascaded computers. To control even more computers, up to 8 (JKP115-801e/117-801e) and 16 (JKP115-1601e/117-1601e) additional switches can be cascade from the CPU ports of the First Stage (Master) switch. The cascaded Switches that connect back to the First Stage switch are referred to as Second Stage switches (or BANKS) and assigned a location. - Page 18 Connect the PS/2 keyboard and mouse connectors of the KVM cable set to the second stage switch’s console keyboard and mouse ports. Note : The above working diagram represents an JKP1610LS (16 port) KVM switch cascaded with the JKP115-801e/17JKP1 KVM switch.
- Page 19 Connecting the Power Supply Connect the power cord to the power jack on the rear of the JKP1 KVM switch. Then plug the power cord into an available power outlet. For all KVM switches attached, connect in turn, the “DC 9V, 600mA” power adapter to the power jack on the rear of each switch.
-
Page 20: Operation
OPERATION Controlling your computers with the JKP1 series couldn’t be easier. The JKP1 series allows you to access the computers using three simple methods: Hot Keys Manual Selectors OSD (On Screen Display) Menu PC Manual Selectors You can select any computer or access any Bank by using the PC selectors located at the top left of the console draw. - Page 21 Press [SCROLL LOCK], [SCROLL LOCK], “ ” Multiple Switch Installation / Cascade: Note: The above working diagram represents an JKP1610LS (16 ports)KVM Switch cascade with the JKP115-801e/117-801e KVM Switch. For example, To access a PC with the port ID 0008:...
-
Page 22: Quick View Scan Mode
Reset PC Name This function resets PC Name settings to default values. Quick View Scan Mode The Quick View Scan feature allows you to monitor the activity of the connected computers at regular intervals so that you can monitor the computer activity without having to take the trouble of switching yourself. -
Page 23: Hot Key Summary
HOT KEY COMMANDS SUMMARY Note : 1.The [SCROLL LOCK] key must be pressed within 2 seconds. 2. The “Shift” key can be another Hot Key choice. 3. You will find that after the KVM unit switches to another computer, there is a mouse-keyboard delay of 1-2 seconds. -
Page 24: Osd Operation
OSD OPERATION The On Screen Display (OSD) is an intelligent menu system designed to help administrators set up and easily access and control a multiple server installation. The menu driven interface consists of a main Overview menu and an Administrative sub-menu from which users can perform multiple tasks from naming servers to configuring operations. - Page 25 15-801e/817/115-1601e/117-1601e Navigation Use the following to navigate through the OSD menu: To escape from the OSD menu or sub-menu, press the [Esc] key. To move up and down through the screen list use the Up / Down arrows. Move the highlight bar to the desired location and press [Enter] to activate a port. OSD Main Menu Functions This section provides details on the use of the following OSD functions;...
- Page 26 Accessing computers using the OSD: To access computers of the Master Switch Invoke the Hot key mode by pressing the [SCROLL LOCK] key twice within two seconds. Key in [SPACE] Move the highlight bar between 1 and 8. Press [ENTER] to gain access to the computer shown with a symbol.
- Page 27 According to the previous OSD, port 1 of the Master Switch is cascaded. In order to access the Slave Switch, move the highlight bar to port 1 and press [ENTER] to access the slave switch. Press [SCROLL LOCK] key twice within two seconds. Key in [SPACE].
- Page 28 ENTER To confirm a selection and save the content input press [ENTER]. [ESC] To exit the current OSD menu press [ESC]. OSD Administration Sub-Menu This section provides details on configuring default Hot keys to setting up user password access. To access the Administration sub-menu complete the following: 1.
-
Page 29: Firmware Upgrades
OSD Function Description CHANGE HOT KEYS Changes the default HOT Key option (Scroll Lock <-> Shift CHANGE SCAN TIME Quick View Scan allows users of large installations hands-free automatic scanning and viewing of all connected ports for a selected time interval. You may choose 7, 15, 30, or 60 seconds. - Page 30 An available serial port on the computer. A custom serial cable (8 pin to RS232 9 pin) included in package . Firmware update files available at customer support web site. Set Up To setup for the flash upgrade, do the following: Open the firmware upgrade program by double clicking on the latest firmware file from customer support web site.
-
Page 31: Package Contents
LCD CONTROL CONSOLE JKP115e/117e OVERVIEW The JKP115e/117e is a rackmounted control console designed for 19” rack systems. The JKP115e/117e is designed for the control and access of server farms or automation applications. The JKP115e/117e integrates a 15/17 inch color TFT LCD module, which supports up to XGA (1024 x 768 ) and 16.7M, 8 bit color. -
Page 32: Specifications
Check to make sure that the unit was not damaged during shipment. If you encounter a problem, contact your dealer. Please read this manual thoroughly. Follow the installation guide and operation procedures carefully to prevent any damage to the JKP115eRM/117e, and/or any of the devices that connect to it. SPECIFICATIONS... -
Page 33: Display Diagrams
DISPLAY DIAGRAMS Console Drawer Handle LCD Display (15”/17”) LCD Display Controls External mouse port Touchpad and keyboard Mouse and touch Pad switch Power LED Power Switch Rack mounting Brackets 1. DC input 2. CPU Port Connect your computer / KVM switch here. - Page 34 HARDWARE REQUIREMENT Computer ． 6 Pin PS/2 mini DIN, keyboard port. ． 6 Pin PS/2 mini DIN, mouse port. ． VGA ,SVGA, MultiSyncR. Above equipment must be built in one computer. The KVM console must support the following specification. ． 6 Pin PS/2 mini DIN, keyboard port.
- Page 35 JKP115e/117e Gently slide the RM chassis into the fixed brackets of the rack rail assembly. Fasten the front-end screws. Your RM Switch is now ready for use; locate the Smart handle, slide out the console and flip the LCD cover. (Note: The front-end screws must be fastened to properly secure the RM chassis to the server rack.) Installation of JKP115eRM/117e Plug the VGA/Mouse/Keyboard cable to the JKP115eRM/117e unit.
- Page 36 LCD FLAT PANEL DIPSLAY Panel Controls and OSD Functions Press “MENU” Button, display will show following picture. Continue to press “ “ and “ ” button to select function. Then ,press “ SEL” to enter these functions and adjust them to your personal Auto Brightness Contrast Horizontal...
- Page 37 Auto Brightness Contrast Horizontal Vertical Color OSDHP OSDVP OSD Time Language Recall Exit Press the “SEL” button to enter. Use the “ “ and “ ” button to adjust the brightness of the display. Press the “SEL” button to go back to main menu. Brightness Adjust LCD brightness level 0-255 of the image.
- Page 38 Horizontal Adjust LCD display horizontal level 0-255 Vertical Adjust LCD display vertical level 0-255 Recall Adjust LCD setting back to previous setting Color OSDHP Adjust OSD horizontal level 0-255 OSDVP Adjust OSD vertical level 0-255 OSD TIME Adjust OSD time 5-60 seconds Language Chinese, English Recall...
-
Page 39: Vcci Warning
FCC CERTIFICATIONS This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
